Predator 62548 Owner's Manual & Safety Instructions

208cc 26"
Hide thumbs Also See for 62548:

Advertisement

Owner's Manual & Safety Instructions
Owner's Manual & Safety Instructions
Owner's Manual & Safety Instructions
Save This Manual
Save This Manual
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Keep this manual and the receipt in a safe and dry place for future reference.
Keep this manual and the receipt in a safe and dry place for future reference.
Using an engine indoors
CAN KILL YOU IN MINUTES.
Engine exhaust contains carbon monoxide.
This is a poison you cannot see or smell.
NEVER use inside
a home or garage,
EVEN IF doors and
windows are open.
Visit our website at: http://www.harborfreight.com
Email our technical support at: productsupport@harborfreight.com
Email our engine support at: predator@harborfreight.com
When unpacking, make sure that the product is intact
When unpacking, make sure that the product is intact
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
and undamaged. If any parts are missing or broken,
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
please call 1-888-866-5797 as soon as possible.
please call 1-888-866-5797 as soon as possible.
©
©
©
Copyright
Copyright
Copyright
2015 by Harbor Freight Tools
2015 by Harbor Freight Tools
2015 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
No portion of this manual or any artwork contained herein may be reproduced in
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
any shape or form without the express written consent of Harbor Freight Tools.
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
Diagrams within this manual may not be drawn proportionally. Due to continuing
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
improvements, actual product may differ slightly from the product described herein.
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Tools required for assembly and service may not be included.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Keep this manual for the safety warnings and precautions, assembly,
Keep this manual for the safety warnings and precautions, assembly,
Only use OUTSIDE
and far away from
windows, doors,
and vents.
®
®
®
. All rights reserved.
. All rights reserved.
. All rights reserved.
Read this material before using this product.
Read this material before using this product.
Read this material before using this product.
Failure to do so can result in serious injury.
Failure to do so can result in serious injury.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
SAVE THIS MANUAL.
SAVE THIS MANUAL.
REV 15l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 62548 and is the answer not in the manual?

Questions and answers

Summary of Contents for Predator 62548

  • Page 1 Visit our website at: http://www.harborfreight.com Email our technical support at: productsupport@harborfreight.com Email our engine support at: predator@harborfreight.com When unpacking, make sure that the product is intact When unpacking, make sure that the product is intact When unpacking, make sure that the product is intact and undamaged.
  • Page 2: Table Of Contents

    1560 ± 50 RPM The emissions control system for this Engine is warranted for standards set by the U.S. Environmental Protection Agency. For warranty information, refer to the last pages of this manual. Page 2 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 3: Safety

    Risk of Fire. Read the manual before Do not refuel while operating. set-up and/or use. Keep flammable objects away from engine. WARNING marking concerning Risk of Hearing Loss. Wear hearing protection. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 3...
  • Page 4 (e) Replace all fuel tank and container caps securely. lines, and landscape fabric. Remove all large sticks, stones, wires, or other foreign objects. Page 4 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 5: Operation

    21. Never pick up or carry a machine such as in the presence of flammable while the engine is running. liquids, gases, or dust. Gasoline-powered engines may ignite the dust or fumes. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 5...
  • Page 6 California to cause cancer and birth defects or other reproductive harm. (California Health & Safety Code § 25249.5, et seq.) Page 6 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 7: Maintenance And Storage

    It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. SAVE THESE INSTRUCTIONS. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 7...
  • Page 8: Setup

    Attach the Handlebar Assembly to the Handlebar Frame (49) using four Hex Head Flange Bolts (72), Flat Washers (66), Spring Washers (67), and Nuts (62). Refer to Figure A. Handlebar Assembly Flat Washer, Spring Washer & Nut Flange Bolt Handlebar Frame Figure A Page 8 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 9 Components and Controls Throttle Engine Forward Clutch Control Switch Lever Reverse Muffler Clutch Lever Fuel Cap Oil Cap/ Dipstick Filter Drag Starter Handle Choke Oil Drain Fuel plug Valve Tines ITEM 62548 For technical questions, please call 1-888-866-5797. Page 9...
  • Page 10 6. Thread the dipstick back in clockwise. NOTICE: Do not run the engine with too little oil. The engine will shut off if too little engine oil is used. Page 10 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 11 10% ethanol (E10). Do not use E85 ethanol. Add fuel To prevent FIRE, do not start the engine stabilizer to the gasoline or the Warranty is VOID. while the smell of fuel hangs in the air. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 11...
  • Page 12: Engine Oil

    4. Turn the Engine Switch on. Note: If engine does not start, check engine oil. Engine will not start with low or no engine oil. Page 12 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 13: Engine Oil

    The maintenance break-in period will last about 20 hours of use. • Change the engine oil after this period. Under normal operating conditions subsequent maintenance follows the schedule explained in the MAINTENANCE section. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 13...
  • Page 14: Spark Plug

    Tiller. 3. Start the Engine following instructions If any damage is found have the problem corrected in Manual Start on page 12. before further use. Page 14 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 15: Spark Plug

    Tine Blades and Shaft, then cover the equipment and store in a dry, level, well-ventilated area out of reach of children. NOTICE See Long-Term Storage on page 21 for complete storage instructions. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 15...
  • Page 16: Maintenance

    Many maintenance procedures, including any not detailed in this manual, will need to be performed by a qualified technician for safety. If you have any doubts about your ability to safely service the equipment or engine, have a qualified technician service the equipment instead. Page 16 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 17 4. Clean carbon build-up from combustion chamber Replace fuel line if necessary Service more frequently when used in dusty areas. These items should be serviced by a qualified technician. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 17...
  • Page 18 Average outdoor temperature 8. Thread the dipstick back in clockwise. NOTICE: Do not run the engine with too little oil. The engine will shut off if too little engine oil is used. Page 18 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 19 6. Apply dielectric spark plug boot protector (not included) to the end of the spark plug 5. Tighten the cable clamp screw. and reattach the wire securely. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 19...
  • Page 20 Tighten the Cable Clip. Springs f. Recheck belt tension, including OFF position tension. Replace Belt Cover when finished. Belt Replacement Only a qualified technician should replace the Forward and/or Reverse Clutch Belt. Page 20 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 21 Clean out area around spark plug. refer to Starting the Engine on page 12. Remove spark plug and pour one tablespoon of engine oil into cylinder through spark plug hole. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 21...
  • Page 22: Troubleshooting

    Check engine oil before EVERY use. 2. Engine mounted on a slope, 2. Bring engine level. Check engine oil. triggering low oil shutdown. Follow all safety precautions whenever diagnosing or servicing the equipment or engine. Page 22 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 23 Clutch Cable. 3. Protective output shaft key has 3. Have qualified technician install sheared off. new output shaft key. Follow all safety precautions whenever diagnosing or servicing the equipment or engine. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 23...
  • Page 24: Parts List And Diagram

    Reverse Gear Tension Pulley Spring Forward Clutch Cable Forward Clutch Belt 13 x 1050LW Reverse Clutch Cable Belt Cover Throttle Cable Handlebar Cover Lock Nut M8 Handle Grip Ø25 Large Washer Ø8 Page 24 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 25: Assembly Diagram

    Assembly Diagram ITEM 62548 For technical questions, please call 1-888-866-5797. Page 25...
  • Page 26 Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 26 For technical questions, please call 1-888-866-5797. ITEM 62548...
  • Page 27: Warranties

    HFT. For emissions warranty service, contact the HFT Customer Service Department at 1-888-866-5797 or productsupport@harborfreight.com. ITEM 62548 For technical questions, please call 1-888-866-5797. Page 27...
  • Page 28 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
