Summary of Contents for IRUS unitrak

  • Page 2: Warranty Conditions

    Dear IRUS Customer, You have made your decision for an IRUS machine. We would like to thank you for the trust you have placed in us. It is our desire that you will have just as much satisfaction with your IRUS machine as many thousands of other IRUS customers have had in the past.
  • Page 3 The operating instructions must be strictly observed, as IRUS will assume no liability for damages resulting from neglect. The intended use of IRUS machines also includes the observance of the operating and maintenance conditions prescribed by IRUS, as well as the exclusive use of original IRUS spare parts.

  • Page 4: General Description

    IRUS absolutely requires that you have your IRUS machine inspected for safety by an authorized repair shop at least once a year.

  • Page 5: Technical Details

    Technical details: Measurements: Length: 1600 mm, without attachments Width: 1150 mm (For terra tyres 23x10.50-12) Height: 1000 mm, depending on the position of the steering bar Transmission: Hydrostatic PTO shaft: Engine PTO shaft: 970 rpm (at engine speed 3300 rpm) Steering: Active steering Steering bar:...

  • Page 6: Noise Level

    The following diagrams are located on the machine : The following dia This symbol tells you that it is dangerous to operate the machine without detailed knowledge of the operating instructions. Symbol for the throttle. Symbol for the coupler Noise level: Measured at 1.8 m behind the handlebars (where the operator would be standing) with the measuring instrument directed towards the machine.
  • Page 7 Note: Upon delivery, it is important that all screws, especially those on the wheels, are tightened again. Once delivery has been made, IRUS requires the following work to be done as the initial inspection: 01. Motor check 02. Hydraulic oil level checks 03.
  • Page 8 Figure 2 1 Steering bar 2 Steering rod cover 3 Attachment quick coupler 4 Wheels 5 Battery (only with electric start) 6 Grass guard 7 Throttle 8 Fuel tank...

  • Page 9: Starting The Engine

    Figure 3 1 Engine stop lever 2 Coupler lever 3 Catch spring Adjusting the steering bar to the correct working height: Pull lever (Fig. 1/3) upward and release the steering bar. Move the steering bar to the desired height. Press lever (Fig.

  • Page 10: Stopping The Engine

    WARNING: RISK OF ACCIDENTS!!! Before the engine can be started, it needs to be checked if both the control lever (Fig. 2/7) as well as the PTO control lever (Fig. 1/5) are positioned at * 0 *. It must also be made sure that nobody is lingering in front of the machine.
  • Page 11 Figure 4 1 Oil gauge glass for the hydraulic oil level 2 Screws for fastening the axle 3 Axle Installation of PTO attachments: All PTO attachments are taken up by the quick coupler. This is done as follows: 01. Pull out latch lock (Fig. 1/4) upwards and rotate 90°. 02.

  • Page 12: Switching Off

    Driving: The IRUS UNITRAK is equipped with a variable drive system. By pushing the control lever (Fig. 2/7) upwards, the machine is set in forward motion. The further the lever is moved, the faster the machine runs. By moving the lever back, the machine slows down again. In the idling position, a catch can be felt on the lever.

  • Page 13: Transportation Of The Machine

    Steering: The IRUS UNITRAK is so designed that it always has the tendency to go straight ahead. Do not try to control the machine forcibly at the steering bar. This is not necessary because the machine has an active steering system.
  • Page 14 Figure 5 1 Grease nipples (2 x) beneath for steering 2 Oil tank ventilation 3 Hydraulic oil tank 4.Filling plug...
  • Page 15 Figure 6 1 Adjusting screw for straight running (left and right to the machine) 2 Grease nipples (3 x) for steering 3 Adjusting nut for the 0 position 4 Hydraulic oil filters...
  • Page 16 Figure 7 1 Grease nipple...

  • Page 17: Maintenance

    Maintenance: General: The IRUS UNITRAK was constructed so that it requires only a minimum of maintenance and upkeep. The duration and efficiency of the machine depends upon conscientiously observing the instructions that follow. (For the maintenance of the engine, please see the separate instructions for the engine.) All maintenance and servicing activities are only to be performed with the engine off and the spark plugs pulled.

  • Page 18: After The First 50 Hours Of Operation

    Daily: 01. Lubricate attachment quick coupling. 02. Check engine oil level (see separate manual for the engine). 03. Clean air filter, if necessary (see separate manual for the engine). 04. Check coupler play and adjust, if necessary (Figure 8). Every 20 hours or sooner, if necessary: 01.
  • Page 19 ATTENTION battery! The built-in IRUS UNITRAK battery is completely maintenance free. Should it be necessary to charge the battery, an approved gel battery charger must be used for charging. IRUS - Motor Equipment GmbH • D-72393 Burladingen-Salmen things Industrial area cottagers turf •...
