Part
Number
0304-3461
0304-3462
0304-3467
0304-3468
3015-5636
2020-0001
2020-0002
2020-0004
2020-0005
2020-0006
2020-0007
2020-0008
2020-0010
2020-0011
2020-0037
2020-0012
2020-0013
2020-0014
2020-0015
2020-0016
2020-0017
2020-0039
2020-0018
2020-0019
2020-0040
2020-0020
2020-0021
2020-0022
2020-0023
2020-0024
2020-0025
2020-0026
22
0.561.8187
Dwg
Item #
Power supply cord, CEE 7/7
Power supply cord, SANS 164-1
1 Power supply cord, AS 3112
Power supply cord, NEMA 5-15
Power supply cord, BS 1363
31 In-line filter
32 Hose (4" long, 3/16" I.D.)
2 80% Shut-off cord
30 Shoulder strap
3 Filter screen for inlet fitting
4 Inlet fitting O-ring
29 Inlet fitting
5 Control knob
Circuit breaker; 110 V
6
Circuit breaker; 220 V
7 Gauge (input)
8 Gauge (output)
10 Switch (push-button, start)
11 Manifold assembly
12 O-ring, 67 x 2.65 mm (I.D. x wall thickness)
Capacitor (running); 110 V
13
Capacitor (running); 220 V
14 Circuit board (main)
Capacitor (starting); 110 V
15
Capacitor (starting); 220 V
16 O-ring, 2.8 x 1.8 mm (I.D. x wall thickness)
17 O-ring, 30 x 1.8 mm (I.D. x wall thickness)
18 Piston ring
19 Piston ring retaining plate
20 Screw, M5 x 14, stainless steel
21 Cylinder
22 Pin, 30 x 1.8 mm
