IEM 200
UHF wireless system
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IEM 200 and is the answer not in the manual?

Questions and answers

Related Manuals for thomann IEM 200

Summary of Contents for thomann IEM 200

  • Page 1 IEM 200 UHF wireless system user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 17.11.2015, ID: 278192...

  • Page 3: Table Of Contents

    4.2 Transmitter............................19 4.3 Transmitter............................22 4.4 Starting up the system........................24 Components and functions........................ 25 5.1 Transmitter............................25 5.2 Receiver............................... 32 Operating..............................38 6.1 Setting up the transmitter......................38 6.2 Setting up the receiver........................40 Troubleshooting............................45 IEM 200...
  • Page 4 Table of contents Technical specifications........................48 8.1 Transmitter............................48 8.2 Receiver............................... 49 8.3 Frequency charts..........................51 Protecting the environment......................59 UHF wireless system...

  • Page 5: General Notes

    Our products are subject to a process of continuous development. We therefore reserve the right to make changes without notice. Symbols and signal words This section provides an overview of the symbols and signal words used in this user manual. IEM 200...
  • Page 6 General notes Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. CAUTION! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in minor injury if it is not avoided.

  • Page 7: Safety Instructions

    Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices. IEM 200...
  • Page 8 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug.
  • Page 9 NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. IEM 200...
  • Page 10 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
  • Page 11 Safety instructions NOTICE! Possible damage by leaking batteries Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a longer period. IEM 200...

  • Page 12: Features And Scope Of Delivery

    Features and scope of delivery Features and scope of delivery The UHF wireless system IEM 200 is suitable for use as in-ear monitoring system, especially for professional events, on rock stages and concert halls, theatres and musicals. UHF wireless system...
  • Page 13 Features and scope of delivery the t.bone IEM 200 606 MHz Your UHF wireless system IEM 200 606 MHz consists of the following components: (item no. 278192) 9.5" stereo transmitter IEM 200 T – Very high sensitivity at very high signal-to-noise ratio –...
  • Page 14 Features and scope of delivery the t.bone IEM 200 710 MHz Your UHF wireless system IEM 200 710 MHz consists of the following components: (item no. 278283) 9.5" stereo transmitter IEM 200 T – Very high sensitivity at very high signal-to-noise ratio –...
  • Page 15 Features and scope of delivery the t.bone IEM 200 740 MHz Your UHF wireless system IEM 200 740 MHz consists of the following components: (item no. 278284) 9.5" stereo transmitter IEM 200 T – Very high sensitivity at very high signal-to-noise ratio –...
  • Page 16 Features and scope of delivery the t.bone IEM 200 820 MHz Your UHF wireless system IEM 200 820 MHz consists of the following components: (item no. 278285) 9.5" stereo transmitter IEM 200 T – Very high sensitivity at very high signal-to-noise ratio –...

  • Page 17: Installation And Starting Up

    Establish all connections as long as the unit is switched off. Use the shortest possible high- quality cables for all connections. IEM 200...
  • Page 18 For more information, please visit: http://www.thomann.de. Make sure that transmitter and receiver are both tuned to the same channel.

  • Page 19: Transmitter

    XLR/1/4" combo sockets are used for the signal inputs on the transmitter. Drawing and table indicate the XLR pin assignment (balanced wiring) as well as the pin assignment of a suitable 1/4" phone plug. Ground, shielding Positive signal (+) Negative signal (–) IEM 200...
  • Page 20 Installation and starting up Signal Ground, shielding Phone socket for headphones Drawing and table indicate the pin assignment of a 1/8" (top) and 1/4" (bottom) phone plug to outlet be used. Signal (left) Signal (right) Ground, shielding UHF wireless system...
  • Page 21 Set the volume control (6) to a mid position first. To achieve best sound quality, a fine adjustment of this control may be required. If the input level is too high, enable the level attenuation function ( Ä ‘Enabling attenuation’ on page 40). IEM 200...

  • Page 22: Transmitter

    Installation and starting up 4.3 Transmitter Inserting batteries into the receiver Make sure that the main switch / volume control (17) of the receiver is in ‘OFF’ position. Simultaneously press on both snap-in locks of the battery compartment at the side and pull it completely out of the receiver.
  • Page 23 Slide the battery compartment back into the receiver until it clicks into position. Phone socket for earplugs Drawing and table indicate the pin assignment of a 1/8" TRS mini phone plug for stereo use. Signal (left) Signal (right) Ground, shielding IEM 200...

  • Page 24: Starting Up The System

    Installation and starting up 4.4 Starting up the system Make sure that both transmitter and receiver are switched off. The transmitter display is dark; the main switch / volume control (17) is in ‘OFF’ position. Attach the receiver with the clip to your belt or guitar strap. Carefully insert the earplugs into the ear canal, observing the markings ‘L’...

  • Page 25: Components And Functions

    Components and functions Components and functions 5.1 Transmitter Front panel of the transmitter IEM 200...
  • Page 26 Components and functions 1 POWER Main switch to turn the device on or off. For turning on, keep this button pressed for one second. 2 Display. 3, 5 [+] / [–] Buttons for increasing / decreasing the currently indicated value. 4 [SET] Enter button for menu navigation.
  • Page 27 Components and functions 8 PHONES 1/8" mini phone socket (stereo) for headphones connection. 9 PHONES 1/4" phone socket (stereo) for headphones connection. IEM 200...
  • Page 28 Components and functions Rear panel of the transmitter 10 IEC chassis connector for the mains cable with fuse holder. Next to it, the proper operating voltage is indicated. 11 Indication of the frequency range, in which the unit operates. The specification here must match the specification on the rear side of the receiver.
  • Page 29 XLR / 1/4" combo sockets (left and right channel) for direct connection to a mixing console or another audio device that is used as signal source. 14 ANTENNA OUT BNC mounting socket for the supplied UHF antenna. Make sure that the frequency indicated on the antenna matches the frequency range indicated on the transmitter. 15 UHF antenna. IEM 200...
  • Page 30 Components and functions Display of the transmitter A Indicates the frequency that is assigned to the set combination of frequency group and channel. B G / CH Indicates the selected frequency group and the set channel. C ATT-10dB Indicates that the attenuation is turned on. D ST / MONO Indicates the selected operating mode (stereo or mono).
  • Page 31 Components and functions H MODE Flashing while the operating mode is set. I ATT Flashing while the attenuation is set. J LOCK Indicates that the unit is locked to prevent unintentional operation. IEM 200...

  • Page 32: Receiver

    Components and functions 5.2 Receiver Front panel of the receiver 16 Flexible antenna. 17 OFF/ON/VOL Main switch and volume control. Turn this knob clockwise past the point of resist‐ ance to turn on the receiver. Turn it further to increase the volume. Turn this knob counter-clockwise to reduce the volume.
  • Page 33 Components and functions 22, 23 + / – Buttons to increase or decrease the currently shown value. 24 Fasteners of the battery compartment for two AA cells (LR6, 1.5 V) or comparable rechargeable batteries. IEM 200...
  • Page 34 Components and functions Top panel of the receiver 16 Flexible antenna. 17 OFF/ON/VOL Main switch and volume control. Turn this knob clockwise past the point of resist‐ ance to turn the receiver on. Turn it further to increase the volume. Turn this knob counter-clockwise to reduce the volume.
  • Page 35 25 Clip to attach the transmitter to the guitar strap or your body, e.g. to the belt. 26 Indication of the frequency range in which the device operates. The specification here must match the specification printed on the back of the transmitter. IEM 200...
  • Page 36 Components and functions Display of the receiver K STEREO Indicates the selected operating mode (stereo or mono). L Radio signal strength indicator (one to five bars). M Indicates that the unit is locked to prevent unintentional operation. N HF Indicates the activated high frequency boost function. O LTD Indicates that the overload protection (dynamic limiter) is turned on, preventing clipping and volume peaks.
  • Page 37 Components and functions R Indicates the frequency that is assigned to the set combination of frequency group and channel. S G: / CH: Indicates the selected frequency group and the set channel. IEM 200...

  • Page 38: Operating

    Operating Operating 6.1 Setting up the transmitter Selecting frequency group and Keep [SET] pressed for some seconds until the field ‘FREQ’ is flashing in the top row of the dis‐ channel play. Press [SET] again until the field ‘GROUP’ is flashing in the top row of the display and the field ‘G’...
  • Page 39 Press [SET] again until the field ‘MODE’ is flashing in the top row of the display. Use the [+] / [–] buttons to toggle between mono and stereo operation. When the desired mode is shown, press [SET] to confirm the setting and to quit the menu. IEM 200...

  • Page 40: Setting Up The Receiver

    Operating Enabling attenuation Keep [SET] pressed for some seconds until the field ‘FREQ’ is flashing in the top row of the dis‐ play. Press [SET] again until the field ‘ATT.’ is flashing in the top row of the display. Use the [+] / [–] buttons to turn a 10 dB attenuation on or off. When the desired mode is shown, press [SET] to confirm the setting and to quit the menu.
  • Page 41 Transmitter and receiver must be set to the same combination of frequency group and channel. If you use multiple wireless systems from this device family, for best results you should assign all systems to the same frequency group, but give each system a different channel. IEM 200...
  • Page 42 Operating Setting the frequency directly As an alternative to selecting the frequency group and channel, you can also adjust the trans‐ mission frequency directly. Select the menu item ‘1. Frequency’ . Press [SET]. ‘Frequency’ appears in the top row of the dis‐ play.
  • Page 43 ‘OFF’ ) operation. In locked mode, the system settings can be viewed, but not changed. The display shows a key symbol then. When the desired mode is shown, press [SET] to confirm the setting and to leave this menu item. IEM 200...
  • Page 44 Operating Setting the display contrast Select the menu item ‘7. Contrast’ . Press [SET]. The display shows a symbolic slider. Use the [+] / [–] buttons to change the contrast in a range of –3 and +3. When the display has the desired contrast, press [SET] to confirm the setting and to leave this menu item.

  • Page 45: Troubleshooting

    Troubleshooting Troubleshooting In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: IEM 200...
  • Page 46 Troubleshooting Symptom Remedy No sound 1. Check the power supply of the transmitter and receiver. 2. Make sure that both transmitter and receiver operate in the same frequency range and that the transmitting antenna is designed for this frequency range. The frequency range is stated on the devices.
  • Page 47 The sound is distorted 1. Change the ‘VOLUME’ setting on the transmitter. 2. Turn the overload protection on. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. IEM 200...

  • Page 48: Technical Specifications

    Technical specifications Technical specifications 8.1 Transmitter Input 2 × XLR / 1/4" combo sockets (balanced) Headphones outlet 1/4" phone and 1/8" mini phone sockets (stereo) Modulation type Frequency modulation (FM) Transmission level 10 dBm Transmission power 10 mW Input impedance 20 kΩ...

  • Page 49: Receiver

    Dimensions (W × D × H, without antenna) 212 mm × 220 mm × 44 mm (1 RU) Weight 1450 g 8.2 Receiver Modulation type Frequency modulation (FM) Image frequency rejection > 60 dB Sensitivity –102 dBm @ 12 dB SINAD, typical IEM 200...
  • Page 50 Technical specifications Audio output level 100 mW Operating supply voltage 2 × AA cells (LR6, 1.5 V) Dimensions (W × D × H, without antenna) 75 mm × 130 mm × 25 mm Weight (without batteries) 200 g UHF wireless system...

  • Page 51: Frequency Charts

    612.250 MHz 612.875 MHz 614.000 MHz Channel 9 Channel 10 Channel 11 Channel 12 Channel 13 Channel 14 Channel 15 Channel 16 614.875 MHz 616.250 MHz 619.250 MHz 620.000 MHz 621.625 MHz 622.750 MHz 624.250 MHz 629.750 MHz IEM 200...
  • Page 52 Technical specifications the t.bone IEM-200 606 MHz – 630 MHz (item no. 278192) Frequency group C Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 607.125 MHz 607.750 MHz 608.625 MHz 609.750 MHz 610.500 MHz 612.125 MHz 612.875 MHz...
  • Page 53 716.250 MHz 716.875 MHz 718.000 MHz Channel 9 Channel 10 Channel 11 Channel 12 Channel 13 Channel 14 Channel 15 Channel 16 718.875 MHz 720.250 MHz 723.250 MHz 724.000 MHz 725.625 MHz 726.750 MHz 728.250 MHz 733.750 MHz IEM 200...
  • Page 54 Technical specifications the t.bone IEM-200 710 MHz – 734 MHz (item no. 278283) Frequency group C Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 711.125 MHz 711.750 MHz 712.625 MHz 713.750 MHz 714.500 MHz 716.125 MHz 716.875 MHz...
  • Page 55 746.250 MHz 746.875 MHz 748.000 MHz Channel 9 Channel 10 Channel 11 Channel 12 Channel 13 Channel 14 Channel 15 Channel 16 748.875 MHz 750.250 MHz 753.250 MHz 754.000 MHz 755.625 MHz 756.750 MHz 758.250 MHz 763.750 MHz IEM 200...
  • Page 56 Technical specifications the t.bone IEM-200 740 MHz – 764 MHz (item no. 278284) Frequency group C Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 741.125 MHz 741.750 MHz 742.625 MHz 743.750 MHz 744.500 MHz 746.125 MHz 746.875 MHz...
  • Page 57 826.250 MHz 826.875 MHz 828.000 MHz Channel 9 Channel 10 Channel 11 Channel 12 Channel 13 Channel 14 Channel 15 Channel 16 828.875 MHz 830.250 MHz 833.250 MHz 834.000 MHz 835.625 MHz 836.750 MHz 838.250 MHz 843.750 MHz IEM 200...
  • Page 58 Technical specifications the t.bone IEM-200 820 MHz – 844 MHz (item no. 278285) Frequency group C Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 821.125 MHz 821.750 MHz 822.625 MHz 823.750 MHz 824.500 MHz 826.125 MHz 826.875 MHz...

  • Page 59: Protecting The Environment

    Batteries must not be disposed of as domestic waste or thrown into fire. Dispose of the bat‐ teries according to national or local regulations regarding hazardous waste. To protect the environment, dispose of empty batteries at your retail store or at appropriate collection sites. IEM 200...
  • Page 60 Protecting the environment Disposal of your old device This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE). Do not dispose with your normal household waste. Dispose this device through an approved waste disposal firm or through your local waste facility.
  • Page 61 Notes IEM 200...
  • Page 62 Notes UHF wireless system...
  • Page 64 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
