CHAPTER 6: FUNCTIONS (FUNCTION MODE)
Accessing the Dual-Rate Function (continued)
Note: You can observe the servo changes by
moving the respective stick while increasing or
decreasing the values. The control changes
accordingly. To clear the dual rate for the respective
channel and switch position, press the Clear
key. After the dual rates have been dialed in
to your satisfaction, we suggest that you begin
to adjust the exponential values. Refer to the
Exponential section for more information.
Automatic Dual-Rate
If the Automatic Dual-Rate function AUTO is active
(on), when switching the flight mode switch, aileron,
Exponential
Servo Reversing
To access this function, move to the D/R (Dual-Rate)
screen, and press the Channel button until the word
"AUTO" appears at the top center of the screen, with a
small box with the number 1 to the far left. This would
indicate the Auto D/R function for Flight mode 1. Press
the (+) or (-) keys to turn the function on or off. Repeat
this procedure for flight modes 2 and
34
•
7. To access the Servo Reversing function, press
the Down key.
8. To access the Exponential function, press the
Up key.
9. To exit the Dual-Rate function, press the Down and
Channel keys simultaneously.
elevator and rudder channel Dual-Rate values are
switched to preset values settled by position 1.
Flight mode position to be adjusted
Condition (off or on)
Press the (+) or (-)
keys to turn the
Auto D/R function
Press Channel to
select the desired on or off.
flight mode to adjust
(1,2 or HO).
Hold (HO).To confirm that the Auto D/R is
functioning, simply move the flight mode switch
while at any of the normal D/R channel screens. If
the Auto D/R is functioning, the screen will indicate
D/RAT, and the D/R switch position at the far right of
the screen will change from 0 to 1 as the switch
is moved.
Flight mode position to
be adjusted
Press Clear to return to the
factory default setting (off).
