OWNER'S MANUAL
BOTTOM FREEZER
REFRIGERATOR
Please read this manual carefully before operating
your set and retain it for future reference.
MANUAL DE USUARIO
REFRIGERADOR
CON CONGELADOR INFERIOR
Lea detenidamente este manual antes de empezar
a utilizar el refrigerador y guárdelo como referencia
para el futuro.
Model Name/Nombre de Modelo *
=color number/número de color
LFXS24623*
P/No. MFL67227304
www.lg.com
www.goedekers.com

Advertisement

Table of Contents
loading

Related Manuals for LG LFXS24623 series

Summary of Contents for LG LFXS24623 series

  • Page 1 MANUAL DE USUARIO REFRIGERADOR CON CONGELADOR INFERIOR Lea detenidamente este manual antes de empezar a utilizar el refrigerador y guárdelo como referencia para el futuro. Model Name/Nombre de Modelo * =color number/número de color LFXS24623* P/No. MFL67227304 www.lg.com www.goedekers.com...

  • Page 2: Table Of Contents

    24-26 Congratulations on your purchase and Refrigerator Shelves welcome to the LG family. Crisper Humidity Control Your new LG French Door Refrigerator Door Racks combines advanced cooling technology with simple operation and high Dairy Compartment efficiency. Follow the operating and care...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS SAFETY MESSAGES This manual contains several important safety notices. Always read and obey all of the following safety messages. This is the safety alert symbol. This symbol is a warning to potential dangers that could cause death, injury or damage to you, others or the product.

  • Page 4: Requirements For Ground Connection

    115 V ~ 60 Hz, AC or 127 V ~ 60 Hz, If the power cord is damaged, it must be replaced by AC (according to the National rating). This provides our service center or qualified LG technician to avoid the best performance and prevents an overload which any risk.

  • Page 5: Parts And Features

    24-hour period to keep the ice 5 5 10 dispenser fully supplied. The in-door design creates more shelf space. CRISPERS LG’s crispers preserve humidity and help vegetables stay crisp. GLIDE‘N’SERVE (In some models). Provides storage space with a variable temperature...

  • Page 6: Parts And Features

    PARTS AND FEATURES KEY PARTS AND COMPONENTS In addition to the special features and components outlined in the Special Features section, there are several other important components that are referenced in this manual. ADJUSTABLE REFRIGERATOR SHELVING LED INTERIOR LAMPS The refrigerator compartment shelves are Refrigerator interior is lit by the LED array.

  • Page 7: Refrigerator Installation

    REFRIGERATOR INSTALLATION 3. Install the refrigerator in an area between 55 °F WARNING (13 °C) and 110 °F (43 °C). If the surrounding temperature is lower or higher than previously mentioned, it can EXCESSIVE WEIGHT HAZARD adversely affect the unit. Use the assistance of two or more persons to move or install the refrigerator.
  • Page 8 REFRIGERATOR INSTALLATION TOOLS YOU MAY NEED 1 / 4 in (6 mm) 1 / 4 in (6 mm) 3 / 8 in (10 mm) 3 / 32 in (2,5 mm) Hex Socket Wrench Phillips Screwdriver Flat Head Screwdriver Allen Wrench NOTE: It is always recommended that the doors be removed when it is necessary to move the refrigerator through a narrow opening.

  • Page 9: Refrigerator Doors

    REFRIGERATOR INSTALLATION REFRIGERATOR INSTALLATION HOW TO REMOVE AND INSTALL REFRIGERATOR DOOR 1. Removing Refrigerator Doors Remove the left-side door first. NOTE: Handle, top hinge and hinge cover appearance may vary from illustrations on this page. WARNING Disconnect electrical supply to the refrigerator before installing. Failure to do so could result in death or serious injury.

  • Page 10: How To Remove And Install Handle

    REFRIGERATOR INSTALLATION HOW TO REMOVE AND INSTALL REFRIGERATOR DOOR (CONT.) 2. Refrigerator Door Reinstallation Install the right-side door first. Left Door Righ t Door Lower the door onto the middle hinge pin (7). Lower the door onto the middle hinge pin (1). Make sure the door is aligned with the cabinet.
  • Page 11 REFRIGERATOR INSTALLATION Insert the water supply tube into the connector. Insert the tube at least 5/8 in. (15 mm) into the connector. Hook the tab on the door-switch side of the cover under the edge of the wire opening in the cabinet top.

  • Page 12: How To Remove And Install Pull-Out Drawer

    REFRIGERATOR INSTALLATION Remove the screws of the rail on both sides. HOW TO REMOVE AND INSTALL THE PULL (Fig. 4) OUT DRAWER 1. Removing Pull out Drawer Fig. 4 IMPORTANT: To avoid possible injury, product or property damage, you will need two persons to perform the following instructions.
  • Page 13 REFRIGERATOR INSTALLATION Hook door supports into rail tabs. (Fig. 10) Push the rails back into drawer cavity. With both hands, hold the center of the bar and push it in Fig. 10 so that both rails go back simultaneously. (Fig.7) Door Supports (Fig.

  • Page 14: Closing And Aligning The Doors

    REFRIGERATOR INSTALLATION CLOSING AND ALIGNING THE DOORS Aligning the Doors To adjust the height of the doors, use the wrench (Included with the User Manual) to adjust the bolt in Closing the Doors the door hinge (counter clockwise to raise or clockwise Your refrigerator has two front leveling screws, one on the right and one on the left.

  • Page 15: Using Your Refrigerator

    USING YOUR REFRIGERATOR CONTROL PANEL FEATURES NOTE: The shape of the buttons may not match your model. LED DISPLAY The LED display shows the temperature settings, dispenser options, water filter, door alarm, and locking status messages. ICE TYPE / ICE PLUS The ICE TYPE / ICE PLUS button is used to select Cubed Ice or Crushed Ice.

  • Page 16: The Led Display

    USING YOUR REFRIGERATOR THE LED DISPLAY The LED display shows the temperature settings, dispenser options, water filter, door alarm, and locking status messages. DISPENSER SELECTION INDICATOR Shows Cubed ice or Crushed Ice selection that will be dispensed when the push switch is pressed.

  • Page 17: Adjusting The Temperatures And Display

    USING YOUR REFRIGERATOR ADJUSTING THE TEMPERATURES AND POWER SAVING MODE (in some models) The display will remain off until the next time the door DISPLAY is opened. The display will also turn on when any button is Adjust Freezer Temperature pressed, and it will remain on for 20 seconds after To adjust the temperature in the freezer compartment, the last door opening or button selection.

  • Page 18: Operating The Dispenser

    USING YOUR REFRIGERATOR OPERATING THE DISPENSER DISPENSING WATER DISPENSING CRUSHED ICE Press the ICE TYPE / ICE Press the push WATER switch with a glass PLUS button to illuminate or other container and chilled water will the Crushed Ice icon. be dispensed.

  • Page 19: Setting The Functions

    USING YOUR REFRIGERATOR SETTING THE FUNCTIONS ACTIVATING ICE PLUS SETTING THE DISPENSER LOCK Press by 3 seconds the Press hold ICE TYPE / ICE PLUS DOOR ALARM / LOCK button once to activate button for three seconds the ICE PLUS function. to lock the dispenser The ICE PLUS icon on and all of the other...

  • Page 20: Spaceplus Ice System

    USING YOUR REFRIGERATOR SPACEPLUS ICE SYSTEM CAUTION Keep hands and tools out of the ice compartment NOTE: If the On/Off switch on the icemaker is set to door and dispenser chute. You could break some- Off for an extended time, the ice compartment will thing or injure yourself.

  • Page 21: Automatic Icemaker

    USING YOUR REFRIGERATOR AUTOMATIC ICEMAKER WARNING Ice is made in the automatic icemaker and sent to the Personal Injury Hazard dispenser. The automatic icemaker can make 10 or 12 DO NOT place fingers or hands on the automatic ice cubes (depending on your device) at a time, above icemaking mechanism while the refrigerator is 100 cubes per 24-hour period.

  • Page 22: Adjusting Control Settings

    USING YOUR REFRIGERATOR FOOD STORAGE GUIDE ADJUSTING CONTROL SETTINGS Give the refrigerator time to cool down completely before adding food. It is best to wait 24 hours before ITEMS HOW TO STORE adding food to the refrigerator. Storing Fresh Food Wrap or store food in the The mid-settings indicated in the previous section refrigerator airtight...

  • Page 23: Refrigerator Section

    USING YOUR REFRIGERATOR Packaging Recommendations: REFRIGERATOR SECTION Use sealed plastic containers. Use plastic containers with a smooth surface. REFRIGERATOR SHELVES Package with aluminum foil of high resistance. The shelving of your refrigerator can be adjusted to Wrap with paper layered with plastic. comply with your storage necessities;...

  • Page 24: Crisper Humidity Control

    USING YOUR REFRIGERATOR Sliding Shelves (in some models) You can slide some of the shelves in your refrigerator towards inside or outside like explained below. To slide the shelf towards the outside: Pull towards you, figure A. To slide the shelf towards the inside: Push until it stops, figure B.

  • Page 25: Door Racks

    USING YOUR REFRIGERATOR Glide‘N’Serve (In some models). WARNING: Somebody can be hurt if door racks are not firmly assembled. The Glide‘N’Serve provides storage space with a variable temperature control that keeps the compart- CAUTION : DO NOT allow children to play with ment colder than refrigerator.

  • Page 26: Freezer Section

    USING YOUR REFRIGERATOR FREEZER SECTION WARNING: In order to prevent accidents, such as suffocation, DO NOT let children and ICE BIN (In some models) pets play inside the durabase. To remove Ice Bin: WARNING: There is enough space for the children Pull the drawer as much as possible (1).

  • Page 27: Refrigerator Care And Cleaning

    REFRIGERATOR CARE AND CLEANING BACK COVER WARNING WARNING EXPLOSION HAZARD ELECTRICAL SHOCK HAZARD Before you begin, either unplug the refrigerator or turn off power at the circuit breaker or fuse box. NOTE: Back Cover should only Do not use flammable cleaners. Not following these removed qualified instructions can cause death, explosion or fire.

  • Page 28: Power Interruptions

    REFRIGERATOR CARE AND CLEANING POWER INTERRUPTIONS WHEN MOVING In case of a black out, call your electric company If you decide to take your refrigerator with you when and ask how long it will last. moving, consider the following: In case of a 24 hour or less black out, do not open the refrigerator;...

  • Page 29: Water Filter

    REFRIGERATOR CARE AND CLEANING REPLACING THE WATER FILTER It is recommended that you replace the filter approximately every 6 months, when the water filter indicator reaches 0 months, or when the ice and water dispenser noticeably decreases out-put. Remove the old cartridge. 3.
  • Page 30 REFRIGERATOR CARE AND CLEANING REPLACING THE WATER FILTER Replace with a new cartridge. NOTE: After replacing the filter, flush 2.5 gallons through filter before use (flush for approximately 5 minutes). Check the filter for leaks. When the water filter indicator displays the message 0 Filter Month, hold 3 seconds.

  • Page 31: Performance Data Sheet

    REFRIGERATOR CARE AND CLEANING Performance Data Sheet Model: LG ADQ36006101-S Use Replacement Cartridge: ADQ36006101 The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system as specified in NSF/ANSI Standard 42 and Standard 53.
  • Page 32 1-888-LGCANADA (24 hours per day/7 days kPa). If your water pressure exceeds 80 psi, you must per week or visit our website at www.lg.com). install a pressure limiting valve. Contact a plumbing professional if you are uncertain how to check your 3M is a trademark of 3M Company.

  • Page 33: Certificate For California

    WATER FILTER State of California Department of Public Health Water Treatment Device Certificate Number Date Issued: December 15, 2009 Trademark/Model Designation Replacement Elements ADQ36006101-S ADQ36006101 Manufacturer: Cuno Inc. The water treatment device(s) listed on this certificate have met the testing requirements pursuant to Section 116830 of the Health and Safety Code for the following health related contaminants: Microbiological Contaminants and Turbidity Inorganic/Radiological Contaminants...

  • Page 34: Connecting The Water Line

    CONNECTING THE WATER LINE BEFORE START To determine how much pipe material is needed, measures the distances between the valves located behind the refrigerator and the source of water and add The water source is not guaranteed by the refrigerator to that 8 feet (2,4 m).
  • Page 35 CONNECTING THE WATER LINE 3. DRILL A HOLE FOR THE VALVE 7. CONNECT PIPELINE TO VALVE Drill a 1/4” (6,35 mm) diameter Place the compression nut and the copper pipe ferule at hole water pipeline. the end of the pipe and connect to the valve. Make sure Remove jagged edges produces the pipe is completely inserted into the valve.
  • Page 36 CONNECTING THE WATER LINE Remove the ring plug (1) from the valve located at the 11. CONNECT TO REFRIGERATOR top of such device. Fix pipeline in a way that it does not vibrate on the refrigerator wall. Push refrigerator against wall. 12.

  • Page 37: Troubleshooting Guide

    TROUBLESHOOTING GUIDE UNDERSTANDING SOUNDS YOU MAY HEAR Your new refrigerator might produce certain noises that your previous refrigerator did not. It is normal if you worry. Most of the new sounds you will be hearing are actually normal and expected. Hard surfaces like walls or floor can increase sounds and make them sound louder than they really are.
  • Page 38 TROUBLESHOOTING GUIDE Problem Possible Causes Solutions STRANGE SOUNDS The refrigerator is not correctly You need to adjust the leveling screws due the OR SNOOZING/ positioned. floor is unleveled or weak. Read the Installation VIBRATIONS section. The replaced refrigerator was an Modern refrigerators with a bigger storage older model.

  • Page 39: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Problem Possible Causes Solutions The refrigerator is in defrosting The water will evaporate. It is normal that some THERE´S WATER IN cycle. water falls on the bin. THE DRAINING BIN It’s more humid than usual. It might take a while for the water to evaporate. This is normal when the weather is hot and humid.

  • Page 40: Smart Diagnosis

    Using Smart Diagnosis First, call 1-800-243-0000 (1-888-542-2623 for LG Canada). Only use the Smart Diagnosis feature when instructed to do so by the LG call center agent. 1. Lock the display. To lock the display, press and hold the Door / Alarm Lock button for three seconds.

  • Page 41: Warranty

    Should your LG Refrigerator (“Product”) fail due to a defect in materials or workmanship under normal home use, during the warranty period set forth below, LG will at its option repair or replace the product. This limited warranty is valid only to the original retail purchaser of the product and applies only when purchased and used within the United States including U.S.
  • Page 42 WARRANTY: Should your LG Refrigerator (“Product”) fail due to a defect in material or workmanship under normal home use during the warranty period set forth below, LG Canada will at its option repair or replace the Product upon receipt of proof of original retail purchase.
