Key Phone
MC-50
Operation
Manual
Content
I .Introduction ------------------------------------------------------------ 1
II. Technical Parameter -------------------------------------------------------------2
III. Function Key Introduction --------------------------------------------------------3
IV. Operation Instruction------------------------------------------------------------4
1
Advertisement
Table of Contents
Related Manuals for Miracall Technology mc-50
Summary of Contents for Miracall Technology mc-50
- Page 1 Key Phone MC-50 Operation Manual Content I .Introduction ------------------------------------------------------------ 1 II. Technical Parameter -------------------------------------------------------------2 III. Function Key Introduction --------------------------------------------------------3 IV. Operation Instruction------------------------------------------------------------4...
-
Page 2: Technical Parameter
I. Introduction MC-30 is a new kind of digital key phone developed by Miracall Technology Co.Ltd., specially for MC-A100 and MC-832KA, KB, which has inherit traditional group phone merit and much bold innovation. It can be connected with Ear Phone, Incoming Call Light, LED, and it’s inner structure and outline is designed elaborately and so on. - Page 3 III Function Key CHK/CLR To enter into system program mode/ delete the data or return to normal mode. TH/TL KEY For navigating caller ID numbers and checking 50 groups number in unit . PAGE Key For paging external loud speaker and key phones. CONF Key For making a conference call.
- Page 4 when the lamp lights. And for switching to answer automatically in hook-on status when the lamp lights. TRFR Key For transferring incoming call to another Extension .System can switch to night service mode when the key is pressed in hook-on status. The function can be realized by the key phone connected on port No. 001.
- Page 5 IV. Operation Instruction All below operation is based on CO Line Dialing tone when off-hook: Function Operate Code Intercom Call ICM +ext. number Dial Outside Off-hook + CO line number Call Transfer DRFR + ext. + on-hook Call on hold HOLD Retrieve a call By local ext: ICM + “44”...
- Page 6 How to program keys? 1.CO Line port setting: press CHK twice, EXT PROG MODE, press desired key, then press “1”, LINEX, then input 2-digits CO line series number, press HOLD and CLR ,exit. 2. EXT port setting: press CHK twice, EXT PROG MODE, press desired key, then press “2”, PORT XXX EXT XXXX, then then input 3-digits EXT port number, press HOLD and CLR ,exit.
