- Page 1 OWER UPPLY PV-1075 & PV-1075-CAR NiMH battery pack with charger for PV-5127 User Manual & Installation Guide . 1.3 DOC: M5247DM.REV1.3 Micro Technic A-S • Denmark • Tel. +45 6615 3000 • Fax +45 6615 3077 E-mail: support@micro-technic.com Website: www.micro-technic.com...
-
Page 2: Table Of Contents
Users Manual & Installation Guide TABLE OF CONTENTS ... 2 GENERAL INFORMATION... 4 ... 4 RDERING CODES ... 4 CCESSORIES DESCRIPTION ... 5 ... 5 LOCK IAGRAM CONNECTORS ... 6 (KL2)... 6 NPUT CONNECTOR (KL1) ... 6 UTPUT CONNECTOR (J1) ... 7 ATTERY CONNECTOR PC/104 (CN1) ... -
Page 3: Revision History
Users Manual & Installation Guide Revision history Revision number PV- 1075: N Reason for change Initial revision Added PV-1075-car version Changed front page Changed “discharge current” BATTERY PACK WITH CHARGER Date 05-Apr-04 06-Dec-05 07-Apr-18 07-Dec-03 Page 3 of 9... -
Page 4: General Information
Users Manual & Installation Guide General information Ordering codes PV-1075-S S=Stack-through PC/104 connector Available models: Model Ordering code PV-1075-S 016.104.005 NiMH battery pack with charger. PV-1075-S-CAR 016.104.093 NiMH battery pack with charger for mobile applications. Accessories This accessories must be ordered separately if needed. Model no Ordering code PV-1075-NH12 155.104.000... -
Page 5: Description
Users Manual & Installation Guide PV- 1075: N BATTERY PACK WITH CHARGER Description Micronix PV-1075 is a back-up module with Nickel-Metal-Hydride batteries and integrated charger. PV-1075 is designed to support the Micronix PV-5127, a high power PC/104 UPS power supply. Micronix PV-1075 is a high capacity battery pack for your PC/104 system. -
Page 6: Connectors
Users Manual & Installation Guide PV- 1075: N BATTERY PACK WITH CHARGER Connectors The PV-1075 is equipped with four connectors: Input connector (KL2) Power into PV-1075 is supplied through KL2 that is a two-pole removable screw clamp connector. The layout of this connector is shown on the connection drawing above. The voltage used must be in the interval of 18-36V DC (PV-1075-CAR: 10.8V –... -
Page 7: Battery Connector (J1)
Users Manual & Installation Guide Battery connector (J1) The NiMH battery is connected to PV-1075 using J1 that is a two-pole MOLEX connector. The battery connector is disconnected at delivery to prevent deep discharge of the battery when not used for a longer period. -
Page 8: Technical Data
Users Manual & Installation Guide Technical data Mains input: Input voltage: PV-1075 PV-1075-CAR Input current: PV-1075 PV-1075-CAR Battery charger: Charging modes: Charging time: Charge counter: Battery: Battery voltage: Battery type: Number of cells: Battery capacity: Recommended discharge current(max): Battery protection: Environmental: Temperature range by Standard charge: Temperature range by discharge:... -
Page 9: Mechanical Layout
Users Manual & Installation Guide PV- 1075: N BATTERY PACK WITH CHARGER Mechanical layout The schematic on this page shows the dimensions for PV-1075. All dimensions are in mm. Page 9 of 9...
