Congratulations on purchasing your new
Casablanca® ceiling fan! It will provide
comfort and performance in your home
or office for many years. This installation
and operation manual contains complete
instructions for installing and operating
your fan.
We are proud of our work and appreciate
the opportunity to supply you with the
best ceiling fan available anywhere in the
world.
To register your fan, please visit:
www.CasablancaFanCo.com/register
Save your receipt for proof of purchase.
What to Expect with
Your Installation
7 feet
Downrod
Blades
Light Kit
13
M8510-01 • 10/30/14 • © Casablanca Fan Company
Tools Needed
30 inches
Ladder
2
3
Wiring
6
9
Operation
14
15
1
www.CasablancaFanCo.com
Mounting Options
Ceiling Bracket
4
Canopy
Wall Control
11
Maintenance
& Cleaning
Troubleshooting
?
?
17
1.888.227.2178
5
12
?
18
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Casablanca M8510-01W
Summary of Contents for Casablanca M8510-01W
- Page 1 Downrod Wiring Canopy Wall Control world. To register your fan, please visit: www.CasablancaFanCo.com/register Save your receipt for proof of purchase. Maintenance & Cleaning Blades Light Kit Operation Troubleshooting M8510-01 • 10/30/14 • © Casablanca Fan Company...
-
Page 2: What To Expect With Your Installation
Assess ceiling angle Select a downrod length installed and used in accordance with the instructions may cause harmful interference to radio communications. M8510-01 • 10/30/14 • © Casablanca Fan Company... -
Page 3: Tools Needed
Tools Needed www.CasablancaFanCo.com 1.888.227.2178 Pliers Wire Strippers Screwdrivers Ladder Power Drill 9/64” Drill Bit (optional) (optional) If mounting to a support structure, you will also need these tools. M8510-01 • 10/30/14 • © Casablanca Fan Company... -
Page 4: Mounting Options
You need BOTH You need ONLY a Longer a Longer Downrod & Downrod an Angled Mounting Kit *most common M8510-01 • 10/30/14 • © Casablanca Fan Company... -
Page 5: Ceiling Bracket
To avoid possible electrical shock, before 1-888-227-2178. installing your fan, disconnect the power by turning off the circuit breakers to the outlet Refer to warning w.1 on pg. 2 box associated with the wall switch location. M8510-01 • 10/30/14 • © Casablanca Fan Company... - Page 6 Steps 1-5 to remove standard downrod pipe Longer Downrod for angled ceilings or ceilings 10’ or higher Shorter Downrod for fans installed close to ceiling Steps 6-10 to reassemble with new pipe M8510-01 • 10/30/14 • © Casablanca Fan Company...
- Page 7 4-5 full turns) until it stops. with pliers. DO NOT can be inserted. from the top of the downrod. HAND TIGHTEN. 8” 3/8” If the setscrew is not tightened securely, the fan may fall. M8510-01 • 10/30/14 • © Casablanca Fan Company...
- Page 8 Put the wires and downrod through the canopy. Let the canopy sit loosely on top of the fan. CANOPY OR WIRES. Place the downrod ball into the slot in the ceiling bracket. M8510-01 • 10/30/14 • © Casablanca Fan Company...
- Page 9 Spread the wires apart, with the grounded wires on one side of Refer to CAUTION c.1 on pg. 2 the outlet box and the ungrounded wires on the other side of the outlet box. M8510-01 • 10/30/14 • © Casablanca Fan Company...
- Page 10 Spread the wires apart, with the grounded wires on one side of Refer to CAUTION c.1 on pg. 2 the outlet box and the ungrounded wires on the other side of the outlet box. M8510-01 • 10/30/14 • © Casablanca Fan Company...
-
Page 11: Wall Control
(1) this device may not cause harmful interference, and (2) this device must accept the green wire coming from the wall control with an included wire nut. any interference received, including interference that may cause undesired operation. M8510-01 • 10/30/14 • © Casablanca Fan Company... - Page 12 Lift the canopy into place so that Install the two canopy screws lifted into place, the canopy fits into the screw holes are aligned. found in the hardware bag. the hanging bracket as shown. M8510-01 • 10/30/14 • © Casablanca Fan Company...
- Page 13 Insert grommets found in the hardware bag into the holes in the blades, then secure each blade to a blade iron with screws found in the hardware bag. Note: Fan style may vary. M8510-01 • 10/30/14 • © Casablanca Fan Company...
-
Page 14: Light Kit
Exceeding the wattage limit marked on the MAX wattage sticker affixed to the light socket(s) may result in fire hazard or improper operation. M8510-01 • 10/30/14 • © Casablanca Fan Company... -
Page 15: Operation
Fan Off button and the 4 button for four seconds to pair the remote. To prevent faulty operation, please disconnect power from all other ceiling fans within range while pairing. M8510-01 • 10/30/14 • © Casablanca Fan Company... - Page 16 The reverse (a) downward air flow pattern. button changes the direction that In cold weather, use (b) upward the blades turn. The power button air flow pattern. turns the fan off and on. M8510-01 • 10/30/14 • © Casablanca Fan Company...
-
Page 17: Maintenance And Cleaning
Unscrew the bulb and replace it with a bulb of the same type and wattage. Reinstall the globe. M8510-01 • 10/30/14 • © Casablanca Fan Company... -
Page 18: Troubleshooting
Centers, visit www.CasablancaFanCo.com/FAQs www.CasablancaFanCo.com or and click “How do I properly install call toll free 1-888-227-2178. multiple remote-controlled fans?” for information on how to correct this issue. M8510-01 • 10/30/14 • © Casablanca Fan Company...
