Art. 7311
WIDE TOUCH MONITOR TYPE 7311
INSTRUCTION MANUAL
Product is according to EC Directive 2004/108/CE and following norms.
GB
02/2011
RL.02
Cod. S6I.731.11E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7311 and is the answer not in the manual?

Questions and answers

Related Manuals for Elvox 7311

Summary of Contents for Elvox 7311

  • Page 1 Art. 7311 WIDE TOUCH MONITOR TYPE 7311 INSTRUCTION MANUAL Product is according to EC Directive 2004/108/CE and following norms. 02/2011 RL.02 Cod. S6I.731.11E...

  • Page 2: Table Of Contents

    WIDE TOUCH monitor type 7311 CONTENTS General description page User interface pages 4 - 5 Operation during a video call pages 6 - 7 Operation during self-start of the external camera page Description of home page page Video answering machine menu page 6.1.

  • Page 3: General Description

    WIDE TOUCH monitor type 7311 GENERAL DESCRIPTION Wide Touch is a latest-generation door entry monitor which combines an array of useful functions and technologies with all the classic features of a door entry monitor. Wide Touch enables you to record photo sequen- ces and audio conversations with visitors calling from external entrance panels, and to record audio conversations with other intercom devices.

  • Page 4: User Interface

    WIDE TOUCH monitor type 7311 USER INTERFACE The user interface consists of a soft-touch keypad and a touch screen. The keypad can be used to activate all the classic video entry functions, such as answering a call and opening the gate or door.
  • Page 5 WIDE TOUCH monitor type 7311 Touch screen Automatic record button Answer message playback button Menu for accessing: 3.1. Video Answering Machine menu 3.2. Family Memo menu 3.3. Picture Memo menu 3.4. Directory menu 3.5. Cameras and CCTV functions menu 3.6. Activations menu 3.7.

  • Page 6: Operation During A Video Call

    WIDE TOUCH monitor type 7311 3. OPERATION DURING A VIDEO CALL When a call is received, the name of the entrance from where the call is made (if entrance labels programmed) appears at the top of the screen. On receipt of a call and during a call you can: •...
  • Page 7 WIDE TOUCH monitor type 7311 Fig. 3.1 3.1 Controls (brightness, contrast, colour and conversation volu- Brightness Contrast Colour Conversation Control Control Control volume Control 7/32...

  • Page 8: Operation During Self-Start Of The External Camera

    WIDE TOUCH monitor type 7311 4. OPERATION DURING SELF-START OF EXTERNAL CAMERA Press the “eye” button to switch on the monitor to the main came- Once the image appears on the display, the conversation button will flash and you can then perform all the operations described in the previous paragraph.

  • Page 9: Description Of Home Page

    WIDE TOUCH monitor type 7311 5. HOME PAGE From the home page you can access the various menus and activate the recording and answering machine functions. In the middle of the display, the “envelope“ symbol (10) indicates the presence of new messages. The number on the envelope indicates the number of unread messages (fami- ly + audio/video answering machine).

  • Page 10: Video Answering Machine Menu

    WIDE TOUCH monitor type 7311 6. VIDEO ANSWERING MACHINE MENU In this menu you can play back and/or delete messages recorded by the entrance cameras, or record an answer message. Messages recorded from outside the property (“Vision Memo” messages) consist of audio files and a sequence of photographs.

  • Page 11: Recording An Answer Message

    WIDE TOUCH monitor type 7311 6.1. RECORDING AN ANSWER MESSAGE From the video answering machine menu (paragraph 6), access the “record answer message” submenu by pressing the icon. This function is used to record a message with a maximum duration of 32 seconds, to be played to the visitor if you are out or do not wish to be disturbed.

  • Page 12: Call Recording Menu

    WIDE TOUCH monitor type 7311 6.2. Call Recording menu From the video answering machine menu (paragraph 6), access the “Call Recording” submenu by pressing the icon. This function enables you to view a list of the last 10 calls received, indi- cating for each call: date, time and entrance panel from which the call was received.

  • Page 13: Family Memo Menu

    WIDE TOUCH monitor type 7311 FAMILY MEMO MENU From the home page you can access the Family Memo Menu by pressing icon. In this menu you can record new messages and play mes- sages left by family members or cohabitants. Up to 3 messages can be stored in the memory.

  • Page 14: Picture Memo Menu

    WIDE TOUCH monitor type 7311 PICTURE MEMO MENU The Picture Memo menu enables you to write a short message for the attention of your family members or cohabitants, by means of the remo- vable stylus (9). You can write up to 32 Picture Memo messages, after which message no.

  • Page 15: User Directory Menu

    WIDE TOUCH monitor type 7311 USER DIRECTORY MENU From the main menu you can access the “User directory menu” by tap- ping the icon. In this menu you can call other internal users (audio and video door entry units), by means of intercom calls. You first need to make a call and save the internal user in the directory, assigning a user name (maximum 14 characters) for each intercom appliance.

  • Page 16: User Directory Menu

    WIDE TOUCH monitor type 7311 The “User directory menu” functions are: Fig. 9.1 - Enter a new user in the directory by tapping the icon. Assigning the ID of the internal user requires the use of the self-learning function, which is described below. Each line can be assigned one name of up to 14 characters.

  • Page 17: Cameras And Cctv Functions Menu

    WIDE TOUCH monitor type 7311 10. CAMERAS AND CCTV FUNCTIONS MENU The Cameras and CCTV Functions menu is used to control images recorded by local cameras, if fitted. Camera(s) and movement sensors need to have been connected and the CCTV functions programmed by the installer.

  • Page 18: Activations Menu

    WIDE TOUCH monitor type 7311 To view the list of direct commands to the locks connected to the ACTIVATIONS MENU entrance panels, press the icon. From the main menu you can access the “Activations menu” by tapping Fig. 11.1 icon.

  • Page 19: Activations Menu

    WIDE TOUCH monitor type 7311 To view the list of F1 or F2 commands to the entrance panels, press To view the list of auxiliary commands to relays connected to the F1 F2 icon. system, press the icon. Fig. 11.3 Fig.

  • Page 20: Camera And Activations Menu

    WIDE TOUCH monitor type 7311 11.1. CAMERA AND ACTIVATIONS MENU From the camera menu you can switch on one of the outdoor cameras, the main camera or secondary ground floor cameras, depending on the type of installation. To switch on a camera, select it and then press the “...

  • Page 21: Settings Menu

    WIDE TOUCH monitor type 7311 12. SETTINGS MENU From the Settings menu you can: • Set the wake-up call function by tapping the icon • Adjust the volume controls for communicating with speech units and intercom devices, adjust the ringtone volume and recorded message...

  • Page 22: Wake-Up Call Menu

    WIDE TOUCH monitor type 7311 12.1. WAKE-UP CALL MENU After entering the wake-up call menu you can make the following adju- stments: Set the hour and minutes of the wake-up call (wake-up call time is always displayed in 24-hour format).

  • Page 23: Volume And Ringtone Controls Menu

    WIDE TOUCH monitor type 7311 12.2. VOLUME AND RINGTONE CONTROLS MENU After entering the volume and ringtone controls menu you can make the following adjustments: Adjust the volume for communicating with speech units Adjust the volume for communicating with intercom devices...

  • Page 24: Background Selection Menu

    WIDE TOUCH monitor type 7311 12.3. BACKGROUND SELECTION MENU Press the button to confirm the background and return to the previous menu. Select the previous background. Select the next background. 24/32...

  • Page 25: Time Slot Setup Menu

    WIDE TOUCH monitor type 7311 Start Start 12.4. TIME SLOT SETUP MENU If programmed (by the installer) the monitor can execute, in these time slots, the automatic activation of an auxiliary function or a programmed command, for example automatically releasing a lock on receiving an external call, switching on a light, activating an automation, etc.

  • Page 26: Menu For Setting Date, Time, Temperature And Formats

    WIDE TOUCH monitor type 7311 12.5 MENU FOR SETTING DATE, TIME, TEMPERATURE AND FOR- MATS From this menu you can make the following adjustments: a. Set hour and minutes b. Select the time display format (24h or am/pm) c. Set the date (day/month/year) d.

  • Page 27: Maintenance, Keypad And Touch Screen Lock

    WIDE TOUCH monitor type 7311 MAINTENANCE, KEYPAD AND TOUCH SCREEN LOCK To clean the monitor you need to activate the keypad and touch screen lock. To do this press and hold the central button on the keypad for five seconds, until you hear a beep. At this point the red “padlock” sym- bol appears at the bottom of the screen.
  • Page 28 WIDE TOUCH monitor type 7311 28/32...
  • Page 29 WIDE TOUCH monitor type 7311 29/32...
  • Page 30 WIDE TOUCH monitor type 7311 30/32...
  • Page 31 WIDE TOUCH monitor type 7311 SAFETY INSTRUCTIONS FOR INSTALLERS Directive 2002/96/EC (WEEE) -Carefully read the instructions on this leaflet: they give important information on The crossed-out wheelie bin symbol marked on the product indicates that at the safety, use and maintenance of the installation.
  • Page 32 10135 Turin Shanghai 201615 Milan Via Conti Biglia, 2 20162 Milan ELVOX Costruzioni elettroniche S.p.A. - ITALY Via Pontarola, 14/a - 35011 Campodarsego (Padova) Tel 049 9202511 - Fax 049 9202603 - info@elvox.com www.elvox.com Telefax Export Dept. +39/049 9202601 - elvoxexp@elvox.com...
