- Page 1 KXT 481 SOS Instruction manual – English...
-
Page 2: Table Of Contents
1 Installation: ..............2 5.4. Delete a caller ID number ........12 1.1 Where to install the emergency phone ....2 5.5. Delete all of caller ID numbers ......12 1.2 Install battery of the telephone backup ....2 6. Phonebook management ...........13 1.3 To Replace the battery of Pendant......3 6.1. -
Page 3: Installation
1 Installation: 1.1 Where to install the emergency phone When install the emergency phone, consider that the unit should be within the range of emergency pendant, therefore placed in an area of a common use during day and night. The range of pendant is reduced by the structural obstacles and has a range up to 40meters in open field. -
Page 4: To Replace The Battery Of Pendant
1.3 To Replace the battery of Pendant The pedant is equipped with a pre-installed 12V DC internal battery. Each time the red key is pressed, the LED will light to show correct transmission. In the case, LED does not light on, please replace battery with new one. -
Page 5: Product Layout
2 Product layout... - Page 6 Key Name Key description Key Name Key description HOOK REDIAL/P SWITCH SCREEN 3-line display. Top line segment DISPLAY for Time and icon; Middle line segment for 14-digits number; LED light on while the telephone is IN-USE LED Bottom line dot matrix for off-hook mode.
- Page 7 Key Name Key description Key Name Key description In number and character input It is used to memory some important mode, press the key to delete number , like as Police and hospital one digit or a letter; in menu HOT KEY 1 number.
-
Page 8: Basic Functions Of Telephone
3 Basic Functions of Telephone 3.1 Make a call Pick up the handset or press hands-free key, you can hear the dial tone from earpiece or speaker if line is connected. Input the desired desired number to make a call. If the dialed number over 14digits, it will show the last 14digits only. -
Page 9: Emergency Feature
During inputting number, press “DEL” key to delete wrong inputting digit one by one. 3.4 Emergency Feature User friendly big button phone with emergency call feature, special designed for senior people living alone. It supply a separate “SOS” key on the top surface of telephone , also supply a red key on wireless pendant for making emergency call. -
Page 10: Last Number Redial
Note: If not set any emergency call, can not dial out any call when start emergency call function, only hearing the loud local alarm for 15 seconds, 3.5 Last number redial Pick up the handset or press “hands-free” button, then press “REDIAL/P” key, the telephone will automatically dial out the last dialed number. -
Page 11: Adjust Ringer Volume
Hands-free volume key is set on the right edge of the telephone, slide the key to continuously adjust hands-free volume. 3.10 Adjust ringer volume Ringer volume switch is set on the rear edge of the telephone. There are 3 volume level with low/middle/ high symbol . -
Page 12: Caller Id Management
record his own voice (up to 20seconds). H). FLEXIBLE PHONEBOOK EMERGENCY LIST WITH PRIORITY SETTING: when a telephone number is stored in phonebook list, user can decide if the number is an emergency number (on/off) and which position in priority list to assign( from 1 to 5, phonebook can store 30 groups number, only 5 groups can be added into emergency list once). -
Page 13: View The Caller Id List
If the caller ID number is withheld, “Withheld” will be displayed. If the caller ID number is unavailable, “Out Of Area” will be displayed. 5.1 View the Caller ID List In idle mode, press key to view caller ID list. All unanswered and answered calls are saved in the caller ID list. -
Page 14: Phonebook Management
6. Phonebook management You can store up to 30 groups of phonebook entries in the telephone memory, with maximum 22digits for number and 16characters for name. While phonebook memory is full and you want to add more a phonebook, screen shows “MEMORY FULL”, you must delete one phonebook entry, then add new phonebook entry. -
Page 15: Store A Number On Hot Key 1 Or Hot Key 2
6.4. Store a number on HOT key 1 or HOT key 2 Enter main menu of “STORE NUMBER”, press “OK/DIAL” key to enter, input number (up to 22digits), press HOT key 1 or HOT key 2, then press “OK/DIAL” key again, screen show “SAVED” to tell storing success. -
Page 16: Lcd Contrast Setting
During submenu settings, press “DEL” key to go backward to upgrade level menu, press “CID/ESC” key to exit menu setting and return to idle mode. After entering menu setting, if wait 30seconds without next operating, screen will return to idle mode. 7.1. -
Page 17: Name Recording Setting
7.4. Name Recording setting “Name Recording” is to record user own voice for phonebook entry, the voice will be playback while an incoming call is from the phonebook entry. Enter “NAME RECORDING”, press “OK/DIAL” key, screen show phonebook list, select one phonebook entry, then press and hold “OK/DIAL” key, “VOICE” is flashing on the top line of screen, user can record voice 3seconds. -
Page 18: Voice Setting
Select main menu option of “LCD LANGUAGE”, then press “OK/DIAL” key to enter language options, press key to select language for LCD display, there are 11 kinds of languages on the phone. Please note: if user select language from Italian/English/ French/ German/ Spanish from LCD display, the voice type of talking caller ID, pre-dialing, menu prompt and SOS message are also correspondingly changed. -
Page 19: Pair New Pendant
7.11. Pair New Pendant By this menu, user can pair up to 5 pendants to the telephone for emergency call. Please one emergency pendant has already been paired to the telephone, you need not re-pair it before using the pendant. Select main menu option of “PAIR NEW PENDANT”, press “OK/DIAL”...
