Bodytronics ProFit Instruction Manual

FEATURES:

•
Counts steps to 99,999 and miles/km to 999.99
•
Calculates calories burned and time spent walking or running.
•
Memory stores previous week totals and current week running total
•
Time of day clock
•
Clamshell case design prevents accidental resets and allows easy viewing while on waist
•
Anti-falsing filter ignores non-step movements for more accurate step tally
•
Large easy-to-read display
•
Slim, lightweight design is perfect for all-day wear with any attire

INITIAL SETUP:

1. Clip the pedometer on your belt or waistline.
2. Open the pedometer by grasping the top corners and pulling away from your body.
3. Remove pedometer from waist, leaving it open to reveal the display and buttons.
4. Press the mode (E) button until the > indicator points to DIST. Either ML (miles) or KM (kilometers) will be
displayed on the far left of the display. To change the units of measure press and hold the reset (A) button until
the display blinks and the desired units are displayed.
5. Press the mode (E) button until the > indicator points to KCAL. Press the set (B) button to enter your weight.
Pressing and holding the SET (B) button will increase the weight. The weight range is 60-300 pounds or 30-
135 kilos. To enter a weight lower than what is displayed simply continue past the maximum value and the
pedometer will start back at the low end of the range.
6. Measure your stride length by stopping mid-step and measuring from toe to toe. (Average 18"-30")
7. Press the mode (E) button until the > indicator points to DIST. Press the set (B) button to enter your stride
length. Pressing the SET (B) button will increase the stride. The stride range is from 1.00'-7.00' or 30-215cm.
To enter a stride lower than what is displayed simply continue past the maximum value and the pedometer will
start back at the low end of the range.
8. Press the mode (E) button until the > indicator points at the clock symbol. Press the set (B) button to set the
time. Pressing the set (B) button adjusts minutes, pressing the reset (A) button adjusts hours, pressing the recl
(C) button adjusts the day of the week. Press the mode (E) button when finished. Setup is now complete!

OPERATION:

1. Clip the pedometer on your belt or waistline.
2. Open the pedometer by grasping the top corners and pulling away from your body.
3. Press the mode (E) button until the > indicator points to STEP.
4. Press and hold the reset button for 2 seconds. The display should reset to 000000.
5. Close the case and begin walking. The case must be closed for the pedometer to operate correctly.
6. After exercise open the pedometer and press the mode (E) button to review your exercise data.

MEMORY RECALL:

1. Memory recall is available while in STEP, DIST, KCAL, and TIMER modes.
2. Press the mode (E) button until the > indicator points to the data to be recalled (step, dist, kcal, timer)
3. Press the recl (C) button to view the cumulative total for the previous week. All day of week bars will be
indicated on the top of the display. Press the recl (C) button to return to the current day/trip.
4. Press the total (D) button to view the cumulative total for the current week to this point in time. The day of week
bars will indicate which days of the week the count applies to. Press the total (D) button to return to the current
day/trip.
5. Repeat the steps above for each mode (step, dist, kcal, timer) for which you want to recall data.

POSITIONING THE PEDOMETER:

1. Clip the unit to your belt or to your waistline as close to the hip as possible. Do not be afraid to experiment
with positioning to obtain the best results for your body type.
2. Make sure the unit is placed level on your belt or waistline as shown below:
3. Test your pedometer by walking 20 steps on a hard, flat surface, and then check the pedometer display. If the
pedometer counts 18-22 steps the positioning is correct. If not, reposition the pedometer and repeat the test.
