DENRYO Solar Amp mini User Manual

Solar charge controller
Hide thumbs Also See for Solar Amp mini:

Advertisement

Quick Links

Download this manual
Solar Charge Controller
User's Manual
Ver. 3.01
DENRYO CO., LTD.

Advertisement

loading

Related Manuals for DENRYO Solar Amp mini

Summary of Contents for DENRYO Solar Amp mini

  • Page 1 Solar Charge Controller User's Manual Ver. 3.01 DENRYO CO., LTD.

  • Page 2: Table Of Contents

    D / D ： Dusk to Dawn This Document must not be copied, photocopied, reproduced or converted to any electronic or machine-readable form in whole or in part without prior written approval of DENRYO CO., LTD. © 2010-2015   DENRYO CO., LTD. All Rights Reserved.

  • Page 3: Safety Information

    1. Safety Information 1-2 : Protect from direct rain 1-1 : Do NOT short circuit 1-3 : Explosion hazard 1-4 : Mounting direction 1-5 : Negative earth ground 1-6 : Do NOT reverse polarity connection − ＋ − ＋ ＋ −...

  • Page 4: Appearance

    2. Appearance MODE SW STATUS LED STATUS MODE SW MODE LED MODE ERROR LED ERROR SELECT SW SELECT SW RESET BATTERY LOAD ＋ − ＋ − ＋ − (mm)

  • Page 5: Connection

    3. Connection 3-1 : Connect wires to 3-2 : Connect to load SolarAmp mini It is recommended to install Screw tightly not to loose. an external fuses (less than 10A) between controller and load. − ＋ 3-3 : Connect to PV 3-4 : Connect to battery Cover the PV with cloth It is recommended to install...

  • Page 6: Operation

    4. Operation 4-1 : Battery Type Selection Follow the white arrow when you push the MODE SW (White Button). Follow the black arrow when you push the SELECT SW (Red Button). Battery Sealed Type Selection STATUS LED MODE LED Flooded LVD Voltage Compensation STATUS LED...
  • Page 7 4-2 : LVD Voltage Compensation Follow the white arrow when you push the MODE SW (White Button). Follow the black arrow when you push the SELECT SW (Red Button). Battery Type Selection STATUS LED MODE LED − 0.1V LVD Voltage Compensation STATUS LED Normal...
  • Page 8 4-3 : Night Light Type Selection Follow the white arrow when you push the MODE SW (White Button). Follow the black arrow when you push the SELECT SW (Red Button). Night Light OFF Battery (Load is always ON) Type Selection MODE LED STATUS LED Night Light ON...
  • Page 9 4-4 : Normal Timer Setting Follow the white arrow when you push the MODE SW (White Button). Follow the black arrow when you push the SELECT SW (Red Button). Battery 6 hours ON Type Selection STATUS LED MODE LED 8 hours ON LVD Voltage Compensation STATUS LED...
  • Page 10 4-5 : Rate Timer Setting Follow the white arrow when you push the MODE SW (White Button). Follow the black arrow when you push the SELECT SW (Red Button). Battery 40% of nighttime ON Type Selection STATUS LED MODE LED 50% of nighttime ON LVD Voltage Compensation...
  • Page 11 4-6 : Reset (1) Push MODE SW and SELECT SW simultaneously. (2) Release your hands from both of the SWs than LED blink twice. Successfully reset will be completed. 4-7 : Factory defaul (1) Push MODE SW and SELECT SW simultaneously. (2) Keep pushing MODE SW and release your hand from SELECT SW only.

  • Page 12: Led Indications

    5. LED Indications 5-1 : STATUS LED and ERROR LED during normal operation STATUS LED ERROR LED Indication Indication Description Description 1 blink LVD (LOAD OFF) 1 blink Battery Level Low 2 blinks Battery Error 2 blinks Middle 3 blinks PV Error 3 blinks Full...

  • Page 13: Night Light Timer

    6. Night Light Timer 6-1 : Multi Timer Night Night Light OFF (Load is always ON) Dusk-to-Dawn Normal Timer 6h Normal Timer 8h Normal Timer 10h Normal Timer 12h Normal Timer 14h Rate Timer 40% Rate Timer 50% Rate Timer 60% Rate Timer 70% Rate Timer 80% Four Operation Modes...
  • Page 14 6-2 : Early Start Lighting Function Night Dusk Turn on early Other controller's night light load ON point SolarAmp mini early start lighting load ON point SolarAmp mini has the early start lighting function. The load will start to turn on from dusk. This function will operate the following day after insatlling SolarAmp mini at the earliest.
  • Page 15 6-3 : Rate Timer Function Night Rate 80% Rate 70% Winter Rate 60% Rate 50% Rate 40% Rate 40% Rate 50% Summer Rate 60% Rate 70% Rate 80% SolarAmp mini rate timer is different from a traditional night-light timer. The lighting time of load is set by a rate (%) of night time. Even if the night time is changed seasonally, the lighting-off time will be apporoximately at the same time.

  • Page 16: Troubleshooting

    7. Troubleshooting 7-1 : Lighting ERROR LED LVD : The battery voltage is low. Please charge with the battery 12.5V or more until becoming it. Battery : The cause is as follows. Please check the wire connection and battery voltage for the system. PV : The PV voltage is lower than battery voltage.
  • Page 17 Model SA-MN05-8 System Voltage 12 V Max. input Voltage 25 V 8.5 A Max. input Current Max. load Current 8.5 A Min. input battery Voltage Negative ground Grounding Self-consumption Current 1 mA Reverse Polarity Protected Fuse：10 A - 20 ∼ + 60 ℃ Operation Temperature - 30 ∼...
  • Page 18 DENRYO CO., LTD. 28-5, Nishinippori 2 Chome, Arakawa-ku, Tokyo, 116-0013 Japan : +81-3-3802-3671 : +81-3-3802-2974 E-mail : info-en@denryo.com : www.denryo.com Website...
