IMPORTANT SAFETY INSTRUCTIONS
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS. Failure
to follow all instructions listed below, may result in electric
shock, fire and/or serious personal injury.
WARNING:
Changes or modifications to this unit not expressly
approved by the party responsible for compliance could
void the user's authority to operate the equipment.
WARNING:
Use of controls, adjustments, or performance of
procedures other than those specified here can results
in hazardous radiation exposure.
 Read operator's manual carefully. Learn the applica-
tions and limitations, as well as the specific potential
hazards, related to this device. Following this rule will
reduce the risk of electric shock, fire, or serious injury.
 Do not operate battery devices in explosive atmo-
spheres, such as in the presence of flammable liquids,
gases or dust. Battery devices create sparks which may
ignite the dust or fumes.
 Do not disassemble the device. Contact with internal
parts may increase the risk of electric shock or cause
damage to the device.
 Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
device in unexpected situations.
 Do not store the device in an area of high heat or
humidity. Do not expose the device to extended high
heat from the sun (such as on a vehicle dashboard.)
To reduce the risk of serious personal injury, do not
store outside or in vehicles. Damage to the device or
the battery can result.
App images may vary.
Thank you for purchasing RYOBI
TM
TM
This app is optimized for:
For a full list of compatible phones please visit
www.ryobitools.com/phoneworks
ES2000 INFRARED THERMOMETER
If you need assistance
DO NOT RETURN TO THE STORE
Please contact us at 1-877-578-6736
 Do not expose device to rain or wet conditions. Water
entering a device will increase the risk of electric shock.
 Use the device in accordance with these instructions
and in the manner intended for the device, taking into
account the environmental conditions and the work to
be performed. Use of the device for operations different
from those intended could result in a hazardous situation.
 Do not use as a precision thermometer.
 Do not use the thermometer for medical evaluations
or to measure body temperature. This device is meant
for household use only.
1 – English
Phone Works
Aperture
990000989
10-3-14 (REV:01)

Advertisement

Table of Contents
loading

Summary of Contents for Ryobi ES2000

  • Page 1 Thank you for purchasing RYOBI Phone Works ™ ™ If you need assistance DO NOT RETURN TO THE STORE Please contact us at 1-877-578-6736 This app is optimized for: iOS versions 6.0 and higher ∙ Android versions 4.0 and higher For a full list of compatible phones please visit www.ryobitools.com/phoneworks...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS  The laser guide radiation used in the device is Class  Do not mix old and new batteries or different brands IIIa, <5 mW, 630-670nm wavelengths. of batteries.  Avoid direct eye exposure when using the laser and ...
  • Page 3 SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this device. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will result DANGER: in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could result WARNING: in death or serious injury.
  • Page 4 FEATURES ICON DESCRIPTION / FUNCTION ICON DESCRIPTION / FUNCTION Main RYOBI Phone Works app home ™ ™ Camera ON screen Camera OFF Laser is ON Note Laser is OFF File cabinet (stored projects) Take a picture Settings Device battery charge level...
  • Page 5: Operation

    CONNECTING THE IR THERMOMETER TO YOUR SMARTPHONE See Figure 3.  Insert the smartphone into the clip and make sure it is securely attached before use.  Select and open the RYOBI Phone Works app. ™ ™  Insert the device’s plug into your smartphone’s head- phone jack.
  • Page 6: Taking Temperature Readings

    OPERATION Turn the volume on your smartphone to its maximum set- Fig. 4 ting. Some phones have features that limit the amount of volume available. Turn these features off before you at- tempt to use the device. For the most accurate readings: ...
  • Page 7 OPERATION Fig. 7 MANAGING YOUR PROJECTS See Figure 7. To add, edit, delete or share your images: Tap the project name in the top right corner. A menu appears showing Add New, Edit, Use Existing or Cancel. Add New  Tap Add New and enter the name of your new project. ...
  • Page 8: Sharing Projects

    OPERATION PROJECT FOLDER SUMMARY Fig. 12 See Figure 10.  The file cabinet may be accessed from the RYOBI ™ Phone Works home screen or from any app segment. ™  Accessing the file cabinet from the home screen will dis- play all projects and icons representing the app segments used for each project.
  • Page 9 Swipe to reveal the DELETE option and select DELETE. GLOBAL SETTINGS/SETTINGS See Figure 14.  Tap the Settings icon on the RYOBI Phone Works ™ ™ home screen to make changes based on your preferenc-  Settings specific to some app segments can only be changed within the app segment.
  • Page 10: General Maintenance

    MAINTENANCE BATTERY RECYCLING WARNING: Consult the Earth 911 website (www.earth911.com) or your When servicing, use only identical replacement parts. local waste authority for information regarding available Use of any other parts could create a hazard or cause recycling and/or disposal options. device damage.
