RECHARGEABLE WET/DRY VACUUM CLEANER Model: CVC633 充電式乾濕兩用吸塵機 型號: CVC633 Read this operation manual carefully before using the product. Keep this operation manual in a safe place. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruc- tion concerning use of the appliance by a person responsible for their safety.
INSTRUCTION FOR USE Before using your vacuum cleaner for the first time, allow the battery to charge for approx. 16 hours. SPECIFICATION: 12V Rechargeable NiMH Battery Adaptor Input : AC 200V-240V ~ 50/60Hz Adaptor Output: DC 18V 200mA PARTS: 1. HANDLE 8.
MOuNTING THE CHARGING BRACKET Select a point in the vicinity of a wall socket, indoors and not subject to damp. Position the bracket against the wall and mark the points at which the fastening screws are to be inserted. Using a 5mm diameter drill, drill the holes for the screws, insert the plastic anchor provided, and then screw in the screws until only the last 5mm is still protruding.
REMOVING BATTERIES 1. Open the battery cover. 2. Cut the straps on both side of battery. 3. Pull out the battery. 4. Rotate the wire nuts anticlockwise to disconnect the batteries. 5. The battery must be recycled or disposed of properly. –...
