Surefire SF308LP Use And Care Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

4 Burner w/ Rear Burner Gas Grill - LP
USE AND CARE MANUAL
Stop! Missing a part? DO NOT RETURN PRODUCT TO STORE
The store where you made the purchase does not stock
parts for this item. If you need parts, whether they are
missing or damaged, please call Customer Service at
Call us between 8:00 AM and 5:00 PM Eastern time, Monday through Friday
FOR YOUR SAFETY:
1. Read this Manual before attempting to assemble or operate your grill.
2. Follow safety instructions.
3. Check for leaks according to the directions in this Manual before operating your grill,
even if purchasing an assembled grill.
4. Keep this Manual for future reference.
5. Contact 1-800-229-5647 should you need assembly assistance or have any questions.
THIS GRILL IS FOR OUTDOOR USE ONLY.
If stored indoors, then detach and leave propane cylinder outside.
or email us at saleshelp@sureheat.com
SF308LP
1-800-229-5647

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF308LP and is the answer not in the manual?

Questions and answers

Related Manuals for Surefire SF308LP

Summary of Contents for Surefire SF308LP

  • Page 1 4 Burner w/ Rear Burner Gas Grill - LP USE AND CARE MANUAL SF308LP Stop! Missing a part? DO NOT RETURN PRODUCT TO STORE The store where you made the purchase does not stock parts for this item. If you need parts, whether they are...

  • Page 2: General Safety Instructions

    General Safety Instructions IMPORTANT SAFETY INFORMATION - Read this manual carefully before using your grill to reduce the risk of fire, burn hazard or other injury. - Extreme care should be used because of the high temperatures produced by this appliance.
  • Page 3 General Safety Instructions ▲ ▲ WARNING WARNING NOTE: DO NOT operate the main burners and DO NOT use the rotisserie in the rain. infrared back burner at the same time. This can cause warping of the roll top grill hood. ▲...

  • Page 4: Grill Features

    Grill Features 1. Roll top grill hood 8. Bread warming rack 2. Grilling/cooking surface 9. Rear Infrared burner 3. Side shelf 10. Side burner 4. Towel bar 11. Control Knob: Side burner 5. Control knob: Rear infrared burner 12. Electronic igniter: main burners, side burner, rear infrared burner 6.

  • Page 5: Getting Started

    Getting Started Self-tapping Screw x 13 Phillips Pan Head M6 x 10 Screw x 6 pcs Getting Started 1. Please follow the steps in the order that they are presented. 2. Assemble the grill where you plan to use it. 3.

  • Page 6: Grill Assembly

    Grill Assembly STEP ONE a. Remove the four (4) wheel channel assembly nuts and two (2) bolts from the wheel channel assemblies. Note: The bolts are hand tightened to the wheel channels. b. Set the Cart Base (1A) on the floor and then lay the Wheel Channel left (1B) on the left side and the Wheel Channel Right (1C) on the right side of the cart base.
  • Page 7 Grill Assembly STEP TWO a. Place the Cart Side Left (2A) onto the two (2) wheel channel assembly bolts, make sure the large flange is toward the front of the cart base b. Secure the cart side left in place by hand tightening the wheel channel assembly nuts onto the wheel channel assembly bolts.
  • Page 8 Grill Assembly STEP THREE a. Attach one end of the Spare L.P. Gas Tank Barrier (3A) to the cart back with a M5 screw and M5 nut, then attach the flat end of the barrier to the pre-drilled hole in the cart base with a self-tapping screw. The Spare L.P.
  • Page 9 Grill Assembly STEP FOUR a. Remove parts from inside grill hood, then tilt the Grill Head Assembly (4A) onto it's back. WARNING: Keep hands and fingers away from grill hood when moving Grill Head Assembly. Grill hood is loose and will open and close when moving into place. b.
  • Page 10 Grill Assembly STEP FIVE a. Remove the paper from the back of the Mirror Overlay (5A) and paste it onto the cart door. Make sure the two holes on the overlay match the holes on the cart door. b. Remove the protect film on the mirror overlay, Use one M6 x 10 phillips pan head screws (5B) to attach one samll handle end (5C) to the cart door.
  • Page 11 Grill Assembly STEP SIX a. Lay the Side Shelf Left Assembly (6A) on its side. Use one (1) M6 x 10 phillips pan head screw to attach one of the Handle Ends (6B) to the front of the shelf. Note: Be careful not to scratch the side of the shelf. b.
  • Page 12 Grill Assembly STEP SEVEN a. On the inside bottom of the side burner assembly you will find the brass burner cap attached with tape. Remove and set aside. b. Feed the side burner gas supply hose assembly through the large square hole in the side of the cart. c.
  • Page 13 Grill Assembly STEP EIGHT a. Remove two phillips pan head screws (8A) from the side burner valve assembly (8B). b. Carefully insert the valve assembly into the cast side burner. You will need to angle the tube into the side burner casting assembly (8C).
  • Page 14 Grill Assembly STEP NINE a. Place the Drip Pan (9A) on the drip pan guides underneath the grill head. b. Insert the Flavor Grids (9B) into the cut outs with triangle ridges facing up. c. Install Main Cooking Grates (9C) on the ledges provided on the grill to create your cooking surface.

  • Page 15: Gas Requirements

    Gas Requirements GENERAL INFORMATION ▲ Never attach an unregulated gas line to the appliance. Connection to WARNING an unregulated gas line can cause excessive heat or fire. Verify the type of gas supply to be used, either Natural Gas (N.G.) or Liquid Propane (L.P.), and make sure the serial plate agrees with that of the supply.

  • Page 16: Gas Installation

    Gas Requirements L.P. GAS INSTALLATION Sure Fire™ Gas Grills that are set to operate with L.P. gas come with a high capacity hose and regulator assembly. (Note: Only use the pressure regulator and hose assembly supplied with the grill or a replacement pressure regulator and hose assemblies specified by Sure Fire™).

  • Page 17: Pre Operation Leak Testing

    Pre Operation Leak Testing GENERAL INFORMATION Although all gas connections on the grill are leak tested prior to shipment, a complete gas tightness check must be performed at the installation site due to possible shifting during shipment, installation or excessive pressure unknowingly being applied to the unit. Periodically check the whole system for leaks and immediately check the system if the smell of gas is detected.

  • Page 18: Lighting The Grill

    Lighting the Grill Do not attempt to "Light" the grill if the odor of gas present!! BEFORE LIGHTING Fig. 1 Important! Before Lighting: ▲ WARNING • Check the gas supply line for cuts, wear or abrasion. • Always keep your face and body as far away from the grill as possible when lighting.
  • Page 19 Using the Grill and Side Burner GRILL LOCATION Do not use the grill in garages, breezeways, sheds or any enclosed area. Never operate the grill ▲ WARNING in enclosed areas as this could lead to a carbon monoxide buildup, which could result in injury or death.

  • Page 20: Using The Rotisserie Burner

    Using the Rotisserie Burner The grill rotisserie burner is designed to cook items from the back using infrared heat. The rotisserie burner is an infrared type which provides intense searing radiant heat. Preferred by chefs over other cooking methods, this intense heat sears in the natural juices and nutrients found in quality cuts of meats.

  • Page 21: Care And Maintenance

    Care and Maintenance PROTECTION OF INFRARED BURNERS The burners of your grill are designed to provide a long life of satisfactory performance. However, there are steps you must take to prevent cracking of the burner's ceramic surfaces, which will cause the burners to malfunction.
  • Page 22 Care and Maintenance DRIP TRAY The drip tray should be cleaned periodically to prevent heavy buildup of debris. NOTE: Allow the drip tray to cool before attempting to clean. Important: Do not leave the grill outside during inclement weather unless it is covered. Rain water can collect inside of the grill, the grill cart or the drip tray if left uncovered.

  • Page 23: Troubleshooting Your Grill

    Troubleshooting Your Grill GENERAL TROUBLE SHOOTING You should inspect the burners at least once a year or immediately if any of the following conditions occur: • The smell of gas. • Flames appearing mostly yellow. (some yellow at the tips is OK) •...
  • Page 24 Troubleshooting Your Grill Problem SOLUTION Grill will not light with a match or low heat with dial • Is your gas supply fully turned on? set to "High" position. • Is there gas in your L.P. tank? Check your gas level. •...

  • Page 25: Replacement Part List

    Replacement Part List Hood Assembly Main Burner Tube FCTG3007004 FCMD3008002 1 set 1 pcs Hood Handle Assy. Front Face Assy. FCCS0007007 FCMD3008003 1 set 1 set Manifold & Valve Assy. Temp. Gauge FCCS0007030 FCMD3008004 1 pcs 1 set Large Bezel Bread Warming Rack FCCS0007033 FCMD3008001...
  • Page 26 Replacement Part List Side Burner Casting Cart Door Right FCTG2608028 FCMD3008008 1 pcs 1 set Side Burner Brass Cap Cart Door Handle Assy. FCTG3007023 FCCS0007012 1 pcs 1 set Side Burner Grate Cart Back FCTG2707026 FCMD3008009 1 pcs 1 set Side Burner Right Assy.
  • Page 27 Replacement Part List Drip Pan FCCS0007037 1 pcs Wheel Channel Left Assy. FCCS0007014 1 set Wheel Channel Right Assy. FCCS0007015 1 set Not Shown: FCBJ3308027 Main Igniter w/ Wire 920 Main Igniter w/ Wire 740 FCBJ3308028 Main Igniter w/ Wire 540 FCBJ3308029 FCCS0007023 Back IR Igniter Wire...

  • Page 28: Limited Warranty

    LIMITED WARRANTY Sure Heat Mfg warrants that for 2 years from the date of purchase, the stainless steel panels will not break due to defects in material or workmanship. All other components of this grill are warranted free from defects in material and workmanship for one year from the date of purchase.
