- Page 1 UPPLY PV-5127, PV-5127A UPS & B OWER SUPPLY MODULE WITH ATTERY CHARGER User Manual & Installation Guide . 1.1 DOC: M5236DM Micro Technic A-S • Denmark • Tel. +45 6615 3000 • Fax +45 6615 3077 E-mail: support@micro-technic.com Website: www.micro-technic.com...
-
Page 2: Table Of Contents
INSTALLATION GUIDE... 28 ESD... 28 RECAUTIONS TO ... 28 ETTINGS AND CONNECTIONS ST1 ... 28 Page 2 of 31 PV- 5127: Power supply module with UPS Table of contents (CN2) ... 9 S CONNECTOR 5V STB ... 22 ... 23... - Page 3 CN2 ... 28 CN3 ... 28 CN10 ... 28 KL2... 29 THERMAL CONSIDERATIONS ... 30 DIFFERENCES BETWEEN PV-5127 AND PV-5127A ... 31 PV-5127A ... 31 LOCK DIAGRAM OF THE PV- 5127: Power supply module with UPS Page 3 of 31...
-
Page 4: Revision History
Users Manual & Installation Guide Revision history Revision number Page 4 of 31 PV- 5127: Power supply module with UPS Reason for change Initial revision Error in mechanical layout changed – page 27. Date 23-Mar-04 21-Oct-05... -
Page 5: General Information
S=Stack-through PC/104 connector Available models: Model no Description PV-5127-S 75W PC/104 Power Supply Module (+5V, +12V), 18-35V input supply with UPS/Battery charger PV-5127A-S 75W PC/104 Power Supply Module (+5V, +12V), 10-35V input supply Accessories These accessories must be ordered separately if needed. -
Page 6: Description
PV- 5127: Power supply module with UPS Description The Micronix PV-5127 is a high efficiency PC/104 power supply for embedded, vehicular and automotive systems applications. It will withstand extended temperatures and the shock and vibration of mobile equipment. Micronix PV-5127 has an input supply range of 18-35V (PV- 5127A: 10-35V), which is convenient for automotive and low-voltage applications. - Page 7 Users Manual & Installation Guide PV- 5127: Power supply module with UPS The mains supply is continuously monitored. There is hysteresis on the mains monitor so that a mains failure is reported when the mains voltage drops below 16.5V, and mains is reported OK when the voltage rises above 17.5V.
-
Page 8: Connectors
The layout of this connector is printed in the silkscreen on the heatsink. Output voltage indicators Three green LEDs indicate presence of the output voltages +5V, +5V Standby, and +12V. Page 8 of 31 PV- 5127: Power supply module with UPS " - / 4 9 3 4 #... -
Page 9: Heater And Fan Control And External Leds Connector (Cn2)
Off, main DC/DC converter is off The LEDs should be connected like this: RS232 connector (CN3) This connector is documented in the UPS Control section. PV- 5127: Power supply module with UPS System GND. See note. Logical output for external heat element, 3.3V when active. -
Page 10: Atx Connector (Cn10)
The factory default is a jumper in the “10°C” position. Jumper position (ST3) No jumper installed Jumper on ‘On-board sensor’ Jumper on ‘10°C’ Page 10 of 31 PV- 5127: Power supply module with UPS Function System GND For factory use only For factory use only For factory use only... -
Page 11: Pc/104 Bus Connector (Cn1)
The ATX signals (+5V STB, PS_ON and PWR_GOOD) are not available in the PC/104 connector. The PC/104 bus is also used for software UPS status and power-off, see the UPS Control section. The software interface uses the following signals: PV- 5127: Power supply module with UPS PC/104 pin Function... -
Page 12: System Temperature
J2 instead of a sensor. To simulate too hot, leave both J2 and ST3 unconnected. The temperature ranges are used for these functions: CPU start Range allowed Heater Too cold Cool Warm Too hot Page 12 of 31 PV- 5127: Power supply module with UPS Critical alarm Cold Flashing Flashing... - Page 13 Users Manual & Installation Guide PV- 5127: Power supply module with UPS Note that the heater and fan outputs are logical outputs that become 3.3V when they are active. If necessary, the user must provide driving circuitry to drive an actual heater and fan. The positions of the two outputs in CN2 are shown here.
-
Page 14: Ups Control
4. When the CPU turns itself off while mains isn’t present, everything including +5V STB is turned off, to conserve battery power. It stays off until mains comes back. Page 14 of 31 PV- 5127: Power supply module with UPS... -
Page 15: Rs232
In the table shown inputs are indicated by (i) and outputs by (o). PV-5127 CN3 Function Battery low(o) UPS_active(i), see note Mains failure(o) Shutdown(i) Note: The UPS_active signal is currently unused by the PV-5127. PV- 5127: Power supply module with UPS "# % &' CPU RS232 DB9 RS232 Function Battery low(i) Shutdown(o) -
Page 16: Rs232 Status Signals
3" &5 < = 89" Page 16 of 31 PV- 5127: Power supply module with UPS Status Running normally on mains power. Mains alarm, running on battery. The CPU is advised to shut down if mains power doesn’t come back within reasonable time. This time should be configured in the UPS monitoring software. -
Page 17: Pc/104 Interface
Cool ss=10: Warm ss=11: Too hot m (STATUS bit 2): Mains present. m=0: Mains voltage not present, running on battery m=1: Mains voltage present PV- 5127: Power supply module with UPS Read/write Function read only SIGNATURE read only STATUS... - Page 18 RS232_STATUS bit 7: DTR (Shutdown). Input into the PV-5127. SHUTDOWN (port 254h, read/write): This port holds the current state of the Softoff state machine. Please see the section ATX and Softoff state machines. Possible values are: Page 18 of 31 PV- 5127: Power supply module with UPS...
-
Page 19: Software Compatibility
This cannot happen with the PV-5127 because it always turns off power for at least two seconds after a power-off command through RS232 or PC/104, even if mains power is present. PV- 5127: Power supply module with UPS http://www.micro- Page 19 of 31... -
Page 20: Battery Monitor And Charger
Charging a lead-acid battery while it is too hot may damage it. The PV-5127 has an input, J1, for connecting an external battery temperature sensor. The sensor, if used, should be physically Page 20 of 31 PV- 5127: Power supply module with UPS ST1 removed Fast charge current=0.5A... - Page 21 Battery error. This indicates that the battery is either empty, low, or disconnected. < 7 - * 89" > > PV- 5127: Power supply module with UPS Charger function Disabled. See note. Enabled (factory default) Enabled when not too hot 7 - *...
-
Page 22: Atx And Softoff State Machines
Users Manual & Installation Guide PV- 5127: Power supply module with UPS ATX and Softoff state machines The PV-5127 provides several ways to turn on/off power. ATX compatible CPUs can turn themselves on and off using PS_ON, and UPS monitoring software on CPUs without PS_ON can turn off using either a RS232 handshake signal or a software command through the PC/104 bus. -
Page 23: The Atx On/Off State Machine
SOFT_TEMPBAD. SOFT_ON and SOFT_DELAY are the “on” states, i.e. only in these states can the 5V+12V be turned on. SOFT_OFF and SOFT_TEMPBAD are the “off” states, where the 5V+12V is guaranteed to be off. PV- 5127: Power supply module with UPS Page 23 of 31... - Page 24 Note that the PV-5127 does not have a very accurate clock. You should expect deviations of 10% from the nominal times in SOFT_DELAY and SOFT_OFF. Page 24 of 31 PV- 5127: Power supply module with UPS ' ( 7 3 : 4 ; " ! / <...
-
Page 25: Technical Data
Software: Logic outputs (Fan_ON, Heat_ON, and PWR_GOOD): – Output high voltage: – Output high voltage: – Output low voltage: PV- 5127: Power supply module with UPS 18-35Vdc (with UPS and charger) 10-35Vdc (without UPS and charger) +5Vdc, 8A +/-100mV +/-1%... -
Page 26: Environmental Specifications
Sustained vibration: Shock: Size: (W x L x H): Page 26 of 31 PV- 5127: Power supply module with UPS -20° C to +70° C at 0.5 m/s airflow -40° C to +85° C 20 to 90% non-condensing ETS 300 019-2-5 or equal 10-1000 Hz sinus and random @ 1-1.5G RMS EN... -
Page 27: Mechanical Layout
Users Manual & Installation Guide PV- 5127: Power supply module with UPS Mechanical layout The schematic on this page shows the dimensions for PV-5127. All dimensions are in mm. Page 27 of 31... -
Page 28: Installation Guide
Users Manual & Installation Guide PV- 5127: Power supply module with UPS Installation guide Precautions to ESD Please note that the Micronix PV modules must be handled with respect to ESD (Electrostatic Discharge). Electrostatic Discharge to the PV modules must be avoided. -
Page 29: Kl2
PC/104 connector limits, see section PC/104 connector (CN1), or if you need power for devices that are not powered through the PC/104 bus. Connection number in KL3 " - PV- 5127: Power supply module with UPS Function Mains+ in Mains- in... -
Page 30: Thermal Considerations
Users Manual & Installation Guide Thermal considerations When installing the Micronix PV-5127 in a PC/104 stack, some considerations about convection must be made. For the power supply to work properly, certain temperature limits must not be exceeded. Several factors will affect the temperature raise in the PV-5127: •... -
Page 31: Differences Between Pv-5127 And Pv-5127A
• The battery charger is omitted. • The input selector circuit is omitted. • J1 for battery temperature sensor is omitted. • CN3 for “RS232” UPS communication is omitted. Block diagram of the PV-5127A PV- 5127: Power supply module with UPS Page 31 of 31...
