8. Roller Bar: This bar moves your mat through the Inspiration™ as
it is cutting.
9. Mat loading area: This is the proper area to load your mat into
before pressing the Load button (see #7).
10. Slide out tray: This helps support your mat as it travels in and out
of the machine.
11. Blade holder: This is what the Inspiration Vūe
12. Thumbscrew: Loosen to remove the blade holder and tighten to
secure the blade holder back in place.
13. Blade carriage: This carriage moves left and right to move the
blade holder while the Inspiration Vūe
Inspiration Vūe
Blade Holder
Cradle
Thumb Screw

Instructions for Inserting and Removing the Blade Holder

1. Before inserting the Blade Holder, make sure that the black ar-
row on the blade holder points to the number 1.
2. Check to make sure that the blade is inserted into the blade
holder with the sharp end of the blade slightly exposed out of
Carriage
™
blade is held in.
™
is cutting.
™
Carriage
