Summary of Contents for ClearSounds QLinkTV
- Page 1 QLINKTV BLUETOOTH STEREO AUDIO TRANSMITTER USER GUIDE Better Sound in Every Ear...
- Page 3 Thank you for purchasing the ClearSounds QLinkTV Bluetooth Stereo Audio Transmitter. You are either really smart for purchasing the QLinkTV or someone really likes you and bought this for you. Or maybe you are both smart AND lucky to have someone who gave you the QLinkTV.
-
Page 4: Contact Information
Welcome Contact Information Please contact us with any questions that you might have. We are happy to assist you! ClearSounds Communications, Inc. 1743 Quincy Avenue, Suite 143 Naperville, IL 60540 USA 800-965-9043 (toll-free) Information Online To view & print additional... - Page 5 Safety Precautions The following precautions are the kind of boring but important information you should read to ensure maximum performance and safety when using the QLinkTV. Although it may seem fairly obvious that standing outside in a lightning storm wearing an electronic device is not wise, we do have to officially advise you that it’s not a good idea to do that-- along with these other nuggets of wisdom.
- Page 6 ‘low’ when not in use. WARNING: Do not spill liquid on the QLinkTV or clean it while it is plugged into AC power. This can cause a short circuit, a fire or electrical shock.
- Page 7 CAUTION: Some electronic devices that are not properly shielded will generate electromagnetic interference (EMI) that may cause buzzing or odd sounds in the QLinkTV (or any headset, for that matter). Examples of potential EMI-emitting devices include PCs, automobiles and large screen TVs.
- Page 8 Connect the supplied AC power adapter into a surge protector. Power surges can damage the equipment. CAUTION: To clean the QLinkTV unit, use only a cloth slightly dampened in a mild soap and water solution. Do not use harsh chemical or solvent cleaners or abrasive detergents.
-
Page 9: Table Of Contents
Contents Overview .........................8 Unpack ........................9 Getting Familiar ....................10 Charging .......................12 Turning On/Off ......................13 Attaching ......................14 Pairing to Bluetooth Devices ................16 Reconnecting to Bluetooth Devices ..............18 LED Indicator ......................19 Care and Maintenance ..................20 FAQs ........................21 Glossary of Terms ....................22 Specifications .......................24 Warranty Information ...................25... -
Page 10: Overview
Overview About the QLinkTV The QLinkTV is a Bluetooth stereo transmitter. Music, radio, TV shows, audiobooks and videos can be transmitted wirelessly from your MP3 player, computer, TV and other devices to your Bluetooth stereo receiver using the QLinkTV. Examples of compatible receivers include A2DP Bluetooth-enabled speakers, earphones, headsets, hearing aid streamers, personal neckloops and hearing aids with t-coils. -
Page 11: Unpack
Ensure that your packing box includes all of the parts shown below, in addition to a user guide. If any parts are missing or damaged, please contact your vendor or ClearSounds. IMPORTANT: YOUR RECEIPT IS REQUIRED FOR WARRANTY PURPOSES. PLEASE RETAIN YOUR RECEIPT. -
Page 12: Getting Familiar
USB charging cable into the QLinkTV. Multi-Function Button: This button is used to turn the QLinkTV on and off, pair the QLinkTV to your Bluetooth stereo receiver (e.g. headset) and connect the QLinkTV to a paired receiver. - Page 13 This is where you plug the 3.5mm audio cable into the QLinkTV. Battery Engage Switch: This switch, located on the back of the QLinkTV, MUST be in the position in order This is not the QLinkTV on/off switch. for it to function.
-
Page 14: Charging
To charge, connect the USB cable to the QLinkTV and to the AC power adapter as shown on page 10, then plug the AC power adapter into a standard power outlet or surge protector (recommended). -
Page 15: Turning On/Off
This is the only time you will ever need to touch this switch. In order to preserve the integrity of the battery while the QLinkTV travels from the production line to our warehouse and the warehouses of retailers across the country, we protect it by keeping the battery disengaged. -
Page 16: Attaching
Using your TV’s user guide, locate its 3.5mm audio-out (headphone) jack, which is likely on the back side. Plug one end of the 3.5mm audio cable into the QLinkTV as shown on page 11. Plug the other end of the 3.5mm audio cable into the 3.5mm audio-out jack on your TV. - Page 17 (the red and white connectors), which is likely on the back side. Plug one end of the 3.5mm audio cable into the QLinkTV as shown on page 11. Plug the other end of the 3.5mm audio cable into the single ‘female’ end of the analog RCA cable. Plug the RCA cable’s red and white connectors into the corresponding red and white audio jacks...
-
Page 18: Pairing To Bluetooth Devices
Pairing Pairing to Bluetooth Devices Once the QLinkTV is attached to your audio source, it will need to be paired to your Bluetooth stereo receiver in order to wirelessly enjoy audio. Before pairing, make sure your receiver supports A2DP Bluetooth. - Page 19 Things to note: • Pairing mode will last 1 minute. If no devices can be connected within that minute, the QLinkTV will enter standby mode and you will need to restart the pairing process. • The QLinkTV can only be paired to 1 Bluetooth stereo receiver at a time.
-
Page 20: Reconnecting To Bluetooth Devices
Bluetooth has been enabled on the receiving device. Manual connection When the QLinkTV is in standby mode and not connecting to any devices, briefly press the MFB once and it will automatically connect to the last connected device, as long as the above criteria are met. -
Page 21: Led Indicator
About the LED indicator Before attaching to your TV, computer or audio device, refer to the instructions below for information on connecting to the correct type of audio output jack. LED Indicator Status of QLinkTV blue LEDs are flashing In pairing mode... -
Page 22: Care And Maintenance
Do not expose the QLinkTV to liquid, moisture or humidity, to avoid potential damage to its internal circuit. • Do not expose the QLinkTV to extremely high or low temperatures, as this will shorten the life of electronic devices, destroy the battery or distort certain plastic parts. -
Page 23: Faqs
Customer Solutions team (see next page). 2) What should I do if my QLinkTV won’t pair & connect to a Bluetooth stereo receiver? First, make sure the Bluetooth stereo receiver supports A2DP v3 Bluetooth. Second, make sure the Bluetooth stereo receiver is placed within 5 feet of the QLinkTV. -
Page 24: Glossary Of Terms
Audio Output: Also known as ‘audio-out’, this is the jack on a TV, MP3 player or other device that sends sound (audio) out of the device. The QLinkTV, speakers, headphones or other listening tools get plugged into a device’s audio output. - Page 25 The abbreviation for the Radio Corporation of America. RCA carries audio and video signals through color-coded plugs and jacks; red & white for audio and yellow for video. The QLinkTV’s RCA cable is audio-only, so it is only red and white. USB: The abbreviation for Universal Serial Bus.
-
Page 26: Specifications
Specifications Component Specification Bluetooth version Bluetooth v3 Bluetooth profile A2DP, AVRCP Frequency range 2.4 GHz Effective range 33 feet/10 meters (indoor) Charging input voltage DC, 5V / 500mA Working time Up to 7 hours Charging time About 3 hours Dimensions 2”... -
Page 27: Warranty Information
Warranty Your ClearSounds QLinkTV Bluetooth Stereo Audio Transmitter comes with a one-year limited warranty from the date of purchase. This product is warranted by ClearSounds against manufacturing defect in material and workmanship under normal use. In the event that this product fails to function properly due to defects in... - Page 28 Warranty If a defect covered by this warranty should occur, promptly contact a Customer Service www.clearsounds.com/contact-us representative by phone, or log on to to obtain a Return Merchandise Authorization (RMA) number and shipping instructions before shipping the product to us. Any shipment without an RMA number will not be accepted and will be returned to you at your expense.
- Page 29 Ok, we may be a bit biased, but these products are fantastic complements to the QLinkTV. Together, they provide a solution for every aspect of communication. From personal listening to mobile phones, TV & entertainment to the office – we’ve got you covered.
- Page 30 © 2015 ClearSounds QLinkTV UG Ver 1...
