Newcastle Systems PowerPack Ultra 2.6 Assembly Instructions

Portable power system

Advertisement

The PowerPack 2.6 Portable Power System will be received in 1 piece.
There are (2) power switches on the PP2.6
There are (2) power outlets to plug in your equipment
There is (1) power cord (included) for charging the PP2.6
Nut, bolt and washers for battery connection included
Your equipment power outlets
Tools Included: 5/32 Allen wrench
Tools Required: (2) adjustable wrenches

To connect the battery for use:

1. Open the top cover using the 5/32 allen wrench
provided.
2. Slide back the black boot on the (-) black cable
(as shown on the right
1.
Assembly Instructions for
PowerPack Ultra 2.6 Portable Power System
)
Location of the two
power switches
Power cord for charging the unit;
(it plugs into side of unit)
Cord can be coiled neatly on top of unit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerPack Ultra 2.6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Newcastle Systems PowerPack Ultra 2.6

  • Page 1 Assembly Instructions for PowerPack Ultra 2.6 Portable Power System The PowerPack 2.6 Portable Power System will be received in 1 piece. There are (2) power switches on the PP2.6 • There are (2) power outlets to plug in your equipment •...
  • Page 2 3. Connect the black cable to the negative on the battery. (You will need (2) adjustable wrenches). Use 1 wrench to hold the bolt while tightening the nut with the other wrench. (Nut, bolt and washers provided). 4. Make sure connection is tight (as shown on the right 5.
  • Page 3 To charge the PP2.6 after each use: Turn your equipment off. Turn the bottom power Plug the female end of charging Plug the charging cord to switch off; (0) pressed in. power cord to the side of the unit as your wall outlet.
