- Page 1 NAVMAN DEPTH NAVMAN...
-
Page 2: Table Of Contents
Setting Alarms ......................8 Set Shallow Alarm ..................... 8 Set Deep Alarm ......................8 Secondary Functions ..................... 9 Set Display Dampening ..................... 9 Keel Offset ........................9 Simulation Mode ......................9 Troubleshooting Chart ....................10 D100/ENG/1C NAVMAN D100 User Manual... -
Page 3: Specifications
Display is backlit for Depth is decreasing Night Operation Indicates alarm is on Depth is decreasing FEET MTRS FATH SHALLOW DEEP Deep Alarm Indicate depth units Set/Indicator DEPTH Shallow Alarm Alarm On/Off Set/Indicator Change Value Down Change Value Up NAVMAN D100 User Manual... -
Page 4: Installation
Installation Location Mounting The NAVMAN D100 is designed for above or The mounting surface must be flat. Use the below deck installation. Select a position that is: template to set the centre of the fixing hole. • At least 300mm from a compass •... -
Page 5: Wiring Connection
NMEA output to repeater Depth Transducer Multiple Instruments The NAVMAN D100 may be used as an individual instrument or connected with a number of other 100 series instruments to the 100 series repeater or to other instruments accepting NMEA 0183 data. -
Page 6: Operation
FATH MTRS Backlighting On / Off Simultaneously press the keys to FEET MTRS FATH turn the backlight on. Repeat this procedure to turn the lighting off. FEET MTRS FATH SHALLOW DEEP FEET MTRS FATH SHALLOW DEEP NAVMAN D100 User Manual... -
Page 7: Setting Alarms
Set Shallow Alarm MTRS SHALLOW Use the keys to set alarm value. Press the key to exit. Set Deep Alarm MTRS DEEP Use the keys to set alarm value. Press the key to exit. NAVMAN D100 User Manual... -
Page 8: Secondary Functions
Set Display Dampening Keel Offset Rough water conditions, schools of fish and The NAVMAN D100 will normally display the thermal layers cause erratic depth readings. depth of water below the face of the transducer. Display dampening controls the rate that the... -
Page 9: Troubleshooting Chart
3. Add alternator whine filter to alternator. 4. Replace spark plug wire with resistive type. Simulation Mode At power up, if all the segments display for 5 seconds then the instrument is in simulation mode. NAVMAN D100 User Manual... - Page 10 3 feet. It is recommended to use the lowest number possible if shallow water performance is important. It must also be noted that in situations where the D100 is tracking the bottom and displaying a consistent depth but occasionally...
