- Page 1 CMP-MOBPLAY40 Media Player Enclosure with LAN connection ANLEITUNG MANUAL MODE D’EMPLOI GEBRUIKSAANWIJZING MANUALE MANUAL DE USO HASZNÁLATI ÚTMUTATÓ KÄYTTÖOHJE NÁVOD K POUŽITÍ BRUKSANVISNING...
- Page 2 1. Package contents 1 Media player enclosure Remote control Power adapter + cable Driver CD Manual 2 A/V cables USB cable Network cable 2. Hardware installation Step 1: Open the enclosure by unscrewing the back panel and pulling out the board. Step 2: After removing the board, connect the data and power cables to the hard drive and slide it carefully into the board.
- Page 3 Step 4: Gently slide the board with the hard drive connected to it back into the aluminum enclosure. Close up the enclosure with two screws on each side of the back plate. 3. Connections The enclosure has the following connections and buttons: Copy button (used for back-up software on PC) USB 2.0 connection Network connection (not shown in this picture)
-
Page 4: Remote Control Buttons
4. Remote control buttons Button Function Takes you to play or execute the current selection. Direction button to move cursor on the screen. DOWN Direction button to move cursor on the screen. LEFT Direction button to move cursor on the screen. RIGHT Direction button to move cursor on the screen. - Page 5 5. Set-up and use the player When you start the media player and connect it to the TV, you can adjust the TV settings in the set up main page. Press the SETUP button to enter the main menu for set up. Then go to PREFERENCES. You can choose the TV TYPE and select either MULTI-SYSTEM (PAL and NTSC), NTSC or PAL.
- Page 6 5.2 Video You can press the arrow key to select VIDEO from the main menu or press the VIDEO button on the remote control. Press the PAUSE button to pause or resume playback. Press STOP to stop playback of video. To go to the previous video file, press the PREVIOUS or REV button on the remote control.
- Page 7 6. LAN Share (network drive) Connect the included ethernet cable from the ethernet port on the player to the network connection on your switch/router. You can switch between MP4 play (Media Player) or Net HDD (network share mode). The lights on the front panel also indicate which mode is currently active.
- Page 8 2. INSTALL SHIELD WIZARD will appear, click NEXT. 3. Select I ACCEPT THE TERMS IN THE LICENSE AGREEMENT, and then click NEXT.. 4. Click INSTALL. 5. When this window appears, insert the Windows 98SE CD and click OK. 6. Select YES, I WANT TO RESTART MY COMPUTER NOW then click FINISH restart of the computer.
- Page 9 Note: NDAS device ID and Write Key do not contain the letter O. Please use the number 0 for all letter O’s. 6. Checking NDAS device status. 7. Select how you want to mount the NDAS device. 8. Registration is finished. Click Finish. 6.5 Add / Register a New NDAS device without using the Registration Wizard 1.
- Page 10 Safety precautions: To reduce risk of electric shock, this product should ONLY be opened by an authorized technician when service is required. Disconnect the product from mains and other equipment if a problem should occur. Warranty: No guarantee or liability can be accepted for any changes and modifications of the product or damage caused due to incorrect use of this product.
