- Page 2 120Hz 3KHz GAIN GAIN CH1/CH2 CH3/CH4 G1-50x4G Before installing the power amplifier please read this instruction manual carefully. The INPUT instructions for mounting and connecting the set have to be followed precisely. If necessary, a service center should be consulted.
- Page 3 PRECAUTIONS WIRING INSTRUCTIONS This unit is designed for negative ground 12V DC operation only. POWER CONNECTION Use speakers with an impedance of 2 or 4 Ohms (4 to 8 Ohm when used as bridged The battery terminal (BATT) must be connected directly to the positive terminal of the ...
- Page 4 INPUT WIRING DIAGRAM STEREO MODE SPEAKER SPEAKER 2~4 Ohm 2~4 Ohm BRIDGED +12V FUSES G1-50x4G BRIDGED SPEAKER SPEAKER 2~4 Ohm 2~4 Ohm FLAT FLAT 12dB 12dB LPF CROSSOVER BASS BOOST BASS BOOST CROSSOVER MODE BRIDGED MODE PWR/PRT 120Hz 3KHz 50Hz 250Hz...
- Page 5 POWER CONNECTION LEADS OPERATION After the amplifier has been installed and all connections have been made carefully and securely, turn the radio on so that the amplifier is switched on automatically. After a short power-on period, the amplifier reaches its full performance. POWER Now turn up the volume slowly using the volume control of the radio.
- Page 6 OPERATION INTERFERENCE GND(-) = GROUND CONNECTION All cables are sources of interference or gather them. The power cable and Cinch/RCA Connect the GND terminal to the chassis ground of your car and take care of best audio cable are very prone to interference; the remote cables are less prone. There is ...
