American Dynamics Control Center ADCC0200 Quick Reference Manual

Keyboard Settings
The default setting for the keyboard is RS485 mode at 19200 baud. To change these settings,
enter the Special Config menu by pressing SHIFT (
seconds of powering up the keyboard. Then press one of the following:
to change baud rate.
to change the mode (ADNet RS485, RS232).
to select Auto Repeat or Make/Break mode. See the matrix manual for correct setting.
to enable/disable the speaker.
Standard Matrix Operations
FEATURE
Select Monitor
Select Camera
Select Matrix/Site
Telemetry Enable/Disable
Pan Left/Right
Tilt Up/Down
Zoom In
Zoom Out
Focus Near
Focus Far
Iris Open
Iris Close
Flip
Engage Auto Iris
Engage Auto Focus
Select Preset
Record Preset
Manually Trigger Alarm
Acknowledge Alarm
Select Sequence
Select View
Select Salvo
ControlCenter
