- Page 1 Multidea Evo Multidea Evo M WALL-HUNG CONDENSING BOILERS AND HEATING SETS, APPROVED BY I.S.P.E.S.L./I.N.A.I.L. Professional User instructions...
- Page 2 On delivery, the adhesive labels with bar codes supplied in the document envelope should be attached to the specific certificates. CONFORMITY The Multidea Evo appliances comply with: • Gas directive 2009/142/EC • Efficiency Directive 92/42/EEC • Low voltage directive 2006/95/EC •...
-
Page 3: Table Of Contents
INDEX ............SAFETY WARNINGS AND REGULATIONS . -
Page 4: Safety Warnings And Regulations
SAFETY WARNINGS AND REGULATIONS • After unpacking the appliance, ensure that all parts are intact and complete as per the supply specifications, and if any non-conformities are found, contact the Representative that sold the appliance. • The appliance must be installed by professionally qualified personnel, in conformity with current national and local standards and the instructions in the manual supplied with the product. -
Page 5: Description
- reduce noise levels to a minimum. The Multidea Evo boilers are designed for connection to 0-10 V DC controls and for operation in cascade, in sets of up to 6 units, and can be equipped with various system accessories, such as the mix bottle or water shut-off valve, and the ISPESL safety module, which all simplify the work of the installer and comply with compulsory italian legal requirements. -
Page 6: Control Panel
CONTROL PANEL menu Monday, 24. September 2012 09.37 DESCRIPTION OF SYMBOLS ON DISPLAY D.H.W. OPERATING MODE HEATING OUTSIDE OUTSIDE SENSOR HEATING TEMPERATURE REQUEST ACTIVE READING SUPPLY BOILER TEMPERATURE WATER PRESSURE READING SET DATE Monday, 24. September 2012 DOMESTIC HOT WATER SET TIME 09.37 REQUEST ACTIVE... - Page 7 Description offunction Display OPERATING MODES SUMMER: DHW production only OUTSIDE ON OFF Monday, 24. September 2012 09.37 WINTER: heating only or heating and DHW OUTSIDE OUTSIDE Monday, 24. September 2012 Monday, 24. September 2012 09.37 09.37 NONE: no heating or DHW Anti-freeze or “Manual Test”...
- Page 8 Description offunction Display HOLIDAY Holiday start Holiday end 20 / 10 30 / 10 This enables entry of the holiday dates (start/end) 2012 2012 and values for the supply of domestic hot water and heating water during this period to confirm to confirm User menu User menu...
-
Page 9: Ignition And Shutdown
Description offunction Display RED (at bottom) DHW setpoint DHW settings 1. DHW setpoint Enables return to the selected line without saving/ 2. ECO setpoint reduction storing the modified data. 3. Scheduler set to confirm to confirm IGNITION AND SHUTDOWN The initial commissioning of the appliance must be performed by the Technical Services, after which the appliance can operate automatically. -
Page 10: Menu Navigation Trees And Procedures
MENU NAVIGATION TREES AND PROCEDURES User menu navigation TREE and procedure The appliance is supplied in the configuration STAND-BY. To scroll through the screen menus, use the keys shown in the diagram below. date time OUTSIDE MENU OFF OFF STAND-BY User menu screen USER... - Page 11 Factory USER MENU Sub-menu Lines Field Keys Keys Keys settings 20 - max. 1. HEATING 1. CH temperature 75°C absolute T. (*) 1. CH temperature/OTC set 2. Outside temperature OFF / for CH off 7 - 30°C ---> ---> 2. ECO setpoint reduction 50°C 0 - 50°C Enabled/...
- Page 12 Key to the USER menu LINES Ref. menu Line title Meaning line 1. HEATING 1.1.1 CH temperature/OTC set Entry of setpoint of supply temperature (heating) 1.1.2 Outside temperature for CH off Entry of setpoint of outside temperature for automatic switchover to "Summer mode" ECO setpoint reduction Entry of value to reduce temperature on supply in "energy saving"...
-
Page 13: Scheduler Settings
SCHEDULER SETTINGS The system also envisages the option of setting time bands during which the boiler is set to operate, if there is a demand for heat, and those during which it remains off, or in ECO mode when fitted with an outside sensor. There is a maximum of 6 programmable time bands within 24 hours, each of which must be identified by a start time (ON), and end time (OFF). - Page 14 Key to Description Display press Scheduler set Monday-Friday 1. --:-- - --:-- to select the single day or group of days in the week 5. Friday 2. --:-- - --:-- 6. Saturday 3. --:-- - --:-- 7. Sunday 4. --:-- - --:-- 8.
-
Page 15: Temporary Shutdown Or Holiday Schedule
TEMPORARY SHUTDOWN OR HOLIDAY SCHEDULE This function enables a reduction in the operating regime of the boiler in the case of temporary absences, weekends, holidays and above all automatic restart after the set time interval. WARNINGS • During the holiday period, it is essential to leave the electrical and gas mains supplies to the appliance powered, to ensure correct operation. - Page 16 Key to Description Display press Holiday start to return to the initial screen 20 / 10 2012 OUTSIDE OFF OFF to display the “Holiday start” date date to confirm time to set the holiday start day Holiday start Holiday start 30 / 10 30 / 10 2012...
-
Page 17: Maintenance
MAINTENANCE Note that it is a COMPULSORY LEGAL REQUIREMENT THAT THE BOILER SUPERVISOR must arrange for PERIODIC MAINTENANCE and COMBUSTION EFFICIENCY MEASUREMENTS to be performed by PROFESSIONALLY QUALIFIED PERSONNEL. The Technical Services department can fulfil this legal requirement when necessary. PERIODIC MAINTENANCE guarantees: - Increased safety - Reduced operating costs... -
Page 18: Notes
NOTES - 18... - Page 20 008274139 1015 20A4 IT Professional Bongioanni Caldaie S.r.l. Offices - Services and Facilities: Via Piave, 14 12011 Borgo San Dalmazzo (CN) Tel. +39-0171-687816 - Fax +39-0171-857008 www.bongioannicaldaie.it - info@bongioannicaldaie.it...
