Sapido AU-4512S User Manual

Wireless dongle n+
Hide thumbs Also See for AU-4512S:
Table of Contents

Advertisement

Quick Links

Wireless
Dongle
+
Wireless N
USB Adapter
AU-4512S
Networking
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AU-4512S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sapido AU-4512S

Summary of Contents for Sapido AU-4512S

  • Page 1 Wireless Dongle Wireless N USB Adapter AU-4512S Networking User Manual...

  • Page 2: Fcc Statement

    IMPORTANT NOTE FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance20cm between the radiator & your body. http://www.sapido.com.tw ver. 1.0...
  • Page 3 "Council Directive on the Approximation of the Laws of the Member Sates relating to Electromagnetic Compatibility" (89/336/EEC; 92/31/EEC; 93/68/EEC). The Declaration of Conformity can be found at the Sapido regional website. www.sapidotech.de...

  • Page 4: Table Of Contents

    User Guide of AU-4512S Installing the software of USB Adapter ................. 5 Configuring your wireless network (with Microsoft Zero Configuration Tool) ..13 Wi-Fi Protect Setup (WPS)...................... 15 Pin Input Config (PIN)...................... 16 Push Button (PBC)......................20 Radio Off........................... 21 Disable Adapter .........................

  • Page 5: Installing The Software Of Usb Adapter

    Installing the software of USB Adapter Step 1. When installation CD-ROM starts, following language selection menu will appear and please select the preferred Language to begin with. Step 2. To run the Setup Wizard, please select “Driver” on the main menu. http://www.sapido.com.tw ver. 1.0...
  • Page 6 Step 3. The setup program will install the driver and utility to computer. Please click the “Next” button to continue. Step 4. The setup program is ready to begin installation. Please click the “Install” button. http://www.sapido.com.tw ver. 1.0...
  • Page 7 Step 5. The software installation should begin. This may take a few minutes. Step 6. Once the installation success, click “Yes” to restart your system (recommended). Otherwise, click “No” to restart your system later. http://www.sapido.com.tw ver. 1.0...
  • Page 8 Step 7. Once the installation complete, you may now configure your wireless network. http://www.sapido.com.tw ver. 1.0...
  • Page 9 2. Double click on the computer with wireless signal icon in your taskbar or the shortcut icon on the desktop. 3. It should pop up the Wireless Utility window. And then utility shows the connecting wireless network that connected automatically or was the default network in profile. http://www.sapido.com.tw ver. 1.0...
  • Page 10 (WEP, WPA, WPA2, and etc.) set on your wireless network, simply click the “OK” button and skip to step7. If you do have wireless securities on your wireless network, configure the security setting in “Wireless network security” column. http://www.sapido.com.tw ver. 1.0...
  • Page 11 - If you have WPA-PSK or WPA2-PSK, typically you only enter your key in the “Network Key” and type again to confirm it. - If you have 802.1x configure, typically you only configure your setting in 802.1x configure column. http://www.sapido.com.tw ver. 1.0...
  • Page 12 7. After connected to wireless network, utility will back to “General” page and show the wireless network status. Once the wireless network connected successfully, the Network Address will show the AU-4512S has gotten the IP address from DHCP. 8. Click the “Profile” tab to check the profile page. The wireless network configuration has added in Available Profile(s).

  • Page 13: Configuring Your Wireless Network (With Microsoft Zero Configuration Tool)

    Microsoft Zero configuration tool. 1. Please open the wireless utility. And then enable the “Windows Zero Config” as configuration utility. After enabling the “Windows Zero Config” will pop out a message box, click the “ok” button to continue. http://www.sapido.com.tw ver. 1.0...
  • Page 14 2. Once using Microsoft Zero Configuration Tool to configure wireless network, Wireless Utility will be can not configure. http://www.sapido.com.tw ver. 1.0...

  • Page 15: Wi-Fi Protect Setup (Wps)

    Wi-Fi Protect Setup (WPS) WPS is an easy and secure setup solution for Wi-Fi network. Please click the Wi-Fi Protect Setup tab. AU-4512S has two methods, PIN (Pin Input Config) and PBC (Push Button Config), to setup the network. http://www.sapido.com.tw...

  • Page 16: Pin Input Config (Pin)

    If you want to connect to a specific AP, please click the “Yes” button. Or please click the “No” button to continue and skip to step3. Note: Every time you click the tab to change the page, the PIN code will be changed. http://www.sapido.com.tw ver. 1.0...
  • Page 17 2. Select the specific AP which you want to connect. If you can not find the WPS AP in this page, please click the “Refresh” button. And then click the “Select” button. http://www.sapido.com.tw ver. 1.0...
  • Page 18 3. AU-4512S is waiting for the AP to establish the connection. And then enter the PIN code into the AP that you want to connect. For example, the AP uses BR360n to be the connecting device. Enter the PIN code into client pin number and then clicks the “Start PIN”...
  • Page 19 4. Once the WPS connected successfully, wireless utility will show the connection status. http://www.sapido.com.tw ver. 1.0...

  • Page 20: Push Button (Pbc)

    Note: The PBC button can click the visual button on the page or push the physical button on AP. 2. AU-4512S is waiting for the other AP to start the PBC function. The other AP starts the PBC function should be before AU-4512S WPS times out.

  • Page 21: Radio Off

    3. Once WPS connected successfully, Wireless Utility will show the connection status. Radio Off Enable the Radio Off will turn off the radio function. It means AU-4512S will turn off the wireless function. The wireless network connection will be disconnected. http://www.sapido.com.tw...

  • Page 22: Disable Adapter

    Disable Adapter Disable the AU-4512S adapter will turn off the USB adapter function. It means all functions of AU-4512S will be turn off. http://www.sapido.com.tw ver. 1.0...

  • Page 23: Uninstalling The Software

    2. The uninstall window should pop up. Click on “Yes” button. 3. The uninstall process should begin and may take a few minutes. Once completed, click “Finish” to close the uninstall window. 4. Once it’s complete, click the “Finish” button to exit the uninstall program. http://www.sapido.com.tw ver. 1.0...

  • Page 24: Wireless Zero Configuration Troubleshooting

    If you are Windows XP user and you can not see the check option of “Windows Zero Config”, such as following figure, please do the following steps. 1. Click on your start menu and then click the “control panel” into control panel. Next click the “Administrative Tools”. http://www.sapido.com.tw ver. 1.0...
  • Page 25 2. Click on the “Services” item. http://www.sapido.com.tw ver. 1.0...
  • Page 26 3. It will pop up the Services window. Select the “Wireless Zero Configuration” or “Wireless Configuration” item and double click it. http://www.sapido.com.tw ver. 1.0...
  • Page 27 4. It will pop up the Wireless Zero Configuration Properties window. The “Service status” should be in “Stopped” state now. Click the “Start” button to enable the Wireless Zero Configuration function. http://www.sapido.com.tw ver. 1.0...
  • Page 28 5. Once the setting completes, the “Service status” become to “Started”. Click the “OK” button to finish it and the AU-4512S Wireless Utility can see the check option of “Windows Zero Config”. http://www.sapido.com.tw ver. 1.0...
