Installation Instructions Evacuated Tube Solar Water Heaters GreenGlo water heaters are AS/NZ 2712:2007 certified. They are known for their exceptional performance and longevity. Please read the following instructions carefully to ensure their correct installation for optimum results. If you have any questions please call us on 0800 447 336 This document was printed as per March 2013 requirements and may not be the latest document.
GreenGlo Evacuated tube solar system – installation manual This assembly manual covers assembly of the frame (if needed), roof mounting of the 20 and 30 tube evacuated solar tube collectors and installation to the cylinder. Contents Page Section 1 Specifications and cautions...
Section 1: Specifications and cautions Dimensions of the solar collectors: GG20T (20 tube) and GG30T (30 tube). Solar Group Limited – 0800 447 336 | Page 3...
Specifications Model GG20T GG30T Number of Tubes 2050×1400×153 2050×2100×153 Dimensions L ×W×H ( ) Effectual Absorb Area 1.62m 2.42m 63kgs 94kgs Weight E mpty ( ) Manifold’s Capacity 1.15L 1.7L Connections G3/4" male thread G3/4"male thread Components 1. Heat Pipe...
Page 5
When heating a swimming pool or spa, a heat exchanger should be used between the pool and the collector. 1.10 GreenGlo manifolds are designed to operate at a maximum pressure of 6 Bar (90psi). It’s strongly recommended to use a suitable pressure relief valve.
Page 6
Mains pressure, open loop solar system with electricity – Full system Solar Group Limited – 0800 447 336 | Page 6...
Section 2: General guidelines for roof-mounting of the solar collectors The ideal location for the Solar Collectors is on a roof facing the mid-day / early afternoon sun. (North / NNW in New Zealand). The panel angle to the sun should be approximately the same as the geographical latitude (e.g.
Collector assembly Before beginning, make sure you have all the pieces required; 2-3 boxes of 10 evacuated tubes (depending if it is a GG20T or GG30T). • 1 box containing the manifold, bottom track, end cups, stainless steel clips and a small brass fitting.
Finalising position 1. To finalise the position of the Manifold, and tighten the fixings, the two end evacuated tubes must be fitted. An incorrect spacing between the manifold and the bottom rail will mean that the tube end caps will not click securely into place.
Page 10
Section 4: Pitched frame assembly The GG20T and GG30T collectors can be elevated to the required angle on both flat and pitched roofs using the specialised frame pieces supplied. Adjustable angle range: 22 Making up the frame The cross braces (6) and angled bracing section (3) should be cut to the desired length.
Page 11
Section 5: Roof fixings Note: These fixings are for parallel to roof installs only. For roof stands see previous page. Solar Group Limited – 0800 447 336 | Page 11...
Page 12
Section 5: Roof Support Purlin strengthening not needed for flush collectors unless needed according to details sheet S3 & S4 (pages 11 & 12). NOTE: Locate solar collectors away from high wind pressure areas in accordance with NZBC G12/AS2 cl. 4.1 and figure 2. Rafter spacing Use the table below as a guide to determine if the existing rafters are able to span the distance required with the additional loading from the solar collector unit.
Section 7: Plumbing For a new install—please follow 1. NZS3606 installation guide, ensure there is room for thermostat and that relief valves have sufficient room for maintenance and potential removal. For a retrofit—turn off and unplug / disconnect cylinder. Drain cylinder. Add riser to return end of 5-way valve (retrofit) 1/3 up the tank.
Section 8: Electrical Use controller manual supplied for detailed instructions; also refer to plumbing & electrical schematic on pages 2&3 of this guide. Mount controller (and relay for retrofits). Attach probes S3 at top and S2 at bottom of cylinder(s) (top connect behind insulation ½...
Page 15
Installation of the tubes and end-caps To fit the tubes, the heat pipe must be pulled out from the tube as shown. Coat the end of the heat pipe with the thermal conduction glue Then insert the end of the heat pipe firmly and completely into the manifold.
Page 16
Section 10: Common Issues 1. No hot water: Check element is switched on at the wall. Check if power company turned the ripple power off Check that the fuse in the thermostat has not popped – may need to replace with auto-reset thermostat, reduce SMX by 5˚C. Check the timing for the element is on for long enough –...
Page 17
The system is made of copper so pool levels of chlorine are not acceptable for use. For levels of high lime content please check the element in cylinder is incalloy otherwise GreenGlo panels are capable of handling poor water quality.
Page 18
Section 12: Important Checklist for Installer To complete and tick before leaving site Please ask customer to be available at the end of the day/estimated completion time for commissioning and to go through the paperwork. Otherwise this can be discussed by phone or if another appointment is necessary a call out fee may be applied. Important Checks ...
