B-CONTROL FADER BCF2000/B-CONTROL ROTARY BCR2000
Table 5.2: GS/XG Parameter Main Controls
ˆ†vphyÃI‚‡r
C-2
C#-2/Db-2
D-2
D#-2/Eb-2
E-2
F-2
F#-2/Gb-2
G-2
G#-2/Ab-2
A-2
A#-2/Bb-2
B-2
C-1
C0
C1
C2
C3 (Clef C)
C4
C5
C6
C7
C8
G8
Table 5.3: MIDI note number assignment
20
D9DÃI‚‡rÃIˆ€ir…
0
1
2
3
4
5
6
7
8
9
10
11
12
24
36
48
60 (Yamaha-Convention)
72
84
96
108
120
127

6. SPECIFICATIONS

6. SPECIFICATIONS
Type Full-speed 12 MBit/sec.
USB MIDI class-compliant
Type 5-pin DIN connectors IN, OUT A,
OUT B/THRU
BCF2000
Controls 8 motorized 100-mm faders
8 infinitely variable push encoders
with LED rings
Keys 20 keys
10 system keys (4x Encoder Group,
4x programming, 2x Preset)
BCR2000
Controls 24 infinitely variable encoders
with LED rings
8 infinitely variable push
encoders with LED rings
Keys 20 keys
10 system keys (4x Encoder Group,
4x programming, 2x Preset)
Type 4-digit 7-segment LED display
BCF2000
Footswitch 1 x 1/4" TS connector
with automatic polarity detection
Foot pedal 1 x 1/4" TRS connector
BCR2000
Footswitch
Input 1 1/4" TRS stereo connector for
dual-footswitch
Input 2: 1/4" TS connector
both with automatic polarity
detection
Voltage 85 - 250 V~, 50 - 60 Hz
Power consumption max. 10 W
Fuse
Mains connection Standard IEC receptacle
Dimensions
(W x H x D) 13" x 4" x 11 4/5"
(330 mm x 100 mm x 300 mm)
Weight
BCR2000 approx. 2,15 kg (4 ¾ lbs.)
BCF2000 approx. 2,60 kg (5 ¾ lbs.)
BEHRINGER is constantly striving to manintain the highest professional
standards. As a result of these efforts, modifications may be made from
time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
250 V
