GAMA Garden Kft.
H-4900, Fehérgyarmat, Szatmári utca 11.
Please read these instructions carefully and make sure
you understand them before using this machine.
1/15

Lawn Mower

Instruction manual
GLM 51S, GLM 51BS
www.gamagarden.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLM 51S and is the answer not in the manual?

Questions and answers

Related Manuals for Gama Garden GLM 51S

Summary of Contents for Gama Garden GLM 51S

  • Page 1: Lawn Mower

    GAMA Garden Kft. 1/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. Lawn Mower Instruction manual GLM 51S, GLM 51BS Please read these instructions carefully and make sure you understand them before using this machine.

  • Page 2: Table Of Contents

    GAMA Garden Kft. 2/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. CONTENTS SAFETY RULES ............3-5 TECHNICAL DATA ............6 OVERVIEW ..............7 ASSEMBLY ..............8-9 START AND STOP ............10 OPERATION..............11 MAINTENANCE ............12-13 GENERAL INFORMATION ........14 TROUBLESHOOTING ..........14-15...

  • Page 3: Safety Rules

    GAMA Garden Kft. 3/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. SAFETY RULES IMPORTANT: This cutting machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.

  • Page 4: Gama Garden Kft

    GAMA Garden Kft. 4/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. • Stop the blade if the lawnmower has to before restarting and operating the be tilted for transportation when crossing lawnmower; surfaces other than grass, and when - if the lawnmower starts to vibrate transporting the lawnmower to and from abnormally (check immediately).
  • Page 5 GAMA Garden Kft. 5/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. These symbols may appear on your machine or in the literature supplied with the product. Learn and understand their meaning.

  • Page 6: Technical Data

    GAMA Garden Kft. 6/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. TECHNICAL DATA Type GLM 51S GLM 51BS 162 cm 162 cm 104 cm 104 cm 57 cm 57 cm Sound power level 98 d(B)A 98 d(B)A Max. power 2.7 kW/3050 rpm 2.22 kW/2900 rpm...

  • Page 7: Overview

    GAMA Garden Kft. 7/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. OVERVIEW ASSEMBLING 1. Lower handle assembling • Insert pin into the round hole of lower handle from both left and right side. • Insert square neck bolt (M8X16) into the bracket and lower handle, then tighten with knob nut.

  • Page 8: Assembly

    GAMA Garden Kft. 8/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. • Insert bolt (M8X60) into right handle holder, lower handle, upper handle assembly and start rope hook in turn, then tighten with knob nut. • Fasten cables with the clips on the handle rod.

  • Page 9: Start And Stop

    GAMA Garden Kft. 9/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. Mow the lawn twice weekly during the most active periods of growth. Never cut more than 1/3 of the length of the grass, especially during dry periods. Mow with a high cutting height setting the first time. Examine the result and lower the mower to the desired setting.

  • Page 10: H-4900, Fehérgyarmat, Szatmári Utca

    GAMA Garden Kft. 10/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. Connect the cap (1) of cable to the spark plug (2), making sure that there is no grass or dirt either inside the cap or on the spark plug terminal.

  • Page 11: Operation

    GAMA Garden Kft. 11/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. OPERATION 1. The mower should not be used on ground that slopes more than 15°. This could cause engine lubrication problems. 2. To empty grass catcher: when the indictor cap is closed, the grass catcher is full.

  • Page 12: Maintenance

    GAMA Garden Kft. 12/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. • Wipe up the mower with dry cloth. MAINTENANCE AND STORGE Always remove the spark plug lead before repair, cleaning or maintenance work. After 5 hours running time, tighten screws and nuts.

  • Page 13: General Information

    GAMA Garden Kft. 13/15 www.gamagarden.eu H-4900, Fehérgyarmat, Szatmári utca 11. • Wash the foam element in liquid detergent and water. Squeeze dry in a clean cloth. • Saturate the foam element with 2 table-spoons of clean engine oil and squeeze it a few times to distribute the oil evenly.
  • Page 14 Guarantee terms Please carefully retain the guarantee card completed by the seller, or the proof of purchase. The company GAMA GARDEN provides a guarantee for 24 months from the date of purchase This guarantee is in accordance with the relevant state of technology and the utilization purpose / area of application The consumer„s statutory rights are not affected by the following guarantee...
  • Page 15 The used packaging materials must be thrown into the relevant waste collector. GAMA Garden Ltd., 4900 Fehérgyarmat, Szatmári u. 11 certifies CE conformity of the above-mentioned product and that it complies with the technical data specified in the data plate and the “Operating instructions”.
