the bottom of the blade holder.
3. Loosen the Thumbscrew on the Cradle enough for the thumb-
screw to swing to the right. Be careful not to loosen the Thumb-
screw too much or it will fall out!
4. The Cradle should easily swing open to the left.
5. Insert the Blade Holder so that the middle section of the Blade
Holder is resting in the Cradle.
6. Close the Cradle, swing the Thumbscrew to the left and tighten it.
7. Check to make sure the Blade Holder is resting securely in the
Cradle. The Blade Holder should not be able to move within
the Cradle.
8. To remove the Blade Holder again, simply repeat steps 3 and 4.
Inspiration Vūe

Adjusting Blade Depth

The Inspiration Vūe
als. This is acheived by adjusting the blade depth and the force ap-
plied when cutting. The force applied
(pressure) is set in your software. The
depth that the blade will cut to is ad-
justed by twisting the top of the blade
holder. As you twist the top of the
blade holder, an arrow on the side
of your blade holder will point to the
length you have set your blade. The
larger the number, the more of the
blade that is exposed, and the thick-
er the material you can cut through.
Tip: If you are working with a new material, start with a low
blade length. If it doesn't cut through, increase the pressure in the
software and the blade length and perform the cut again. Multi-
pass cutting is often the best way to cut thick or dense materials
12
Blade Holder
™
is designed to cut a variety of different materi-
™
Push Button
Twist Top
Blade Length
Indicator
