- Page 1 SA2100 Quick Start Guide Version: 1.00 SA2100QS001...
- Page 2 Setting Up The Router Insert the SIM into the SIM holder located in the battery compartment. If using a power supply, plug it into an electrical outlet. If using the power cable make sure it is connected to a supported power source. Contact your wireless provider to activate the SIM and/or data plan.
- Page 3 Ports and LEDs Cellular antenna connector RF1 (Primary) Micro USB Port Shutdown or restart button Ethernet port 8 Pin IO connector (Includes power) Cellular antenna connector RF2 Green Power Normal operation Green WiFi Wi-Fi enabled / traffic Green Blue 4G/3G Orange Green Signal...
- Page 4 Connect to the router using the SSID and WiFi key information provided on the label located on the bottom of the device. The default SSID is SA2100-xxx and is also shown on the product label on the bottom of your router.
- Page 5 You may customize your SA 2100 settings via the SA 2100 Web Interface. To access the Web Interface, open an Internet browser on a connected device and navigate to http://my.sa2100/ or 192.168.1.1. and the browser will display the SA 2100 Home Page. You must enter the Administrator password to proceed beyond the Home Page.
- Page 6 Features The SA 2100 has the following features: 3G/4G/LTE cellular service Connect up to 10 Wi-Fi devices Ethernet & Ethernet over USB connectivity N4A Device Manager N4A CMS External Modem Antenna Ports Accelerometer GPIO Interface IPv6 support Business continuity with backup battery Flexible power options Advanced security features 1-wire interface...
- Page 7 Accessories The following accessories are available for the SA 2100: Backup Battery Power Cable USB Cable Mounting bracket Mounting harness Power Supply novatelwireless.com...
- Page 8 Copyright © 2013 Novatel Wireless. All rights reserved. Complying with all applicable copyright laws is the responsibility of the user. Without limiting the rights under copyright, no part of this document may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording or otherwise), or for any purpose, without the express written permission of Novatel Wireless.
