Front Panel Description
LED Indicator
1. PWR LED
2. WLAN LED
3. WAN LED ACT
4. LAN LED ACT
5. WPS LED ACT
State
Description
on
The WLAN Broadband Router is powered on.
off
The WLAN Broadband Router is powered off.
Flashing
Data is transmitting or receiving on the antenna.
off
No data is transmitting or receiving on the antenna.
Flashing
Data is transmitting or receiving on the WAN interface.
on
Port linked.
off
No link.
Flashing
Data is transmitting or receiving on the LAN interface.
on
Port linked.
off
No link.
1sec flash light /1sec light dark / attempt to communicate
Flashing
with wireless client
on
When user press WPS button
off
Default No link
