Repotec RP VC102EP ML User Manual

Vdsl2 pse lan extender
Hide thumbs

Advertisement

Table of Contents

VDSL2 PSE LAN Extender
User Manual
Ver 1.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RP VC102EP ML and is the answer not in the manual?

Questions and answers

Related Manuals for Repotec RP VC102EP ML

Summary of Contents for Repotec RP VC102EP ML

  • Page 1 VDSL2 PSE LAN Extender User Manual Ver 1.02...

  • Page 2: Table Of Contents

    Table of Content 1. Introductions ......... 2 2. Features ..........2 3. Packing Contents ......... 3 4. LED Indicators ........4 5. Dip Switches Settings ......5 6. Data Rates & Distances ....... 6 7. Application Notes ......... 7 (P/N: 41NE-VC102EP0-A00)

  • Page 3: Introductions

    1. Introductions The VDSL2 (Very high-bit-rate Digital Subscriber Line) PSE LAN Extender, provides a broadband transmission up to 100/60Mbps of downstream/upstream data rate over single pair copper line for point-to-point Ethernet connectivity. With 100/60Mbps data rate, VDSL2 PSE LAN Extender supports transmission distance up to 300 meters, and 30/10 Mbps for 1km long range connection.

  • Page 4: Packing Contents

     Fast mode guarantees a minimum end to end latency less than 1  Interleaved mode provides impulse noises protection for any impulse noise with a duration less than 250 us. Interleaved mode has a maximum end to end latency of 10 ms. Interleaved mode is the default mode.

  • Page 5: Led Indicators

    4. LED Indicators On the front panel of VC102EP, there are four LED indicators as the following POWER: “Green On” indicates power is on and normal. LAN: “Green On” indicates Ethernet LAN port is in connection. “Flashing” indicates Ethernet LAN data activities. DSL: “Green On”...

  • Page 6: Dip Switches Settings

    5. Dip Switches Settings Pin 1 Pin 2 Pin 3 Pin 4 VTU-C/R Mode Rate Limit 50/20 VTU-C Interleaved Mbps VTU-R Fast Full Rate Pin 1: VTU-C/R Switch VTU-C: VC102EP will act as at the Central Office (CO) site. VTU-R: VC102EP will act as at the Customer Premise Equipment (CPE) or Remote site.

  • Page 7: Data Rates & Distances

    Pin 3: Rate limit control 50/20 Mbps: Line rate limited to 50/20 Mbps. Full Rate: Provides up to 100Mbps/60Mbps line rate in short line. Pin 4: Signal to Noise Ratio (SNR) 9dB: Higher SNR margin (9dB) will result in less error with more stable VDSL2 link.

  • Page 8: Application Notes

    7. Application Notes 1) Ethernet To Ethernet Bridge Extension Central Office Remote Site VC102E VTU-C VC102EP PSE VTU-R 100/60Mbps up to 300 meters Max 2km for VDSL Link 2) Ethernet To Ethernet Bridge Extension VC102E VC102EP...
