- Page 2 PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com Please read instructions carefully before installation and use. Installation should be performed by a professional installer. To ensure your safety, the driver should not watch videos or operate features on the monitor while driving. There are no serviceable parts in this unit, do not disassemble or try to repair this unit. If the unit malfunctions please return to your vendor or send to a Pyle repair facility. Please observe and obey the local laws and regulations when installing the unit. Upon Installation, please make sure as to not to interfere with any of the vehicle's safety features, wiring, components, etc. We are not responsible for any damages, injury, malfunctions or otherwise noted due to faulty or non‐professional installation. Connection Connect the camera’s threaded locking 4‐pin cable connectors into the female receiving connection of the included 4‐pin extension cables. The extension cables then connect to your compatible video monitors with 4‐pin receiving connectors. The threaded locking cable connectors of the camera serve to provide power and video for all cameras. (camera 1 ‐ channel 1, camera 2‐ channel 2, camera 3 - channel 3, camera 4 - channel 4) Please remember to disconnect your vehicle's battery prior to any connection / installation. Use the included wiring harness to provide power and video signals to your monitor. There are colored wires to assist in the video camera system setup. See the wiring diagram for connections between cameras, monitor and your vehicle ...
- Page 3 PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com Wiring & Connection Ch.2 / V2 is used as the rearview cameras as the backup camera input Red: Power 12/24V Black: GND Green: Reverse Trigger (Backup Camera) Blue: Turning Signal ‐ Left ‐ Trigger White: Turning Signal ‐ Right ‐ Trigger Brown: Forward Trigger When the Reverse Trigger (Green) wire is connected and powered through the vehicle, the ...
- Page 4 PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com The video monitor is provided power and camera video signals via the video and power wiring harness. From the monitor, you will be able to control Ch. 1, Ch. 2, Ch.3 and Ch.4, input video cameras (V1, V2, V3, V4). The monitor also features the ability to rotate the input camera image (Left / Right) to accommodate for camera placement in the rear of the vehicle (Rear view camera compatibility). 7'' Display Monitor A Sun Shade B LCD Display C Menu D Ch.1 ‐ Camera 1 E Ch.2 ‐ Camera 2 F ...
- Page 5 PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com Monitor Stand Mounting The U‐shaped mount stand bracket separates from the LCD display housing for attachment / fixture. The U‐shaped bracket attached to the desired location via 3 screw holes located at the base of the bracket. Please remove the LCD display monitor from the bracket before attempting to secure the bracket to your desired location. Once screwed into the desired location, attach the LCD display monitor housing and tighten with the tightening knob to the side of the housing. Adjust the angle / tilt of the LCD display before tightening the side knob. ...
- Page 6 PLCMTR ‐ Commercial Grade Camera System www.pyleaudio.com Model: PLCMTR104 Weatherproof Rearview Backup Camera & Monitor Video System, 10’’ Display Screen, (4) Night Vision Cameras, Commercial Grade, Dual DC Voltage 12‐24 for Bus, Truck, Trailer, Van Camera & Monitor Video System View All (4) Cameras On‐Screen at the Same Time Includes All Necessary Cables & Wiring Monitor: 10.1'' TFT/LCD Active Matrix Video Monitor Built‐in Quad Control Box Screen Function Supports up to (4) Video Camera Inputs (V1/V2/V3/V4) Selectable Viewing Modes: Single Full View / Split Dual Video View / Quad Four Source View Reverse Image (Backup Camera) Ability Aspect Ratio: 16:9 Widescreen Format PAL/NTSC Video Format Compatible Signal Sense: Auto Power‐On Reversing High Resolution: 1024 x 800 Pixels Universal Stand & Anti‐Glare Sun Visor 4‐Pin Video Connectors Power Requirement: DC 12‐24V Operating Temperature: ‐20 to +145 F Dimensions (W x H x D): 11.22'' x 7.20'' x 2.91'' Camera: Includes (4) Mountable Cameras Weatherproof Rearview Camera System LED IR Night Vision Illumination Marine Grade IP68 Rating Min Illumination: 0.2Lux Image Sensor: Color CMD Video System: PAL/NTSC Auto Switching Effective Pixels: 580 x 540 Resolution: 420 Lines ...
