RR1A / RR2A Remote
Quick Start Guide
INSTALLER:
Leave these instructions with consumer.
CONSUMER:
Retain for future reference.
This guide serves as a supplement to any remote information found in the burner, pilot kit, and remote instructions.
Read all instructions completely and carefully prior to product use. Select models shown, design may vary.
I
INSTALL BATTERIES
Remote Transmitter
• Remove lid.
• Install "12V" battery (included).
• Re-secure lid.
II
INSTALL WALL MOUNT (IF APPLICABLE)
Wall Mount
• For wall mounting: refer to the remote
instructions for install details.
• Route the wires to the fi replace and proceed
to the following CONNECT TO VALVE
section.
Important: DO NOT install 120VAC wires to
remote receiver.
REV 0 - 1411031020
(Remove
lid)
Receiver
button
1
Remote Receiver
• Remove lid.
• install four "AA"
batteries (included).
• Re-secure lid.
slide
Remote
receiver
Cover plate
WALL
Plastic switch box
(not included)
L-A2-390
