- Page 1 121933B OWNERS MANUAL OCTOBER 2006 MDS Power, Inc. DC to AC Power Inverters OWNERS MANUAL for Models: MHI-24/5600DN Form 121933...
-
Page 2: Installation
2.03 The inverter is designed to operate any 120 VAC, 60 HZ single phase appliance, equipment or tool within its power ratings . 1. GENERAL 1.01 MDS Power inverters have been designed Inverter Rating and manufactured for many user applications and Inverter... - Page 3 manual. All wires should be copper conductors. 3.03 Mounting DC Input Wire Lengths (maximum) 3.03.1 Locate a suitable, secure vertical or and Fusing Guide horizontal mounting surface as close to the bat- Distance(feet) tery as possible without being in the same air tight Model 1-10 11-15...
-
Page 4: Start-Up Operation
“On” or “Off” by the remote switch. 5.03 Call MDS Power, Inc. for technical assis- tance and/or a return authorization number if the above steps are completed and the inverter still will not operate satisfactorily. - Page 5 WARNING: CONNECTING THE BATTERY WITH THE WRONG POLARITY TO THE INVERTER WILL CAUSE DAMAGE THAT IS NOT COVERED UNDER THE WARRANTY. FUSE REMOTE A.C. Output EARTH CHASSIS GROUND OUTPUT EARTH OR CHASSIS GROUND REMOTE SWITCH FUSE +24 FROM BATTERY CUSTOMER INSTALLED OPTION FIG.
