Premier L-5
Electric Engine
OPERATOR'S MANUAL
™
or
Advertisement
Table of Contents
Related Manuals for M.T.H. Premier L-5
Summary of Contents for M.T.H. Premier L-5
- Page 1 Premier L-5 Electric Engine OPERATOR’S MANUAL Compatibility This engine will operate on any traditional O-54 Gauge track system, including ® ™ M.T.H.’s RealTrax or ScaleTrax traditional tubular track. It is also compatible with most standard AC transformers. (See page 19 for a complete list of compatible transformers and wiring instructions.)
-
Page 2: Table Of Contents
Table of Contents Set Up Checklis t....................3 Lubrication.....................3 Checking The Battery................3 Basic Operation ....................4 Activating Features................4 Proto-Sound 2.0 Operating Instructions............6 Activating Proto-Sound 2.0 Conventional Mode Features....6 Freight Yard Sounds (FYS)..............7 Proto-Coupler® Operation..............8 Speed Control..................9 Locking Locomotive Into A Direction.......... -
Page 3: Set Up Checklist
You may find, if your locomotive was built several months before you set it up, that the rechargeable battery has run down and needs to be charged before operating. If you notice that the sounds are garbled, test and charge the engine as described in the "Self-Charging Battery Back-Up" on page 14. Premier L-5 Electric Locomotive... -
Page 4: Basic Operation
Neutral cycle neutral-forward-neutral-reverse with each press and release of the direction Reverse Forward button. The engine is programmed to Neutral restart in neutral each time the track voltage is turned off for 25 seconds or more. Premier L-5 Electric Locomotive... - Page 5 To adjust the volume of all sounds made by this engine, turn the master volume control knob located next to the fuel tank clockwise to increase the volume and counter-clockwise to decrease the volume. Proto-Sound 2.0 Volume Adjustment Knob Figure 2: Manual Volume Adjustment Knob Premier L-5 Electric Locomotive...
-
Page 6: Proto-Sound 2.0 Operating Instructions
Timing Chart Press ½ Sec. Press ½ Sec. Press Horn Pause Bell Pause Bell Short & Short & Short & Firm Firm Firm ½ Total Time Lapse: 1 Seconds Premier L-5 Electric Locomotive... -
Page 7: Freight Yard Sounds (Fys)
Once the bell turns off, the operator regains control of the transformer's Bell and Horn buttons and can ring the bell or blow the horn as usual. Premier L-5 Electric Locomotive... -
Page 8: Proto-Coupler® Operation
Horn button, allowing approximately ½ second to lapse between each quick button press. The sound of the liftbar and air line depletion will play, and the knuckle will be released. Fire Bell Horn Horn Horn Rear Coupler Premier L-5 Electric Locomotive... -
Page 9: Speed Control
Each time you shut down the engine completely, it will automatically turn speed control on. Speed Control Two Horn Blasts Place Bell Bell Horn Engine into (indicates change is made) Repeat to Return Neutral to Normal Condition Premier L-5 Electric Locomotive... -
Page 10: Locking Locomotive Into A Direction
• Cab Chatter plays at random intervals when the engine idles in neutral. • Engine Start-up and Shut-down sounds play when the engine is initially powered on or is powered off for five seconds or more. Premier L-5 Electric Locomotive... -
Page 11: Maintenance
4. After the 3rd motor mount screw has been removed, pull the motor away from the gearbox and lightly coat the motor worm gear and the bronze drive gear with grease. Premier L-5 Electric Locomotive... -
Page 12: Cleaning The Wheels, Tires And Track
Thereafter, keep an eye on the track and clean it when it gets dirty to ensure good electrical contact and to lengthen the life of the tires. Premier L-5 Electric Locomotive... -
Page 13: Traction Tire Replacement Instructions
5. Reassemble in the reverse order. One set of replacement tires is packaged with your model. Additional sets are available directly from the M.T.H. Parts Department(order online: www.mth-railking.com, e-mail: parts@mth-railking.com; mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532, FAX: 410-381-6122). Premier L-5 Electric Locomotive... -
Page 14: Headlight Replacement Instructions
Replace: If the sounds are not improved at the end of the 15-minute test charge, it is time to replace the batteries. Available through M.T.H. Parts. Premier L-5 Electric Locomotive... - Page 15 Battery Charger Port Figure 5: Battery Charger Port Disconnect battery and slide out of bracket Figure 6: Removing The Battery Premier L-5 Electric Locomotive...
-
Page 16: Troubleshooting Proto-Sound® 2.0 Problems
The following table should answer most questions. If your problem cannot be resolved with this table, contact M.T.H. for assistance (telephone: 410-381-2580; fax: 410-423-0009; service@mth-railking.com, 7020 Columbia Gateway Drive, Columbia MD 21046-1532). Premier L-5 Electric Locomotive... - Page 17 Premier L-5 Electric Locomotive...
- Page 18 Premier L-5 Electric Locomotive...
-
Page 19: Transformer Compatibility And Wiring Chart
Standard Lionel SW Unknown 130-Watt Standard Lionel TW 8-18v 175-Watt Standard Lionel ZW A,B,C or D 8-20v 275-Watt Standard Lionel Post-War A,B,C or D Common 0-20v 135/190 Watt Electronic Celebration Series ZW * Conventional Mode Only Premier L-5 Electric Locomotive... -
Page 20: Additional Features Accessible Of Dcs Remote Control System
Direction Control Set Up-User can set initial individual start-up direction (start in forward or reverse) for double-heading operations • Locomotive Consist Set-up-User can determine locomotive values for consist make-ups, allowing multiple locomotives belonging to a consist to operate together Premier L-5 Electric Locomotive... -
Page 21: Service & Warranty Information
