- Page 2 PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com Please read instructions carefully before installation and use. Installation should be performed by a professional installer. To ensure your safety, the driver should not watch videos or operate features on the monitor while driving. There are no serviceable parts in this unit, do not disassemble or try to repair this unit. If the unit malfunctions please return to your vendor or send to a Pyle repair facility. Please observe and obey the local laws and regulations when installing the unit. Upon Installation, please make sure as to not to interfere with any of the vehicle's safety features, wiring, components, etc. We are not responsible for any damages, injury, malfunctions or otherwise noted due to faulty or non‐professional installation. Connection Connect the camera’s threaded locking 4‐pin cable connectors into the female receiving connection of the included 4‐pin extension cables. The extension cables then connect to your compatible video monitors with 4‐pin receiving connectors. The threaded locking cable connectors of the camera serve to provide power and video for all cameras. (camera 1 ‐ channel 1, camera 2 ‐ channel 2, camera 3 ‐ channel 3, camera 4 ‐ channel 4) Please remember to disconnect your vehicle's battery prior to any connection / installation. Use the included wiring harness to provide power and video signals to your monitor. There are colored wires to assist in the video camera system setup. See the wiring diagram for connections between cameras, monitor and your vehicle When turning the vehicle's ignition key or turning to the accessory or ON position, power is supplied to the camera system through the control box and the monitor will be in stand‐by mode. ...
-
Page 3: Wiring & Connection
PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com Wiring & Connection *When the Blue ‐ Reverse Trigger ‐ is connected, the system will automatically revert to this connection once the vehicle ... -
Page 4: Monitor Controls
PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com The video monitor is provided power and camera video signals via the video and power wiring harness. From the monitor, you will be able to control Ch. 1, Ch. 2, Ch.3 and Ch.4, input video cameras (V1, V2, V3, V4). The monitor also features the ability to rotate the input camera image horizontally (Left / Right) and vertically (Up / Down) to accommodate for camera placement in the rear of the vehicle (Rear view camera compatibility) or where upside‐down mounting is needed.. Monitor Controls 1 Power 2 Mode 3 Channel 1 ‐ Camera 1 4 Channel 2 ‐ Camera 2 5 ... -
Page 5: Monitor Stand Mounting
PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com Monitor Stand Mounting 1. Set the mount stand in the desired location, then use screws to secure the mount stand into location. Please make sure as to set a location free from vehicle obstruction including any wiring, or location where it may obstruct the driver's view, driving conditions, etc. ... - Page 6 PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com Model: PLCMTR74 Weatherproof Rearview Backup Camera & Monitor Video System, 7’’ Display Screen, (4) Night Vision Cameras, Commercial Grade, Dual DC Voltage 12‐24 for Bus, Truck, Trailer, Van Multi‐Camera & Monitor Video System View All (4) Cameras On‐Screen at the Same Time Includes All Necessary Cables & Wiring Video Display Viewing Modes: Single Full View: 1 picture ‐ from one camera input source Split Dual View: 2 picture ‐ from two camera input sources Split Quad View: 4 picture ‐ from four camera input sources Monitor: 7'' TFT/LCD Active Matrix Video Monitor Built‐in Quad Control Box Screen Function Supports Four Video Camera Inputs (V1/V2/V3/V4) Aspect Ratio: 16:9 Widescreen Format Selectable Viewing Modes: Single Full View / Split Dual Video View / Quad Four Source View PAL/NTSC Video Format Compatible Reverse Image (Backup Camera) Ability High Resolution: 480 x 234 4‐Pin Video Connectors Universal Stand & Anti‐Glare Sun Visor Operating Temperature: ‐20 to +65 Power Requirement: DC 12‐24V Dimensions (W x H x D): 6.77'' x 4.53'' x 0.87'' Camera: Includes (4) Mountable Cameras If you are experiencing any problems with your Weatherproof Rearview Camera System camera and monitor system please contact Marine Grade IP68 Rating support@pyleaudio.com. Image Sensor: Color CMD ...
