  • Page 1 User’s Manual...
  • Page 2 ULTRADRIVE PRO DCX2496 IMPORTANT SAFETY INSTRUCTIONS...
  • Page 3 ULTRADRIVE PRO DCX2496 ULTRADRIVE PRO Ultra High-Precision Digital 24-Bit/96 kHz Loudspeaker Management System ®...
  • Page 4 ULTRADRIVE PRO DCX2496...
  • Page 5 ULTRADRIVE PRO DCX2496...

  • Page 6: Table Of Contents

    ULTRADRIVE PRO DCX2496 FOREWORD TABLE OF CONTENTS 1. INTRODUCTION ............7 2. CONTROL ELEMENTS ..........7 3. QUICK START ............9 4. MENU STRUCTURE AND EDITING ....... 10 5. AUDIO CONNECTIONS .......... 20 6. APPLICATIONS ............21 7. SPECIFICATIONS ........... 34...

  • Page 7: Introduction

    ULTRADRIVE PRO DCX2496 2. CONTROL ELEMENTS 1. INTRODUCTION Fig. 2.1: Input LEDs and display CLIP MUTE 1.1.1 Shipment 1.1.2 Initial operation Fig. 2.2: Menu buttons and data wheel COMPARE PAGE PARAM 1.1.3 Warranty CANCEL...
  • Page 8 ULTRADRIVE PRO DCX2496 Fig. 2.5: Output connectors Fig. 2.3: Output LEDs CLIP Fig. 2.6: Input connectors LIMIT MUTE Fig. 2.4: Mains connector and RS-232/RS-485 interface FUSE HOLDER TERM...

  • Page 9: Quick Start

    ULTRADRIVE PRO DCX2496 3. QUICK START Fig. 3.3: Mute ß Select Fig. 3.1: Setup ß In/Out Fig.: 3.5: Store ß Internal/Card Fig. 3.2: Out ß X-Over Points Fig. 3.6: Recall ß Internal/Card...

  • Page 10: Menu Structure And Editing

    ULTRADRIVE PRO DCX2496 4. MENU STRUCTURE AND EDITING ß Fig. 4.2: Output configuration Fig. 4.3: Setup ß In/Out 4.2.1 IN/OUT 1. MONO (no stereo links) Fig. 4.1: Setup ß In/Out Fig. 4.4: Output configuration MONO...
  • Page 11 ULTRADRIVE PRO DCX2496 2. L(1) M(2) H(3) L(4) M(5) H(6) Fig. 4.5: Output configuration LMHLMH 3. L(1) L(2) M(3) M(4) H(5) H(6) Fig. 4.6: Output configuration LLMMHH 4. L(1) H(2) L(3) H (4) L(5) H(6) Fig. 4.7: Output configuration LHLHLH Fig.
  • Page 12 ULTRADRIVE PRO DCX2496 Fig. 4.9: Setup ß In/Out Fig. 4.12: Setup ß Dly-Corr./Auto-Align Fig. 4.10: Setup ß In/Out Fig. 4.13: Setup ß Dly-Corr./Auto-Align Tab. 4.2: In Stereo Link 4.2.2 DLY-CORR./AUTO-ALIGN Fig. 4.14: Setup ß Dly-Corr./Auto-Align Fig. 4.11: Setup ß Dly-Corr./Auto-Align 4.2.3 COPY...
  • Page 13 ULTRADRIVE PRO DCX2496 Fig. 4.20: Setup ß Page Lock Fig. 4.16: Setup ß Copy Fig. 4.21: Setup ß Page Lock Fig. 4.17: Setup ß Copy Fig. 4.18: Setup ß Copy 4.2.4 PAGE LOCK 4.2.5 GLOBAL LOCK Fig. 4.19: Setup ß Page Lock...
  • Page 14 ULTRADRIVE PRO DCX2496 Fig. 4.22: Setup ß Global Lock Fig. 4.26: PC (RS-232) mode 2. LINK (RS-485) Fig. 4.23: Setup ß Global Lock Fig. 4.27: Setup ß Miscellaneous 4.2.6 MISCELLANEOUS Fig. 4.24: Setup ß Miscellaneous Fig. 4.28: LINK (RS-485) mode 3.
  • Page 15 ULTRADRIVE PRO DCX2496 Fig. 4.31: In A ß Gain 4.3.2 DELAY/NAME Fig. 4.30: PC -> LINK mode Fig. 4.32: In A ß Delay/Name 4.3.3 EQ Fig.4 .33: In A ß EQ 4.3.1 GAIN...
  • Page 16 ULTRADRIVE PRO DCX2496 Fig. 4.35: In A ß Dynamic EQ (ß Dynamics) 4.3.4 DYNAMIC EQ (FILTER) Tab. 4.3: Band-pass settings with extreme values (results in fig. 4.36) Fig. 4.34: In A ß Dynamic EQ (ß Filter) Fig. 4.36: Filter curves with gain above/below threshold...
  • Page 17 ULTRADRIVE PRO DCX2496 4.4.1 INPUT/GAIN Fig. 4.37: Sum ß Input/Gain Tab. 4.4: Default output names, depending on output configuration 4.5.2 X-OVER POINTS Fig. 4.39: Out 5 ß X-Over Points left right 4.5.1 GENERAL left right-hand Fig. 4.38: Out 5 ß General...
  • Page 18 ULTRADRIVE PRO DCX2496 Fig. 4.40: Out 5 ß Limiter Fig. 4.43: Mute ß Select 4.5.4 POLARITY/PHASE Fig. 4.41: Out 5 ß Polarity/Phase 4.5.5 DELAY Fig. 4.42: Out 5 ß Delay Fig. 4.44: Recall ß Internal/Card Fig. 4.45: Recall ß Internal/Card...
  • Page 19 ULTRADRIVE PRO DCX2496 AUTO-STORE 4.8.2 DELETE/FORMAT Fig. 4.49: Store ß Delete/Format 4.8.1 INTERNAL/CARD Fig. 4.50: Store ß Delete/Format Fig. 4.46: Store ß Internal/Card Fig. 4.51: Store ß Delete/Format Fig. 4.47: Store ß Internal/Card Fig. 4.52: Store ß Delete/Format Fig. 4.48: Store ß Internal/Card...

  • Page 20: Audio Connections

    ULTRADRIVE PRO DCX2496 Fig. 4.53: Store ß Delete/Format Fig. 4.57: Store ß Copy 4.8.3 COPY 4.8.4 PRESET-LOCK Fig. 4.58: Store ß Preset-Lock Fig. 4.54: Store ß Copy 5. AUDIO CONNECTIONS Fig. 4.55: Store ß Copy Fig. 4.56: Store ß Copy...

  • Page 21: Applications

    ULTRADRIVE PRO DCX2496 6. APPLICATIONS...
  • Page 22 ULTRADRIVE PRO DCX2496 Fig. 6.1: Stereo 3-way operation...
  • Page 23 ULTRADRIVE PRO DCX2496 Fig. 6.2: Stereo 2-way operation plus subwoofer...
  • Page 24 ULTRADRIVE PRO DCX2496 Fig 6.3: 3x2-way operation [LCR/Triple Bi-Amping]...
  • Page 25 ULTRADRIVE PRO DCX2496 Fig. 6.4: Stereo operation plus mono subwoofer...
  • Page 26 ULTRADRIVE PRO DCX2496 Fig. 6.5: Stereo operation plus 2 woofer cabinets...
  • Page 27 ULTRADRIVE PRO DCX2496 Fig. 6.6: Stereo 2-way operation plus subwoofer and additional monitor...
  • Page 28 ULTRADRIVE PRO DCX2496 Fig. 6.7: Mono 6-way “Zoning” (signal distribution mode)
  • Page 29 ULTRADRIVE PRO DCX2496 Fig. 6.8: Triple stereo delay line...
  • Page 30 ULTRADRIVE PRO DCX2496 Fig. 6.9: Surround 3.0 ®...
  • Page 31 ULTRADRIVE PRO DCX2496 Fig. 6.10: 4-way mono-bridged operation plus 2 monitors (per stereo side)
  • Page 32 ULTRADRIVE PRO DCX2496 Fig. 6.11: 5-way mono operation plus 1 additional mono signal (per stereo side)
  • Page 33 ULTRADRIVE PRO DCX2496 Fig. 6.12: Surround 5.1...

  • Page 34: Specifications

    ß ß ß ® ® BEHRINGER makes every effort to ensure the highest standard of quality. Necessary modifications are carried out without notice. Thus, the specifications and design of the device may differ from the information given in this manual.

  • Page 35: Warranty

    ULTRADRIVE PRO DCX2496 8. WARRANTY ®...
  • Page 36 FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE INFORMATION ULTRADRIVE PRO DCX2496 MUSIC Group Services USA, Inc. Responsible party name: 18912 North Creek Parkway, Address: Suite 200 Bothell, WA 98011, Phone: +1 425 672 0816 Phone/Fax No.: Fax: +1 425 673 7647 ULTRADRIVE PRO DCX2496...
