Summary of Contents for thomann harley benton
- Page 1 Powerplant power supply user manual...
- Page 2 Musikhaus Thomann e.K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 26.02.2013...
-
Page 3: Table Of Contents
Table of contents Table of contents General notes............................... 4 Safety instructions............................. 6 Installation and starting up........................ 10 Components and functions........................ 13 Technical specifications........................16 Protecting the environment......................17 Powerplant... -
Page 4: General Notes
General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to other users, be sure that they also receive this manual. - Page 5 General notes Symbols and signal words This section provides an overview of the symbols and signal words used in this user manual. Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided.
-
Page 6: Safety Instructions
Safety instructions Safety instructions Intended use This device transforms mains voltage into safety extra-low voltage, e.g. for the voltage supply of effects pedals. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 7 Safety instructions Safety DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit.
- Page 8 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician.
- Page 9 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
-
Page 10: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 11 Installation and starting up 8 standard cables (1:1), plug-to-plug, length 55 cm, each to supply one effects pedal with DC 9 V , black/white, inner contact = minus pole. 2 standard cables (1:1), plug-to-plug, length 35 cm, each to supply one effects pedal with DC 12 V or AC 12 V respectively, 1 ×...
- Page 12 Installation and starting up 1 adapter cable with 1/8" mini phone plug (1:1), plug-to-socket, length 35 cm, to supply one effects pedal. 3 adapter cables plug-to-socket to change the polarity of the inner contact from minus to plus pole, length 20 cm. power supply...
-
Page 13: Components And Functions
Components and functions Components and functions Connection panel Powerplant... - Page 14 Components and functions 1 Outlet sockets for the power supply of effects pedals with DC 9 V . 2 POWER Blue pilot LED. Indicates that the device is connected to the power grid. The LED turns off a few seconds after the device is disconnected from the mains power supply.
- Page 15 Components and functions Left side view 5 POWER ON|OFF Mains power switch to turn the device on or off. 6 MAINS VOLTAGE IEC chassis plug with fuse holder for power supply. Powerplant...
-
Page 16: Technical Specifications
Technical specifications Technical specifications Operating supply voltage AC 230 V , 50 Hz Fuse 0.1 A / 250 V (fast-acting) Power consumption 1.54 W Output voltage 8 × DC 9 V , max. 500 mA in total 1 × DC 12 V , max. 250 mA 1 ×... -
Page 17: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 18 Notes power supply...
- Page 20 Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
