overam Mirage 5652 User Manual

Table of Contents

Quick Links

V15.1.00

Table of Contents

Summary of Contents for overam Mirage 5652

Page 1 V15.1.00...
Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Erp Off Mode Power Consumption Statement
Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5 Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.
Page 6: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 7: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 8: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 9: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 10 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 11: Servicing
Preface Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and may expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions: •...
Page 12: Power Safety
Preface Power Safety The computer has specific power requirements:  • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety Warning steady, uninterrupted power supply.
Page 13: Polymer Battery Precautions
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Page 14: General Battery Precautions
Preface General Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 15: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Cleaning Instructions (For Computer Models Supplied with Light Blue Cleaning Cloth) Some computer models in this series come supplied with a light blue cleaning cloth.
Page 16: Travel Considerations
Preface Travel Considerations As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 17 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 18 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 19: Lcd Screen Care
Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 20 Preface XVIII...
Page 21: Table Of Contents
Preface Contents Notice ................................I ErP Off Mode Power Consumption Statement: ................... II FCC Statement ............................IV FCC RF Radiation Exposure Statement: ..................... V Instructions for Care and Operation ......................VII Servicing ..............................IX Power Safety ..............................X Polymer Battery Precautions ........................XI General Battery Precautions ........................XII Cleaning ..............................
Page 22 Preface Model Differences .............................1-6 System Map: LCD Panel Open - Model A ....................1-7 System Map: LCD Panel Open - Model B ....................1-8 LED Indicators ............................1-9 Keyboard - Model A ..........................1-10 Keyboard - Model B ..........................1-11 Keyboard Shortcuts ..........................1-12 Keyboard Application Settings ........................1-13 Function/Hot Key Indicators ........................1-14 Control Center ............................1-15 Flexikey®...
Page 23 Preface Settings ..............................1-30 Windows 10 Taskbar ..........................1-31 Video Features ............................1-32 Microsoft Hybrid Graphics ........................1-32 Power Options ............................1-38 Features & Components Overview ..............................2-1 Hard Disk Drive/Solid State Drive ......................2-2 Optical (CD/DVD) Device ........................2-3 Loading Discs ............................2-3 Handling CDs or DVDs ..........................2-4 DVD Regional Codes ..........................2-5 Multi-In-1 Card Reader ..........................2-6 Touchpad/Clickpad and Buttons/Mouse ....................2-7...
Page 24 Preface Battery ................................3-2 Turning On the Computer ..........................3-3 Shutting the Computer Down ........................3-4 Power Plans ...............................3-5 Power-Saving States ..........................3-7 Sleep ................................3-7 Hibernate ..............................3-8 Shut down ..............................3-8 Configuring the Power Buttons .........................3-9 Resuming Operation ..........................3-11 Power Conservation Modes ........................3-12 Settings Menu Power Controls ........................3-14 Battery Information ..........................3-17 Battery Power ............................3-17 Conserving Battery Power ........................3-18...
Page 25 Preface Drivers & Utilities What to Install ............................4-1 Module Driver Installation ........................4-1 Driver Installation ............................4-2 Updating/Reinstalling Individual Drivers ....................4-5 User Account Control ..........................4-6 Windows Security Message ........................4-6 New Hardware Found ..........................4-6 Driver Installation Procedure ........................4-7 Chipset ...............................4-7 Video (VGA) .............................4-7 NVIDIA Video (VGA) ..........................4-7 LAN ................................4-7 Card Reader ...............................4-7...
Page 26 Preface BIOS Utilities Overview ..............................5-1 The Setup Utility ............................5-2 Failing the POST ............................5-3 Fatal Errors ..............................5-3 Non-Fatal Errors ............................5-3 Setup Screens .............................5-4 Main Menu ..............................5-5 System Time & Date (Main Menu) ......................5-5 SATA Port # (Main Menu) ........................5-6 OffBoard SATA/NVme Controller Configuration (Main Menu) .............5-6 CPU/ ME FW Version / System/ Extended Memory: (Main Menu) ............5-6 MB Series / BIOS Revision / KBC/EC firmware Revision / MAC Address: (Main Menu) .....5-6 Advanced Menu ............................5-7...
Page 27 Preface Set Supervisor Password (Security Menu) ....................5-10 Set User Password (Security Menu) ......................5-11 Password on boot: (Security Menu) ......................5-11 Secure Boot Control (Security Menu) .....................5-12 TPM Configuration (Security Menu) ......................5-13 Boot Menu ...............................5-14 Boot Option Priorities (Boot Menu) ......................5-15 UEFI Boot (Boot Menu) ..........................5-15 Exit Menu ..............................5-16 Modules &...
Page 28 Preface IRST Driver Installation ..........................6-12 Sound Blaster Cinema 2 ..........................6-13 Sound Blaster Cinema 2 Installation .......................6-13 Sound Blaster Cinema 2 Application ......................6-14 Sound Blaster Cinema 2 SBX Pro Studio ....................6-18 PC Camera Module ..........................6-23 Camera App .............................6-24 Taking Pictures/Capturing Video ......................6-26 Trusted Platform Module .........................6-28 Enabling &...
Page 29 Preface Interface (Ports & Jacks) Overview ..............................A-1 Notebook Ports and Jacks .........................A-2 Control Center & Flexikey® Overview ..............................B-1 Flexikey® Application ..........................B-8 Profiles ..................................B-8 Flexikey® Application Features .......................B-9 Keyboard and Mouse Settings ........................B-9 Enabling or Disabling Flexikey® ......................B-10 Keyboard Settings ...........................B-11 Mouse Settings ............................B-12 Keyboard Settings - Express Key ......................B-13 Keyboard Settings - Launch App ......................B-17...
Page 30 Preface Video Driver Controls Video Drivers ............................C-1 Video (VGA) ............................C-1 NVIDIA Video (VGA) ..........................C-1 Dynamic Video Memory Technology ......................C-2 Microsoft Hybrid Graphics ........................C-3 Intel® HD Graphics Control Panel ......................C-5 Display Devices & Options ........................C-19 Attaching Other Displays ........................C-20 Configure Other Displays Using Project ....................C-22 You can configure attached displays from Project.
Page 31 Preface Specifications Processors ..............................D-2 Core Logic ..............................D-2 Display ..............................D-2 Memory ..............................D-2 Video Adapter ............................D-2 Storage ..............................D-2 Audio ................................D-3 Keyboard & Pointing Device ........................D-3 Interface ..............................D-3 Card Reader ..............................D-3 Slots ................................D-3 Communication ............................D-3 Battery ...............................D-4 Power ................................D-4 Power Management ..........................D-4 Indicators ..............................D-4 BIOS .................................D-4 Security ..............................D-4 Features ..............................D-4...
Page 32 Preface Dimensions & Weight ..........................D-5...
Page 33: Quick Start Guide Overview
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 34: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1 “BIOS Utilities” on page 5 - 1 in the reminder of the User’s Manual.
Page 35: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows 10) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Page 36: System Startup
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 37: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 10 (64-bit) operating system is supported.
Page 38: Model Differences
Quick Start Guide Model Differences This notebook series includes two different model types (and two design styles for each model) that mainly differ as indicated in the table below. Note that your model may appear slightly different from those pictured in this manual (also see Appendix D for details of supported processors etc.).
Page 39: System Map: Lcd Panel Open - Model A
Quick Start Guide System Map: LCD Panel Open - Model A Figure 1 - 2 LCD Panel Open -  Model A Wireless Device Built-in PC Camera Operation Aboard PC Camera LED Aircraft Built-In Microphone The use of any portable Power Button electronic transmission de- LED Indicators...
Page 40: System Map: Lcd Panel Open - Model B
Quick Start Guide System Map: LCD Panel Open - Model B Figure 1 - 3 LCD Panel Open - Model B  Built-in PC Camera Wireless Device PC Camera LED Operation Aboard Built-In Microphone Aircraft The use of any portable Power Button electronic transmission de- LED Status...
Page 41: Led Indicators
Quick Start Guide LED Indicators Icon Color Description The LED indicators on the computer display helpful information about the current status of the computer. Green Number Lock Activated Icon Color Description Scroll Lock Activated (to activate Green press Fn & Scr Lk) Orange DC Power is Plugged In Green...
Page 42: Keyboard - Model A
Quick Start Guide Keyboard - Model A  The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards function keys to change operational features instantly. If your keyboard is dam- Function Keys aged or you just want to make a change, you can use any standard USB keyboard.
Page 43: Keyboard - Model B
Quick Start Guide Keyboard - Model B  The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards function keys to change operational features instantly. If your keyboard is dam- Function Keys aged or you just want to make a change, you can use any standard USB keyboard.
Page 44: Keyboard Shortcuts
Quick Start Guide Keyboard Shortcuts  The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navi- gation/operation in Windows 10. Windows Logo Keyboard Shortcut Windows Logo Description Use the Windows logo Key + + D key com- bination to switch be- Tap Winkey Toggle the Start menu tween the Start screen...
Page 45: Keyboard Application Settings
Quick Start Guide Keyboard Application Settings (Model B Factory Option) If your Model B computer includes an illuminated keyboard, you will need to install the keyboard Control Cen- ter application driver (see “Control Center” on page 4 - 8) and you can then select the type of keyboard as ap- propriate for your model’s configuration (you can only select keyboards supported by your system).
Page 46: Function/Hot Key Indicators
Quick Start Guide Function/Hot Key Indicators Keys Function Keys Function Play/Pause (in Audio/Video Programs) Fn + PC Camera Power Toggle Fn + Fn + Fn + TouchPad Toggle Airplane Mode Toggle Turn LCD Backlight Off Fn + Sleep Toggle Fn + (Press a key to or use TouchPad to turn on) Fn + Mute Toggle...
Page 47: Control Center
Quick Start Guide Control Center When in the Windows Desktop application (not in the Start screen) press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Con- trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/Touch Pad on/off (see Appendix B...
Page 48: Flexikey® Application
Quick Start Guide Flexikey® Application The Flexikey® application is a quick hotkey configuration application, which allows you to assign a single key to launch multiple key combinations, or to launch programs and applications, to create text macros and to disable certain keys. The application can also be used to configure the mouse buttons to create hotkeys for gaming etc.
Page 49: Flexikey® Application Features
Quick Start Guide Flexikey® Application Features: For full details see “Flexikey® Application” on page B - • EXPRESS KEY - This feature allows you to configure a single key (or mouse click) to send multiple key combinations, or to create more useful shortcut keys This is useful in gaming or when using applications which have a complex set of keyboard shortcuts.
Page 50: System Map: Front & Left Views - Model A
Quick Start Guide System Map: Front & Left Views - Model A Figure 1 - 9 Front & Left Views Model A LED Power Indicators Multi-in-1 Card Reader DC-In Jack Vent/Fan Intake/ Outlet  External Monitor Port Multi-In-1 Card Reader RJ-45 LAN Jack USB 3.0 Port The card reader allows you to use the most popular digital storage card formats:...
Page 51: System Map: Front & Left Views - Model B
Quick Start Guide System Map: Front & Left Views - Model B Figure 1 - 10 Front & Left Views Model B LED Power Indicators Multi-in-1 Card Reader DC-In Jack Vent/Fan Intake/ Outlet  External Monitor Port Multi-In-1 Card Reader RJ-45 LAN Jack The card reader allows you to use the most popular digital storage card formats: USB 3.0 Port...
Page 52: System Map: Right & Rear Views - Model A
Quick Start Guide System Map: Right & Rear Views - Model A Figure 1 - 11 Right & Rear Views Model A 1. Microphone-In Jack 2. Headphone-Out Jack 3. USB 2.0 Port 4. USB 3.0 Port 5. Optical Device  Drive Bay (for CD/ DVD Device) Battery Information...
Page 53: System Map: Right & Rear Views - Model B
Quick Start Guide System Map: Right & Rear Views - Model B Figure 1 - 12 Right & Rear Views Model B 1. Microphone-In Jack 2. Headphone-Out Jack 3. USB 2.0 Port 4. USB 3.0 Port 5. Optical Device  Drive Bay (for DVD Device) Battery Information...
Page 54 Quick Start Guide   Changing DVD Regional Codes Disk Eject Warning Go to the Control Panel and double-click Device Don’t try to eject a CD/DVD while the system is ac- Manager (Hardware and Sound), then click the + cessing it. This may cause the system to “crash”. Stop next to DVD/CD-ROM drives.
Page 55: System Map: Bottom View - Model A
Quick Start Guide System Map: Bottom View - Model A Figure 1 - 13 Bottom View Model A Battery Component Bay Cover Vent/Fan Intake/ Outlet Multi-in-1 Card Reader Speakers   Overheating The CPU is not a user To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake serviceable part.
Page 56: System Map: Bottom View - Model B
Quick Start Guide System Map: Bottom View - Model B Figure 1 - 14 Bottom View Model B Battery Component Bay Cover Vent/Fan Intake/ Outlet Speakers   Overheating The CPU is not a user To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake serviceable part.
Page 57: Windows 10 Start Menu
Quick Start Guide Windows 10 Start Menu Most of the apps, control panels, utilities and programs within Windows 10 can be accessed from the Start Menu by clicking the icon in the taskbar in the lower left corner of the screen (or by pressing the Windows Logo Key on the keyboard).
Page 58: Right-Clicking The Windows Logo In Start Menu
Quick Start Guide Right-Clicking the Windows Logo In Start Menu Right-click the Start Menu icon (or use the Windows Logo Key + X key combination) to bring up an advanced Context Menu of useful features such as Control Panel, Programs and Features, Power Options, Task Manager, Search, File Explorer, Command Prompt, Device Manager and Network Connections etc.
Page 59: Start Menu Apps & Tiles
Quick Start Guide Start Menu Apps & Tiles The Windows 10 Start Menu will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on the screen so may need click and drag the handles at the edge of the screen to expand the menu in order to view all the apps (you can use the scroll bar to move up and down the screen).
Page 60 Quick Start Guide Pining/Unpinning Apps & Programs to/from the Start Menu To make things easy to find you can add and remove tiles for apps and programs to the Start Menu. Right-Click on a program’s icon and select Pin to Start from the drop-down menu. To remove an app or program from the Start Menu right-click the icon and select Unpin from Start.
Page 61: Windows 10 Control Panel
Quick Start Guide Windows 10 Control Panel In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel can be accessed in a number of ways in Windows 10. • Right-click the Start Menu icon in the taskbar in the lower left corner of the screen and select Control Panel from the menu.
Page 62: Settings
Quick Start Guide Settings The Settings item in the Start Menu (and also as an App) gives you quick access to a number of system settings control panels allowing you to adjust settings for System, Devices, Network & internet, Personalization, Ac- counts, Time &...
Page 63: Windows 10 Taskbar
Quick Start Guide Windows 10 Taskbar In many instances throughout this manual you will see an instruction to access the notification area of the task- bar. The notification area of the taskbar in the bottom right of the screen. Some of the Control Panels and appli- cations referred to throughout the course of this manual can be accessed from here.
Page 64: Video Features
Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearance and Personalization). Click Adjust resolution to make changes to the appearance of the display and to detect and configure any attached displays. In Windows 10 it is possible to quickly configure external displays from the Project menu ( press the Windows logo key on your keyboard and the P key).
Page 65 Quick Start Guide To Configure Displays Using Project Attach your display to the appropriate port, and turn it on. Press the + P key combination. Click on any one of the options from the menu to select PC screen only, Duplicate, Extend or Second screen only.
Page 66 Quick Start Guide To access Display (Control Panel) and Screen Resolution in Windows: Go to the Control Panel. Click Display (icon) and Adjust Resolution - In the Appearance and Personalization category. Make and changes required from the Display, Resolution, Orientation or Multiple display menus. Click Apply to save the settings.
Page 67 Quick Start Guide Display Settings: You can quickly adjust the display by right-clicking the desktop and selecting Display Settings (Figure 1 - 24). Adjust the settings using the sliders in the menu or click Advanced display settings (Figure 1 - 24) to change resolution.
Page 68 Quick Start Guide To access the Intel(R) HD Graphics Control Panel: Click Advanced settings (Figure 1 - 23 on page 1 - 34) in the Screen Resolution control panel in Win- dows. Click the Intel(R)... tab and click Graphics Properties (button) (below).
Page 69 Quick Start Guide To access the NVIDIA Control Panel: Right-click the desktop and select NVIDIA Control Panel (Figure 1 - 26). Double-click the icon (Figure 1 - 26) in the Windows control panel. Figure 1 - 26 - NVIDIA Control Panel Video Features 1 - 37...
Page 70: Power Options
Quick Start Guide Power Options Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power button item in Start Menu (or the context menu) may be used to Shut down or Restart (you can also add Hibernate/Sleep to the menu - see page 39).
Page 71 Quick Start Guide You can also use the context menu (right-click the Start Menu icon or press the Windows logo + X key combination) to Sign out, Sleep, Hibernate, Shut down, and Restart.  Adding Hibernate/Sleep to the Power Men Go to the Power Options (Hardware and Sound) control panel.
Page 72 Quick Start Guide Minimum Screen Resolution Settings Windows 10 has minimum screen resolution requirements. Right-click a blank area of the Desktop and select Screen Resolution (or go to the Display control panel). Adjust the Resolution to make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above. Figure 1 - 29 - Screen Resolution 1 - 40 Power Options...
Page 73: Features & Components Overview
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive/Solid State Drive • Optical (CD/DVD) Device • Multi-In-1 Card Reader • Touchpad/Clickpad and Buttons/Mouse •...
Page 74: Hard Disk Drive/Solid State Drive
Features & Components Hard Disk Drive/Solid State Drive  The hard disk drive (or Solid State Drive) is used to store your data in the computer. Bottom Cover The hard disk can be taken out to accommodate other 2.5" serial (SATA) hard disk Removal Warning drives with a height of 9.5mm/7mm.
Page 75: Optical (Cd/Dvd) Device
Features & Components Optical (CD/DVD) Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page D - 2). The Adjustment optical device is usually labeled “Drive D:”...
Page 76: Handling Cds Or Dvds
Features & Components Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Page 77: Dvd Regional Codes
Features & Components DVD Regional Codes  To change the DVD regional codes: DVD Region Note Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD region detection is DVD/CD-ROM drives. device dependent, not Double-click on the DVD-ROM device to bring up the Properties dialog box, and OS-dependent.
Page 78: Multi-In-1 Card Reader
Features & Components Multi-In-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 79: Touchpad/Clickpad And Buttons/Mouse
Features & Components Touchpad/Clickpad and Buttons/Mouse  The touchpad/clickpad is an alternative to the mouse; however, you can also add a Mouse Driver mouse to your computer through one of the USB ports. The touchpad/clickpad but- tons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- Touchpad/Clickpad Sensitivity...
Page 80 Features & Components Once you have installed the Touchpad driver (see “Touchpad” on page 4 - 8) you  can configure the functions from the Mouse control panel in Windows, or by double- clicking the driver icon in the notification area of the taskbar in the Desktop app. Scrolling You may then configure the tapping, buttons, scrolling, pointer motion and sensitiv- This computer model se-...
Page 81: Gestures And Device Settings
Features & Components Gestures and Device Settings  The Synaptics Gestures Suite application allows you to use a specific gesture (ac- tion) on the surface of the pad to perform specific actions to manipulate documents, Show Video objects and applications. You can get a clearer view of the gestures in- You can configure the settings from the Device Settings tab in Mouse Properties:...
Page 82 Features & Components Disabling the Touchpad/Clickpad If you need to disable the pad for any reason (e.g. you may find that when using the computer’s internal keyboard you accidentally trigger the pad when resting your wrists or palms on it) you can do so by using Fn + F1 key combination. You can also set the system to automatically disable the internal pad when an exter- nal USB point device (e.g.
Page 83 Features & Components ™ PalmCheck  The PalmCheck™ feature (Device Settings > Settings > Pointing > Sensitivity) helps prevent operating the Clickpad/Touchpad by accident, by recognizing when PalmCheck™ your palm is resting on it or brushing its surface while you are typing. order improve Clickpad/Touchpad...
Page 84 Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the pad surface and slide both fingers in the direction required (in a straight continuous mo- Figure 2 - 10 tion).
Page 85 Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the pad and slide it in a circular motion around the station- ary finger (clockwise or counterclockwise) to rotate the object.
Page 86: Audio Features
Features & Components Audio Features  You can configure the audio options on your computer from the Sound control Volume Adjustment panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar The sound volume level notification area/control panel (right-click the taskbar notification area icon can be clicking using the bring up an audio menu).
Page 87: Setup For Audio Recording
Features & Components Setup for Audio Recording  To record audio sources on your computer at optimum quality follow the instruc- tions below: Disabling Front Jack Detection Go to the Control Panel. It is recommended that Click Realtek HD Audio Manager (Hardware and Sound), or right-click the you do not disable front taskbar icon and select Sound Manager.
Page 88 Features & Components 2 - 16...
Page 89: Power Management Overview
Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 90: The Power Sources
Power Management The Power Sources  The computer can be powered by either an AC/DC adapter or a battery pack. Forced Off AC/DC Adapter If the system “hangs”, and the Ctrl + Alt + Del Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ key combination doesn’t DC adapter will damage the computer and its components.
Page 91: Turning On The Computer
Power Management Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- er button on the front panel. When the computer is on, you can use the power button as a Stand by/Hibernate/ Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the computer down).
Page 92: Shutting The Computer Down
Power Management Shutting the Computer Down Note that you should always shut your computer down by choosing the Shut down command as this will help prevent hard disk or system problems. Use the Power item in the Start Menu and select Shut down. You can also use the context menu (right-click the Start Menu icon or press the Windows logo...
Page 93: Power Plans
Power Management Power Plans  The computer can be configured to conserve power by means of power plans (Con- Resuming trol Panel > Power Options). You can use (or modify) an existing power plan, or Operation create a new one. Table 3 - 1, on The settings may be adjusted to set the display to turn off after a specified time, and page 3 - 11...
Page 94 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 95: Power-Saving States
Power Management Power-Saving States  You can use power-saving states to stop the computer’s operation and restart where Wake On LAN you left off. Windows 10 uses the Sleep, Hibernate and Shut Down power-saving Support states. Wake-On-LAN is only supported from Sleep or Sleep Hibernate states...
Page 96: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 97: Configuring The Power Buttons
Power Management Configuring the Power Buttons  The power/sleep button (Fn + F12 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Page 98 Power Management Adding Hibernate/Sleep to the Power Menu Add Hibernate/Sleep to the Power Menu as follows. Go to the Power Options (Hardware and Sound) control panel. Click “Change settings that are currently unavailable” Click Choose what the power buttons do. Click to put a check in the Hibernate/Sleep box under Shutdown settings.
Page 99: Resuming Operation
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F12 key combo). Power Status To Resume Icon Color Table 3 - 1 Power Off Press the Power Button Resuming Press the Power Button...
Page 100: Power Conservation Modes
Power Management Power Conservation Modes  This system supports Power Saving power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Power Conservation of inactivity. Adjust Power Conservation Modes from the Control Center: Modes The Power Saving set- Press the Fn + Esc key combination to toggle the Control Center on/off.
Page 101 Power Management Ctrl + Alt + Delete Key Combination You can use the CTRL + ALT + DEL key combination from almost any of the Win- dows 10 interfaces/Apps to bring up a full-screen displaying Lock, Switch User, Sign out, Change a password and Task Manager options. If you click the Power icon in the lower right corner of the screen a power management option menu ap- pears to display Sleep, Shut down, and Restart.
Page 102: Settings Menu Power Controls
Power Management Settings Menu Power Controls The Settings item in the Start Menu (and also as an App) gives you access to a num- ber of power settings control panels which enable you to quickly adjust power op- tions. Click System to access the menu including the power option settings. Figure 3 - 9 Settings 3 - 14 Settings Menu Power Controls...
Page 103 Power Management Battery Saver Battery Saver will display the battery level, and by clicking Battery Use you can see the current state of battery usage by application etc. Click Battery saver settings to adjust the battery saver level. Figure 3 - 10 Settings >...
Page 104 Power Management Power & Sleep Power & sleep gives you quick access to Screen and Sleep settings. Click Addi- tional power settings to go to the main power options control panel. Figure 3 - 11 Settings > Power & Sleep 3 - 16 Settings Menu Power Controls...
Page 105: Battery Information
Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Page 106: Conserving Battery Power
Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 107: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Page 108: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances Caution • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 109: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 110 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 15 Change Plan Settings / Change Advanced Power Settings 3 - 22 Battery Information...
Page 111 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 16 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 112 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 113: Removing The Battery
Power Management Removing the Battery  We recommend that you do not remove the battery yourself. If you do need to re- Bottom Cover move the battery for any reason (e.g. long term storage) see below. Removal Warning Turn the computer off, and turn it over. Do not remove any cov- Slide the latch in the direction of the arrow.
Page 114 Power Management 3 - 26...
Page 115: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities  This chapter deals with installing the drivers and utilities essential to the operation or Driver Installation & improvement of some of the computer’s subsystems. The system takes advantage of Power some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.
Page 116: Driver Installation
Drivers & Utilities Driver Installation Insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive. Click the message “Tap to choose what happens with this disc.” Click Run autorun.exe. Click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu. Figure 4 - 1 - Drivers Installer Screen 1 4 - 2 Driver Installation...
Page 117 Drivers & Utilities Check the driver installation order from Table 4 - 1, on page 4 - 4 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu below. Click to select the driver you wish to install, (you should note down the drivers as you install them). Follow the instructions for each individual driver installation procedure as listed on the following pages.
Page 118 Drivers & Utilities Win 10 Drivers (64-bit) Page # Win 10 Drivers (64-bit) Other / Options Page # System Required Chipset Page 4 - 7 Wireless LAN Module Page 6 - 2 Video (VGA) Page 4 - 7 Bluetooth Combo Module Page 6 - 7 Intel®...
Page 119: Updating/Reinstalling Individual Drivers
Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click Browse CD/DVD (button) in the Drivers Install- If you wish to update/reinstall individual drivers it er application and browse to the executable file in the may be necessary to uninstall the original driver.To do appropriate driver folder.
Page 120: User Account Control
Drivers & Utilities User Account Control  If a User Account Control prompt appears as part of the driver installation procedure, click Continue or Driver Installation General Guidelines Allow, and follow the installation procedure as direct- The driver installation procedure outlined in this Chapter (and in Chapter 7 Options &...
Page 121: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Note: After installing the video driver go to the Dis- play control panel to adjust the video settings to the Insert the Device Drivers & Utilities + User’s Manual highest resolution. disc and click Install Drivers (button). Chipset 1.
Page 122: Touchpad
Drivers & Utilities Touchpad MEI Driver 1. Click 6.Install Touchpad Driver > Yes. 1. Click 9.Install MEI Driver > Yes. 2. Click Next. 2. Click Next. 3. Click the button to accept the license, and then 3. Click the check box to accept the license and click Next.
Page 123: Optional Drivers
Drivers & Utilities Optional Drivers It is recommended you now also install the Intel Rap- id Storage Technology driver (see “Intel® Rapid See the pages indicated in Table 4 - 1, on page 4 - 4 Storage Technology” on page 6 - 12 - required for the driver installation procedures for any modules in- AHCI mode hard disks).
Page 124 Drivers & Utilities 4 - 10...
Page 125: Bios Utilities Overview
BIOS Utilities Chapter 5: BIOS Utilities  Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- If your computer has never been set up, or you are making important changes to the ed for guidance in set- system (e.g.
Page 126: The Setup Utility
BIOS Utilities The Setup Utility  Each time you turn on the computer the system takes a few seconds to conduct a BIOS Settings POST, including a quick test of the on-board RAM (memory). Warning As the POST proceeds, the computer will tell you if there is anything wrong. If there Incorrect settings can is a problem that prevents the system from booting, it will display a system summary cause your system to...
Page 127: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized distributor/supplier as soon as possible.
Page 128: Setup Screens
BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.
Page 129: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 130: Sata Port # (Main Menu)
BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. OffBoard SATA/NVme Controller Configuration (Main Menu) Pressing Enter opens the sub-menu to show the configuration of any devices on the off board SATA/NVme Controller if applicable.
Page 131: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to enable/disable the FlexiCharger and change the settings for the GPU Performance Scaling Advanced Menu 5 - 7...
Page 132: Flexicharger (Advanced Menu > Advanced Chipset Control)
BIOS Utilities FlexiCharger (Advanced Menu > Advanced Chipset Control)  The sub-menu here allows you to enable/disable the FlexiCharger. The FlexiCharg- er may be set to automatically start charging your battery when the battery reaches FlexiCharger Warning a certain capacity level (e.g. you could start the battery charge level at 40%). You can then set the level to stop charging (e.g.
Page 133: Sata Mode (Advanced Menu)
BIOS Utilities SATA Mode (Advanced Menu) The SATA (Serial ATA) controller operates in AHCI (Advanced Host Controller Interface) mode. Install the Intel Rapid Storage Technology driver to support your drive in AHCI mode (see “Intel® Rapid Storage Technology” on page 6 - 12).
Page 134: Security Menu
BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...
Page 135: Set User Password (Security Menu)
BIOS Utilities Note: To clear existing passwords press Enter and type the existing password, then  press Enter for the new password (without typing any password entry) and Enter again to confirm the password clearance. Password Warning If you set a boot pass- Set User Password (Security Menu) word (Password on boot You can set a password for user mode access to the Aptio Setup Utility.
Page 136: Secure Boot Control (Security Menu)
BIOS Utilities Secure Boot Control (Security Menu) Secure Boot Control prevents unauthorized operating systems and software from loading during the startup process. Secure Boot is available as a menu option if you have enabled UEFI Boot (see “Boot Menu” on page 5 - 14).
Page 137: Tpm Configuration (Security Menu)
BIOS Utilities TPM Configuration (Security Menu) This sub-menu will allow you to enable/disable Trusted Platform Module (TPM) support, and to configure the TPM State. Select TPM Configuration and press En- ter to access the sub-menu. Press Enter to access the Security Device Support menu and select Enable to support TPM.
Page 138: Boot Menu
BIOS Utilities Boot Menu Figure 5 - 7 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.
Page 139: Boot Option Priorities (Boot Menu)
BIOS Utilities available to help you move devices up and down the order. Boot Option Priorities (Boot Menu) Press Enter to access the menu, use the arrow keys to move up and down the menu, and press Enter to select a device from the Boot Option # list (the selected device will be highlighted in white).
Page 140: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 8 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will re- turn the Setup to its original state, and erase any previous changes you have made in a previous session.
Page 141: Modules & Options Overview
Modules & Options Chapter 6: Modules & Options  Overview Wireless Device Operation Aboard Aircraft This chapter contains information on the following modules, which may come with your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
Page 142: Wireless Lan Module
Modules & Options Wireless LAN Module  If you have included an Intel® or 3rd Party 802.11b/g/n (Combo) module is on Wireless Device (i.e. the system is not in Airplane Mode) before installing the driver. Operation Aboard Aircraft Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - The use of any portable Note that you need to install both the WLAN &...
Page 143: 3Rd Party 802.11B/G/N Driver Installation
Modules & Options 3rd Party 802.11b/g/n Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive. 2. Click Option Drivers (button). 3.
Page 144: Wlan Configuration In Windows 10
Modules & Options WLAN Configuration in Windows 10 You can configure a wireless connection using one of the following options, how- ever make sure the Wireless LAN module is turned on (and not in Airplane Mode) before configuration begins. Click the Wireless icon in the notification area of the taskbar.
Page 145 Modules & Options Enter a network security key (password) if required, and click Next. You can choose to share or connect to devices or not. When you are connected to the network access point it will display Connected status Select any connected network and click Disconnect to disconnect from a connected access point.
Page 146 Modules & Options You can click the Airplane Mode button to turn the mode On or Off. 10. You need to either use Airplane Mode, or to turn the WLAN module off aboard aircraft. 11. If you click on Network Settings to bring up Network & Internet for a more comprehensive list of network and internet settings including Wi-Fi (can be turned on/off), Airplane mode (Airplane mode and Wireless devices can be turned on/off) VPN, Dial-up, Ethernet and Proxy.
Page 147: Bluetooth Combo Module
Modules & Options Bluetooth Combo Module  If your purchase option includes the Combination Wireless LAN & Bluetooth Wireless Device module (either Intel® or 3rd Party) then install the driver as instructed overleaf. Operation Aboard Aircraft Make sure that the module is on (i.e. the system is not in Airplane Mode) before in- The use of any portable stalling the driver.
Page 148: 3Rd Party Bluetooth (V4.0) Combo Driver Installation
Modules & Options 3rd Party Bluetooth (V4.0) Combo Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive. 2. Click Option Drivers (button). 3.
Page 149 Modules & Options Bluetooth Configuration in Windows Click the Settings item in the Start Menu and then click Devices (or click the Blue- tooth icon in the taskbar and click Add a Bluetooth Device). Click Bluetooth and make sure Bluetooth is On and a list of discovered devices will appear.
Page 150 Modules & Options Enter the code into your Bluetooth enabled device and click Yes on the computer to complete the pairing. Select a device and click Remove Device to disconnect from any device. Figure 6 - 6 Devices > Bluetooth Remove Device 6 - 10 Bluetooth Combo Module...
Page 151: To Make Your Computer Discoverable To Bluetooth Devices
Modules & Options To Make your Computer Discoverable to Bluetooth Devices Click the Settings item in the Start Menu and then click Devices. Click Bluetooth and under Related Settings click More Bluetooth options (or click the Bluetooth icon in the taskbar Open Settings). In Bluetooth Settings make sure that Allow Bluetooth devices to find this PC check box (Discovery) has a check inside it.
Page 152: Intel® Rapid Storage Technology
Modules & Options Intel Rapid Storage Technology ®  Install the Intel® Rapid Storage Technology to support your AHCI mode SATA IRST and M.2 PCI-e drive. SSDs Note that Intel® Rapid IRST Driver Installation Storage Technology 1. Insert the Device Drivers & Utilities + User’s Manual disc into an attached does not support M.2 SSDs with a PCI-e In- DVD drive.
Page 153: Sound Blaster Cinema 2
Modules & Options Sound Blaster Cinema 2 Install the Sound Blaster Cinema 2 application to allow you to configure the audio settings to your requirements for the best performance in games, music and movies. Sound Blaster Cinema 2 Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive.
Page 154: Sound Blaster Cinema 2 Application
Modules & Options Sound Blaster Cinema 2 Application  Run the Sound Blaster Cinema 2 control panel from the notification area of the taskbar (or from Creative folder item in the Apps menu). Click on the tabs to access Sound Blaster Cinema 2 &...
Page 155 Modules & Options Sound Blaster Cinema 2 Tutorial  The Sound Blaster Cinema 2 application will provide a quick Tutorial on the initial run of the application, however you can also run the Tutorial from the drop-down Software Update menu if you require a further introduction to the application. Check for the latest soft- ware updates by making sure you are connected...
Page 156 Modules & Options Sound Blaster Cinema 2 Advanced Settings Sound Blaster Cinema 2 selects the built-in speakers by default and this setting may cause some sound quality issues when using headphones. To adjust the settings for headphones do the following: Run the Sound Blaster Cinema 2 application.
Page 157 Modules & Options The Sound Blaster Cinema 2 SBX PRO Studio (see overleaf) can be turned On/ Off by clicking the Power Button (when the power is off the icon will be dimmed Volume can be adjusted by means of the slider to the right of the volume icon, and you can toggle mute on/off by clicking the vol- ume icon itself ( Power Button...
Page 158: Sound Blaster Cinema 2 Sbx Pro Studio
Modules & Options Sound Blaster Cinema 2 SBX Pro Studio The Sound Blaster Cinema 2 SBX Pro Studio offers a suite of playback technol- ogies to enhance sound. Each playback technology at the bottom of the screen has an On/Off button to allow you to enable/disable it, and most controls feature a slid- er to adjust the levels.
Page 159 Modules & Options • Crystalizer: Enriches audio to make it sound livelier. Figure 6 - 13 Sound Blaster Cinema 2 SBX Pro Studio Crystalizer • Bass: Enhances the bass level of the sound system. Figure 6 - 14 Sound Blaster Cinema 2 SBX Pro Studio Bass...
Page 160 Modules & Options • Smart Volume: Minimizes sudden volume changes to avoid the need for con- stant adjustment. Figure 6 - 15 Sound Blaster Cinema 2 SBX Pro Studio Smart Volume • Dialog Plus: Optimizes dialogue levels for movies etc. Figure 6 - 16 Sound Blaster Cinema 2 SBX Pro...
Page 161 Modules & Options Sound Blaster Cinema 2 Profiles The Profile buttons on the left side of the screen give you preset settings to enhance your audio settings for Music, Movie, Game and Voice. You can choose Custom to adjust the settings to your own set preferences. Figure 6 - 17 Sound Blaster Cinema 2...
Page 162 Modules & Options Sound Blaster Cinema 2 & HDMI When you connect an HDMI display to the HDMI-Out port, the Sound Blaster Cin- ema controls will be disabled. A warning box will pop-up and will prompt “...Do you want to select another audio device now?”.
Page 163: Pc Camera Module
Modules & Options PC Camera Module When the PC Camera application is run the LED indicator to the left of the camera will be illuminated in (see Figure 1 - 2 on page 1 - 7/Figure 1 - 3 on page 1 8).
Page 164: Camera App
Modules & Options Camera App Make sure the PC Camera is turned on by using the Fn + F10 key combination (or Control Center button). Run the Camera app from the Start menu by clicking on the Camera app icon (you can type “camera”...
Page 165 Modules & Options Click Settings to access the camera settings menu to make adjustments for Camera Button long key press function, Photo Aspect ratio, Framing grid, video recording frame rates, Flicker reduction and Digital video stabilization.  Camera Settings The Self Timer may be set to take Photos after 2, 5 or 10 sec- onds and can also be set to continue taking pictures until the camera button is pressed again.
Page 166: Taking Pictures/Capturing Video
Modules & Options Taking Pictures/Capturing Video Make sure the PC Camera is turned on by using the Fn + F10 key combination (or Control Center button). Run the Camera app from the Start menu by clicking on the Camera app icon (you can type “camera”...
Page 167 Modules & Options Captured photos and videos will be saved to the Photos app stored in the Start menu (type Photos into the search box if you cannot find the app). Figure 6 - 23 Photo App (For Captured Photos & Videos) PC Camera Module 6 - 27...
Page 168: Trusted Platform Module
Modules & Options Trusted Platform Module The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.
Page 169: Enabling & Managing Tpm
Modules & Options Enabling & Managing TPM Restart the computer. Enter the Aptio Setup Utility pressing F2 during the POST/startup. Use the arrow keys to select the Security menu. Select TPM Configuration and press Enter to access the sub-menu. Press Enter to access Security Device Support and select Enable. Press F4 to save the changes and restart the computer.
Page 170: Tpm Management In Windows
Modules & Options TPM Management in Windows You can manage your TPM settings from within Windows: Go to the Control Panel. Click BitLocker Drive Encryption (System and Security). Click TPM Administration. Figure 6 - 25 BitLocker Drive Encryption (TPM Administration) 6 - 30 Trusted Platform Module...
Page 171 Modules & Options The TPM Management window allows you to configure the TPM within Windows. As TPM is usually administered within large enterprises and organizations, your system administrator will need to assist you in managing the information here. Figure 6 - 26 Trusted Platform Module (TPM) Management on...
Page 172: Tpm Actions
Modules & Options TPM Actions Click Prepare the TPM and follow the instructions in the Wizard to prepare the TPM (this will probably require a restart of the computer and confirmation of the setting changes after restart by pressing the appropriate F key). After the restart the TPM will be prepared and you can then use the Actions menu to Turn TPM off, Change Owner Password, Clear TPM or Reset TPM Lockout.
Page 173 Modules & Options BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk. Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Click Turn on Bit Locker. Follow the on-screen instructions to setup BitLocker, and make sure you have a removable media (e.g.
Page 174: 4G Module
Modules & Options 3G/4G Module  (For Model A Computers Only) Wireless Device If you have included an optional UMTS/HSPDA+ based 3G module (Universal Operation Aboard Mobile Telecommunications System or High Speed Packet Access) module or LTE Aircraft (Long Term Evolution) 4G module (see “Communication”...
Page 175 Modules & Options 3G/4G Module USIM Card Installation  Follow the instructions below to install the USIM card (which will be supplied by Power Safety your service provider). Warning Turn off the computer, and turn it over. Before you undertake any Slide the latch in the direction of the arrow.
Page 176 Modules & Options Insert the USIM card (at the rear of the battery compartment) as illustrated  below until it clicks fully into position, and replace the battery. USIM Card Orientation Note that the USIM card’s readable side (with the gold-colored contacts) should face upwards as il-...
Page 177: 3G/4G Configuration In Windows 10
Modules & Options 3G/4G Configuration in Windows 10 You can configure a 3G/4G connection as below, however make sure the system is not in Airplane Mode before configuration begins. You can connect to a 3G/4G con- nection in much the same way as the WLAN connection. Click the Settings item in the Start Menu and then click Network and Internet.
Page 178 Modules & Options 6 - 38...
Page 179: Troubleshooting Overview
Troubleshooting Chapter 7: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 180: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 181: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 182: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 183: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if as this may violate the terms of your warranty.
Page 184 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 185: Problems And Possible Solutions
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
Page 186 Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 187 Troubleshooting Problem Possible Cause - Solution Nothing appears on screen. The system is in a power saving mode. Toggle the sleep/resume key combination, Fn + F12 or F4 (see “Configuring the Power Buttons” on page 3 - The screen controls need to be adjusted. Toggle the screen control key combinations Fn + F8/F9.
Page 188 Troubleshooting Problem Possible Cause - Solution The sound cannot be heard or the volume The volume might be set too low. Check the volume control in the Volume is very low. Control Panel in the Windows notification area, or use the key combination Fn + F5 and F6 (see “Function/Hot Key Indicators”...
Page 189 Troubleshooting Problem Possible Cause - Solution  Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot keys unique to the system’s regular keyboard may not work.
Page 190 Troubleshooting Problem Possible Cause - Solution The Wireless LAN/Bluetooth modules The driver(s) for the module(s) have not been installed. Make sure you have cannot be configured. installed the driver for the appropriate module (see the instructions for the appropriate module in “Modules &...
Page 191 Troubleshooting Problem Possible Cause - Solution I have used Update Driver in Device It is very important that the drivers are installed in the order indicated in Chapter Manager (Unknown device > Other 4 (which is the numbered installation order on the Device Drivers & Utilities + Devices) to try and install the Airplane User’s Manual disc).
Page 192 Troubleshooting 7 - 14...
Page 193: Interface (Ports & Jacks) Overview
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 194: Notebook Ports And Jacks
Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
Page 195 Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot.
Page 196 Interface (Ports & Jacks) A - 4...
Page 197: Control Center & Flexikey® Overview
Control Center & Flexikey® Appendix B: Control Center & Flexikey® Overview The following chapter will give a quick description of the functions of the Control Center & Flexikey® appli- cations. Control Center Control Center gives quick access to frequently used controls, power management features and enables you to quickly turn modules on/off.
Page 198 Control Center & Flexikey®  Control Center Access To run the Control Center press the Fn + Esc key combination, or double-click the icon the notification area of the taskbar. Close the Control Center by clicking the close icon in the top right of the panel (move the cursor onto the top right corner of the panel to highlight it).
Page 199 Control Center & Flexikey® Power Modes You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the Power Conservation Mode, Airplane Mode, Power Plan and PC camera power etc. You can click a Control Center icon to set an overall power mode and then click individual icons in the Control Center to power on/off the Touchpad and PC camera.
Page 200 Control Center & Flexikey® Control Center Menus The Control Center contains 3 menu headings (System Program, Device and Gaming) under the Power Modes. Click the menu headings and then click any of the buttons outlined on the following pages. Figure B - 2 - Control Center Menus B - 4 Overview...
Page 201 Control Center & Flexikey® Power Status (System Program) The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state. Brightness (System Program) The Brightness icon will show the current screen brightness level.
Page 202 Control Center & Flexikey® Power Conservation (System Program) This system supports Power Saving power management features that place computers (CPU, hard drive, etc.) into a low-power sleep modes after a desig- nated period of inactivity (see “Power Conservation Modes” on page 3 - 12).
Page 203 Control Center & Flexikey® TouchPad/Camera (Device) Click either of these buttons to toggle the TouchPad or camera module’s power status. The icon will appear dimmed when it is off Note that the power status of the camera module is also effected by the Power Mode selected (see Table B - 1, on page B Caps Lock/Scroll Lock/ Number Lock/Airplane Mode Click the button to toggle the appropriate lock mode and Airplane Mode.
Page 204: Flexikey® Application
Control Center & Flexikey® Flexikey® Application Click the button in the Control Center, or the click the icon in the notification area of the taskbar, to access the Flexikey® application. Profiles The menus on the left side of the application relate to Profiles. You can Add or Delete Profiles (you can main- tain 12 active Profiles), Export and Import profiles from the menus.
Page 205: Flexikey® Application Features
Control Center & Flexikey® Flexikey® Application Features • EXPRESS KEY - This feature allows you to configure a single key to send multiple key combinations or to create more useful shortcut keys. This is useful in gaming or when using applications which have a complex set of keyboard shortcuts.
Page 206: Enabling Or Disabling Flexikey
Control Center & Flexikey® Enabling or Disabling Flexikey® You can enable or disable Flexikey® (and therefore any hotkeys or mouse profile functions currently in use) by using the Fn + Backspace key combination. Pressing this key combination will toggle you between the currently selected keyboard or mouse profile to the standard keyboard and/or mouse settings, and back again.
Page 207: Keyboard Settings
Control Center & Flexikey® Keyboard Settings The keyboard settings allow you to configure actions for any single key (or a combination of keys). Click the key and then select the Action Type (Express Key, Launch App, Express Text or Disable) from the menu at the bottom of the page.
Page 208: Mouse Settings
Control Center & Flexikey® Mouse Settings When an external mouse is attached, the mouse settings allow you to configure actions for the left , right and middle buttons of the attached mouse, and also for any backward and forward buttons if appli- cable (on a gaming type mouse).
Page 209: Keyboard Settings - Express Key
Control Center & Flexikey® Keyboard Settings - Express Key To configure a single key to send multiple key combinations, or to create more useful shortcut keys, use Express Key. Enable and select the keyboard under your chosen profile, click on a key to select it, and then click to select Express Key in Action Type.
Page 210 Control Center & Flexikey® Click Save to save the settings within your chosen profile. If you want to remove any individual key click to select it, and then click Delete. If you want to clear all the settings click Restore to return to the default key setting. 10.
Page 211 Control Center & Flexikey® Enabling Time Record If you want to create a delay between key presses within the key combination, then you can use Time Record function to do so. Enable and select the keyboard under your chosen profile, click to select a key for the shortcut action, and then click to select Express Key in Action Type.
Page 212 Control Center & Flexikey® You can edit the delay between key presses by clicking in the Delay Time (MS) field and typing a new number for the delay between the key presses. Figure B - 12 - Time Record Between Key Presses Click to close the Time Record window.
Page 213: Keyboard Settings - Launch App
Control Center & Flexikey® Keyboard Settings - Launch App You can configure keys to launch any application or program as follows: Enable and select the keyboard under your chosen profile, click to select a key to launch the application, and then click to select Launch App in Action Type.
Page 214 Control Center & Flexikey® Navigate to the executable file of the application and click Open. The key will now be configured to open the selected application under your chosen Profile, and the key will appear in green. Figure B - 14 - Key Set to Launch App If you want to remove any Launch App Key, select it and click on Restore.
Page 215: Keyboard Settings - Express Text
Control Center & Flexikey® Keyboard Settings - Express Text A single key can be set to send a string of text within any application using Express Text. Enable and select the keyboard under your chosen profile, click to select a key, and then click to select Express Text in Action Type.
Page 216 Control Center & Flexikey® Click in Send key if required (the Send key is the key used to in your target program to send a text message e.g the Enter key would be the most commonly used), or you can leave it blank if you prefer. The key will now be configured to send the text message in the target program under your chosen Profile, and the key will appear in blue.
Page 217: Keyboard Settings - Disable
Control Center & Flexikey® Keyboard Settings - Disable You can use the program to disable any keys not required. Enable and select the keyboard under your chosen profile, click to select a key to disable, and then click to select Disable in Action Type.
Page 218: Mouse Settings - Express Key
Control Center & Flexikey® Mouse Settings - Express Key To assign a mouse button click to send multiple key combinations (an external mouse must be attached), or to create more useful shortcut keys, use Express Key. Enable and select the mouse under your chosen profile, click on a mouse button to select it, and then click to select Express Key in Action Type.
Page 219 Control Center & Flexikey® Click in the Tool Tips field and type to give the key combination a name e.g. “Sprint Fwds”, then click back in the Name field (to avoid adding the recorded keys to the Tool Tips name). Click Start Record and then press the key or keys (in this case we will press Left Shift and W) required (make sure you press the key(s) required and do not click on them).
Page 220: Mouse Settings - Launch App
Control Center & Flexikey® Mouse Settings - Launch App You can assign a mouse button click to launch any application or program as follows: Enable and select the mouse under your chosen profile, click on a mouse button to select it, and then click to select Express Key in Action Type.
Page 221 Control Center & Flexikey® Navigate to the executable file of the application and click Open. The mouse click will now be configured to open the selected application under your chosen Profile, and the button will appear in green Click Save to save the settings within your chosen profile. Figure B - 19 - Mouse Button Set to Launch App Mouse Settings - Launch App B - 25...
Page 222: Mouse Settings - Express Text
Control Center & Flexikey® Mouse Settings - Express Text A mouse button click can be set to send a string of text within any application using Express Text. Enable and select the mouse under your chosen profile, click on a mouse button to select it, and then click to select Express Text in Action Type.
Page 223 Control Center & Flexikey® Click in Send key if required (the Send key is the key used to in your target program to send a text message e.g the Enter key would be the most commonly used), or you can leave it blank if you prefer. The mouse button click will now be configured to send the text message in the target program under your chosen Profile, and the button will appear in blue.
Page 224: Mouse Settings - Disable
Control Center & Flexikey® Mouse Settings - Disable You can use the program to disable any mouse button clicks if not required. Enable and select the mouse under your chosen profile, click on a mouse button to select it, and then click to select Disable in Action Type.
Page 225: Statistics
Control Center & Flexikey® Statistics The Statistics tab allows you to record keys used in any application, and to disable any infrequently, or unused, keys to save any accidental incorrect key presses. Click the Statistics Tab, and press Start Record to start recording the frequency of key presses for keys used. You can then go to the application you wish to use the profile for, and use the application as normal so that a standard set of keys used may be recorded.
Page 226 Control Center & Flexikey® B - 30...
Page 227: Video Driver Controls
Video Driver Controls Appendix C: Video Driver Controls  The basic settings for configuring the LCD are outlined in “Video Features” on Video Card Options page 1 - 32. Make sure you install the drivers in the order indicated in Table 4 - 1, Note that card types, on page 4 -...
Page 228: Dynamic Video Memory Technology
Video Driver Controls Dynamic Video Memory Technology  ® Intel DVMT automatically and dynamically allocates as much (up to 1748MB) system memory (RAM) as needed to the integrated video system (the video driver DVMT Notes must be installed). DVMT returns whatever memory is no longer needed to the op- DVMT is not local video erating system.
Page 229: Microsoft Hybrid Graphics
Video Driver Controls Microsoft Hybrid Graphics  Most notebook computers come with either a discrete or integrated graphics solu- iGPU or dGPU tion. Note the NVIDIA control Discrete graphics solutions feature a dedicated Graphics Processing Unit (GPU) panel refers to High- performance NVIDIA which are capable of playing games, watching HD video or running GPU-based ap-...
Page 230 Video Driver Controls How the Technology works  When the system is powered up and is displaying just the desktop, the dGPU will be powered off. In this case the system is running in the same way as a system without Customization a discrete graphics solution.
Page 231: Intel® Hd Graphics Control Panel
Video Driver Controls Intel HD Graphics Control Panel ® Advanced video configuration options are provided by the Intel HD Control Pan- ® el. To access the control panel see below and overleaf: Click the Intel® HD Graphics Control Panel icon in the Apps screen. Figure C - 1 Apps Screen Intel ®...
Page 232 Video Driver Controls Click Advanced settings in the Screen Resolution control panel in Windows. Click the Intel(R) HD Graphics Control Panel tab and click Graphics Properties (button). Double-click the Intel(R) HD Graphics control panel in the Windows Control Panel. Figure C - 3 Screen Resolution >...
Page 233 Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate  menu panel and adjusting the settings from the menus. Home Click the Home button to return to the main menu screen in any of the sub- menu screens.
Page 234 Video Driver Controls Display  Click either Display Settings or Color Settings to make display adjustments, in- cluding configuration for any attached external displays. Multiple Display At least one other dis- play must be attached in order to view multiple display selection tions.
Page 235 Video Driver Controls Click the Display menu at the top of the screen to display the sub-menus. The Mul-  tiple Displays menu allows you to configure the display mode of any attached dis- plays (see “Attaching Other Displays” on page C - 20).
Page 236 Video Driver Controls The Custom Resolutions sub-menu allows you to adjust the display (or any at- tached display) to any width, height, refresh rate, color depth and underscan percent- age of your choice. Note that incorrect settings can cause system instability and even possible component damage, so this is adjusted at your own risk.
Page 237 Video Driver Controls This menu allows you to choose how 3D images are displayed. Performance gives the smoothest motion of images, Quality displays the most detail, Balanced Mode provides better computer performance with good quality and Custom allows you to configure the Anisotropic Filtering and Vertical Sync and features to your prefer- ences.
Page 238 Video Driver Controls Options and Support Hot Key Manager in Options and Support allows you to create hot keys for open- ing the application, rotating the display, scaling etc. Click Apply to save changes. Figure C - 9 Intel ® HD Graphics Control Panel Options and Support...
Page 239 Video Driver Controls Click the Options menu at the top of the screen to display the sub-menus. The In-  formation Center provides details on System Information, the Built-In Display and any attached displays. Preferences Go to the Preferences sub-menu in Options to configure the preferences for the Intel®...
Page 240 Video Driver Controls Video The Video menu allows you to brighten or darken movies, or to switch to vivid col- ors. The Preview image will display a sample image using the current settings. You can Save Profile and name the Profile to recall the settings at any time. Click Apply to save changes (select Color Enhancement, Image Enhancement, Image Scaling or Gamut Mapping from the menu).
Page 241 Video Driver Controls Click the Video menu at the top of the screen to display the sub-menus.The Image Enhancement menu allows you to adjust the Sharpness, Skin Tone Enhancement in the Basic menu, and Noise Reduction, Contrast Enhancement and Film Mode Detection in the Advanced menu.
Page 242 Video Driver Controls Enable Image Scaling to use the sliders to adjust the scaling. Figure C - 13 Intel ® HD Graphics Control Panel Video Image Scaling C - 16 Intel® HD Graphics Control Panel...
Page 243 Video Driver Controls Power The battery life can be extended through dynamic control of the frame rate if Ex- tended Battery Life for Gaming is enabled. Figure C - 14 Intel ® HD Graphics Control Panel - Power Intel® HD Graphics Control Panel C - 17...
Page 244 Video Driver Controls Profiles You can select one of the preset profiles (Brighten Video, Darken Video and En- hance Video Colors) from the menu on the left. Alternatively you can go through the menus to make adjustments to your preferences for Display, Color, Video, 3D, Options and Support and Power (tick any boxes for the settings required), and then Save the settings to a profile (which may be imported or exported).
Page 245: Display Devices & Options
Video Driver Controls Display Devices & Options  Note that you can use external displays connected to the HDMI-Out port and/or ex- 4K2K Videos on 4K2K ternal monitor port. See your display device manual to see which formats are sup- External Displays ported.
Page 246: Attaching Other Displays
Video Driver Controls Attaching Other Displays  To Clone Displays: Multiple Display Attach your external display to the HDMI-Out port/external monitor port, and turn it on. Go to the Intel(R) HD Graphics Control Panel control panel and click Display > At least one other dis- Multiple Displays (sub-menu).
Page 247 Video Driver Controls To Enable Extended Mode:  Attach your external display to the HDMI-Out port/external monitor port, and turn it on. Go to the Intel(R) HD Graphics Control Panel control panel and click Display > Display Settings Multiple Displays (sub-menu). Extended Desktop Click Extended from the Select Display Mode menu.
Page 248: Configure Other Displays Using Project
Video Driver Controls Configure Other Displays Using Project You can configure attached displays from Project. Attach your display to the appropriate port, and turn it on. Press the + P key combination. Click on any one of the options from the menu to select PC screen only, Duplicate, Extend or Second screen only.
Page 249: Configuring An External Display In Windows
Video Driver Controls Configuring an External Display In Windows Attach your external display to the appropriate port, and turn it on. Go to the Control Panel. Click Display (icon) and Adjust Resolution (Appearance and Personalization). Click the Detect button. The computer will then detect any attached displays. Figure C - 19 Screen Resolution Multiple Displays...
Page 250 Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure C - 20 Screen Resolution Multiple Display Options • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 251 Video Driver Controls The System Control Panel in Settings may also be used to configure displays. Attach your external display to the appropriate port, and turn it on. Click the Start Menu and click Settings > System (or right-click the desktop and select Display Settings).
Page 252: Nvidia Control Panel
Video Driver Controls NVIDIA Control Panel  More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Go to the Control Panel. To access the Ge- Double-click NVIDIA Control Panel (click to view the control panel in either Large Force..
Page 253 Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and  tools which allow quick access to features such as image settings, 3D Settings and video configuration. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 254 Video Driver Controls Customization Options  One of the most important aspects of hybrid technology is that it will switch between Display GPU the integrated GPU and discrete GPU seamlessly and automatically, and does not re- Activity Icon quire any input from the user. However customization options are offered for users who prefer to set their own parameters for GPU usage.
Page 255 Video Driver Controls Close the NVIDIA Control Panel.  Find the executable file icon of the application you want to run. Right-click the icon and select Run with graphics processor from the context iGPU or dGPU menu. Select either High-performance NVIDIA processor (dGPU) or Integrated Note the NVIDIA con- graphics (iGPU) to run the program with the selected GPU.
Page 256: Customization Options
Video Driver Controls Global Settings  Global settings allows you to set the preferred graphics processor for overall use. Ideally this would be the iGPU for battery life, but this can be set to the dGPU if pre- Customization ferred. Options Go to the NVIDIA Control Panel.
Page 257 Video Driver Controls Program Settings Program settings allows you to make specific adjustments for installed applications. Go to NVIDIA Control Panel. Click Manage 3D Settings (3D Settings) and select Program Settings (tab). Select a program to customize from the drop-down menu, or click Add to add any program that does not appear in the menu.
Page 258: Set Physx Configuration
Video Driver Controls Set PhysX Configuration ® NVIDIA PhysX is a physics engine that can use the GPU to accelerate game and ® ® 3D application performance. You can select the GeForce video card or CPU as a PhysX processor, or configure the computer to auto-select a PhysX processor ®...
Page 259: Nvidia Geforce Experience
Video Driver Controls NVIDIA GeForce Experience If you have a working internet connection (and you will need remain connected to the internet to run NVIDIA GeForce Experience) you can click the NVIDIA GeForce Experience desktop icon (or App) to run the application. This will op- timize your gaming settings for your GTX video card by downloading the latest set- tings from the NVIDIA cloud data center.
Page 260 Video Driver Controls NVIDIA GeForce Experience Features • Click the Games tab and click Scan for games to update the optimal settings for your installed games from the NVIDIA cloud data center for your PC. • The Drivers tab allows you to check and download the latest available video driver.
Page 261: Nvidia Geforce Experience - Batteryboost
Video Driver Controls NVIDIA GeForce Experience - BatteryBoost BatteryBoost allows you to optimize your system’s battery life when gaming. You can adjust the BatteryBoost slider in Preferences > BatteryBoost (make sure you have restarted the computer after the first run of NVIDIA GeForce Experience). Running BatteryBoost On first run of NVIDIA GeForce Experience you should be connected to the inter- net (BatteryBoost will not appear at this stage).
Page 262: Nvidia Geforce Experience - Shadowplay
Video Driver Controls NVIDIA GeForce Experience - ShadowPlay Click on the ShadowPlay icon at the top right of the control panel and then click the power button to enable the feature. You can adjust the settings from the menu buttons. Figure C - 32 NVIDIA GeForce Experience...
Page 263: Hdmi Audio Configuration
Video Driver Controls HDMI Audio Configuration  HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Volume Adjustment In some cases it will be necessary to go to the Sound control panel and manually The sound volume level configure the HDMI audio output as per the instructions below. can be clicking using the Go to the Sound control panel.
Page 264 Video Driver Controls Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure C - 34 HDMI Device Properties C - 38 HDMI Audio Configuration...
Page 265 Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party application to play...
Page 266: Wireless Display
Video Driver Controls Wireless Display  Wireless Display uses your Wireless LAN module/WLAN Bluetooth Combo mod- Compatible ule (you need to make sure that your video adapter/display device is compatible Adapters with your particular WLAN/Combo module) in conjunction with a compatible video adapter/display device (purchased separately) to allow you to display the For a list of compatible adapters check the vid-...
Page 267: Wireless Display Configuration
Video Driver Controls Wireless Display Configuration Note that no driver or application is required for wireless display in Windows 10. Press the + P key combination. Click Connect to a wireless display at the bottom of the Project screen and follow the steps to connect to any wireless enabled display.
Page 268 Video Driver Controls You may then need to input a pin number for the device to which you are connecting and click Next. The display will then connect (for specific settings for your display see the documentation supplied with your compatible adapter/display for full details). Go to the Project menu and click Disconnect to temporarily disconnect from the wireless display.
Page 269 Specifications Appendix D: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your distributor/supplier for details.
Page 270: Processors
Specifications Processors Two 204 Pin SO-DIMM Sockets For Models A & B Design II Series: Supporting DDR3L 1600 MHz Memory NVIDIA® GeForce GTX 950M Discrete Intel® Core™ i7-6700HQ (2.6GHz) Modules (real operational frequency GPU: 8MB Smart Cache, 14nm (14 Nanometer), depends on the FSB of the processor) 2GB gDDR3 Video RAM DDR3L-1600MHz, TDP 45W...
Page 271: Audio
Specifications Audio Three USB 3.0 Ports For Model A Only: One External Monitor Port Slot 3 for M.2 3042 LTE/HSPA+ 3G or 4G High Definition Audio Interface Module with USB Interface (Factory One HDMI-Out (High-Definition Built-In Microphone Option) Multimedia Interface) Port (with HDCP) 2 * Built-In Speakers One Headphone-Out Jack Communication...
Page 272: Battery
Specifications For Model A Only: Power Management Features 3G *UTMS/HSPA+ M.2 3042 Card Module Supports Wake on LAN (AC Mode Only) IMR (Injected Molded Resin) LCD Back with USB Interface (Factory Option) Covers (For some Model designs in this Supports Wake on USB series) Supports Wake on RTC Alarm (AC Mode 4G LTE M.2 3042 Card Module with USB...
Page 273: Specifications
Specifications Dimensions & Weight Model A: 374mm(w) * 252mm(d) * 14 - 31.4 mm(h) 2.5kg Barebone System* with Battery & 374mm(w) * 249.5mm(d) * 14.8 - 32.8mm(h) 2.5kg Barebone System* with Battery & Model B: 413mm(w) * 272.8mm(d) * 36.4mm(h) 3.1kg Barebone System* with Battery &...
Page 274 Specifications D - 6...

overam Mirage 5652 User Manual

Quick Start Guide Overview

Features & Components Overview

Power Management Overview

Drivers & Utilities

BIOS Utilities Overview

Modules & Options Overview

Troubleshooting Overview

Interface (Ports & Jacks) Overview

Control Center & Flexikey® Overview

Video Driver Controls

Specifications

Quick Links

Related Manuals for overam Mirage 5652

Summary of Contents for overam Mirage 5652
