Performer High Racer Assembly Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Congratulations
on your purchase of Performer High Racer. Performer High
Racer are made to enhance comfort, performance and to fit your various needs on
touring, shopping and communicating. Let's have fun with your Performer High Racer.
When you receive your High Racer, please make sure all parts referred to in the
instructions have been included. Your new High Racer has been assembly 50%. Please
refer to assembly guide for more details on individual steps.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the High Racer and is the answer not in the manual?

Questions and answers

Related Manuals for Performer High Racer

Summary of Contents for Performer High Racer

  • Page 1 Let’s have fun with your Performer High Racer. When you receive your High Racer, please make sure all parts referred to in the instructions have been included. Your new High Racer has been assembly 50%. Please...
  • Page 3 High Racer parts in the carton Quick release Cable housing Pedal Rubber Reflector Tool Chain Brake wire Shifter wire Rear derailleur...

  • Page 4: Table Of Contents

    Table of content ASSEMBLY GUIDE SSEMBLY MAIN FRAME AND WHEELS ROUTING CHAIN DJUST THE CHAIN LENGTH INSTALL BRAKE AND SHIFTER CABLE HIFTER CABLE DJUST DERAILLEUR RAKE CABLE 錯誤! 尚未定義書籤。 ADJUST HANDLEBAR INSTALL PEDAL SEAT GUIDANCE FOR SAFETY USE WARRANTY IMITED WARRANTY OES NOT COVER ROCEDURE...

  • Page 5: Assembly Guide

    Assembly guide Assembly main frame and wheels 1. Install rear derailleur (pic 1) 2. Install rear wheels on the main frame by rotating the quick release on rear wheel (pic 2) 3. Install front wheels on the main frame by rotating the quick release on front wheel (pic 3) Note: The spare paint on the fork dropout will lead to the difficulty of installing wheel.

  • Page 6: Routing Chain

    Routing chain Normally, our recumbent is suitable for people with 165cm~195cm tall. As a result, we always make our front boom long enough to fit various peoples’ height. Some people need to cut boom shorter to find suitable position. Insert front boom to main frame then sit on seat and step vertically on pedal and move front boom in or out to adjust a comfortable leg length.
  • Page 7 1. Attaching the chain through the front derailleur cage (pic 6) 2. Run through the lower chain tube (pic 7) 3. Under big pulley and free wheel, over the sprockets and down through rear derailleur (pic 8/9) 4. Put the rest chain above small pulley and through the upper tube. Please don’t cut or link the chain unless you find out the proper chain length.

  • Page 8: Adjust The Chain Length

    Adjust the chain length The proper chain length is determined by the sitting place of rear derailleur (pic 12). When the derailleur cage is sitting too high, the chain is too long (pic 13). On the other hand, the chain is too short Pic 13 Pic 12 Shift onto the smallest chainring in the front and shift down to the smallest cog in...

  • Page 9: Install Brake And Shifter Cable

    Install Brake and shifter cable Install handlebar Place the Riser on the stem and tighten riser clamp (pic 14) Align the riser to the front wheel If the stem is not align to the front wheel, please adjust stem by screwing bolts in or After alignment, tighten stem Placing handlebar (pic 15) Pic 14...
  • Page 10 By fork If you want to cut fork shorter, the cutting distance is based on 1cm (spacer width) and it’s multiple. You can contact with your local bike shop to cut for you, if you are not familiar with doing that. By Cutting riser In case you are still not comfortable with handlebar position, you can cut the raiser shorter.

  • Page 11: Shifter Cable

    Install Brake and shifter cable The routing way is not important, while sharp bends are avoided. Cable guides are on the front boom, rear chain stay or under the frame. Grip shifter has been installed on handlebar and been threaded shifter wire. As for bar-end shifter, please slide the shifter wire into the small hole of bar-end shifter first.

  • Page 12: Adjust Derailleur

    Cable for front derailleur (at left side) Repeat the same for the other side Pic 19 Pic 20 Adjust derailleur 1. Check whether the chain can shift to the largest and smallest cog. 2. If doesn’t work, loosen L/H on rear derailleur. 3.

  • Page 13: Brake Cable

    Brake cable Front brake cable (at right side): 1. Squeeze the brake lever to open it up and place the head of the cable into the lever. 2. String the brake wire into cable. 3. Tuck the cable into cable guide. 4.
  • Page 14 Adjust brake Performer recumbent is equipped with disc brake or rim brake. Please read the manual from brake manufacturer Rim brake Check brake pads, make sure they are aligned on the rim. If not, turning the adjusting barrel on rim brake...

  • Page 15: Install Pedal

    Install pedal Grease pedal and screw in right pedal clockwise and left pedal anti-clockwise. Make sure it’s tight enough. Seat Install seat onto the seat bracket, once you find your prefer position. Lock seat clamp and headrests tightly. Please make sure the seat is completely tight, otherwise the loosed bolts on FRP seat will break the seat from the bottom after a period of time.

  • Page 16: Warranty

    The decision to repair and replace is at the sole discretion of Performer. This warranty coverage extends only to the original purchaser, and is not transferable.
