VISIO D50u-D1 User Manual

Hide thumbs Also See for D50u-D1:
Table of Contents

Advertisement

Quick Links

Download this manual
VIZIO
USER MANUAL
Models D50u-D1 and D55u-D1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D50u-D1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VISIO D50u-D1

Summary of Contents for VISIO D50u-D1

  • Page 1 VIZIO USER MANUAL Models D50u-D1 and D55u-D1...
  • Page 2 Safety & Certification   THANK YOU FOR CHOOSING VIZIO IMPORTANT SAFETY INSTRUCTIONS • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, And congratulations on your new VIZIO HDTV. Your TV is designed and manufactured to operate within defined use caution when moving the cart/apparatus design limits.
  • Page 3 • Do not apply pressure or throw objects at your TV. This may • Do not use your TV if any abnormality occurs. If any smoke • The mains plug or appliance coupler is used as the compromise the integrity of the display. The manufacturer’s or odor becomes apparent, unplug the power cord and disconnect device, the disconnect device shall remain warranty does not cover user abuse or improper...
  • Page 4 TELEVISION ANTENNA CONNECTION PROTECTION If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges. Ground Clamp Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides Antenna Lead In Wire...
  • Page 5 For DTS patents, see http://patents.dts.com. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Manufactured under license from DTS Licensing Limited. Laboratories. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS Studio Sound is a trademark of DTS, Inc.

  • Page 6: Table Of Contents

    Table Of Contents Table Of Contents Getting to Know Your TV ..........7 Deleting the Custom Audio Mode ..........32 Changing the DLNA Name of Your TV ..........46 Setting Timers ..................33 Adjusting the CEC Settings ..............46 Inspecting the Package Contents ............7 Setting the Sleep Timer ..............33 Turning the Power Indicator On or Off ..........46 Installing the TV ..................8 Setting the Auto Power Off Feature ..........33...

  • Page 7: Getting To Know Your Tv

    Getting to Know Your TV INSPECTING THE PACKAGE CONTENTS Before installing your new TV, take a moment to inspect the package contents. Use the images below to ensure nothing is missing or damaged. VIZIO LED UHDTV Power Cord Remote Control with Batteries 4 x Phillips Screws TV Stands...

  • Page 8: Installing The Tv

    INSTALLING THE TV To install the stands: After removing the TV from the box and inspecting the package contents you can begin installing the TV. Your TV can be installed in two ways: • On a flat surface, using the included stand •...

  • Page 9: Installing The Tv On A Wall

    To mount your TV on a wall, you will need a wall mount. Consult the information below to find the appropriate mount for your TV model: Installing a TV on a wall requires lifting. To prevent injury or damage to the TV, ask someone to help you. D50u-D1 D55u-D1 Screw Size: Hole Pattern:...

  • Page 10: Front Panel

    REMOTE SENSOR & POWER INDICATOR When using the remote, aim it directly at this sensor. The power indicator flashes on when the TV turns on, then goes out after several seconds. To keep the power indicator on as long as the TV is on, see Turning the Power Indicator On or Off on page 46. FRONT PANEL...

  • Page 11: Rear Panel

    USB - Connect a USB thumb drive to play photo, music, or video. HDMI - Connect an HDMI device. Component/Composite - Connect a component or composite device. HDMI - Connect an HDMI device. Optical Audio Out - Connect an optical/SPDIF audio device, such as home audio receiver. Stereo Audio Out - Connect an RCA audio device, such as sound bar.

  • Page 12: Remote Control Front

    Replacing the Batteries APP LAUNCHER Quickly launch the pictured App. INPUT POWER Change the currently Turn TV on or off. displayed input. A/V CONTROLS Control the USB media player and MENU streaming video playback. Display the on-screen menu. CLOSED CAPTIONS INFO Turn closed captions on and off.

  • Page 13: Connecting Your Devices

    Connecting Your Devices CONNECTING A DEVICE Your TV can be used to display output from most devices. 1. Verify that your device has a video port that matches an available port on the TV (HDMI, Component, etc.). 2. Turn the TV and your device off. 3.

  • Page 14: Connecting A Device - Audio & Video Cable Types

    CONNECTING A DEVICE - AUDIO & VIDEO CABLE TYPES AV CABLE COAXIAL CABLE COMPONENT CABLE HDMI CABLE AV cables (or Composite cables) are the Coaxial cables are the traditional way of Component cables are designed to carry high HDMI is the intelligent, all-digital interface that definition video signals along with additional delivers both dazzling quality and unmatched ease traditional way of connecting your devices to...

  • Page 15: Connecting An Audio Device

    CONNECTING AN AUDIO DEVICE Your TV can output sound to an audio device, such as a receiver or sound bar. 1. Verify that your device has an audio port that matches an available port on the TV (Optical, RCA, or HDMI). 2.

  • Page 16: Connecting An Audio Device - Audio Cable Types

    CONNECTING AN AUDIO DEVICE - AUDIO CABLE TYPES RCA CABLE OPTICAL/SPDIF CABLE HDMI CABLE cables Composite cables) Optical/SPDIF cables transmit audio signals as HDMI technology transmits crystal-clear digital traditional way of connecting your devices to your pulses of light through a cable made of plastic multi-channel surround audio through a single audio device.

  • Page 17: Connecting An Audio Device - Arc

    CONNECTING AN AUDIO DEVICE - ARC Without HDMI ARC With HDMI ARC With an HDMI ARC setup, the audio connection between your Without an HDMI ARC setup, your TV will transmit audio signal TV and Home Audio Receiver can be removed. The HDMI cable from the built-in tuner and VIA apps to your home audio receiver will transmit audio signal to and from your TV with an all-digital through a separate audio connection.

  • Page 18: Connecting To Your Network

    CONNECTING TO YOUR NETWORK Your TV is Internet-ready. It can be connected to your home network Connecting to a Wireless Network with a Wired or Wireless connection. 1. Ensure you have a router or modem broadcasting as high-speed wireless signal (802.11n recommended). Connecting to a Wired Network (Best) 2.

  • Page 19: Completing The First-Time Setup

    Completing The First-Time Setup The first time you turn on the TV, the Setup App will guide To complete the first-time setup: you through each of the steps necessary to get your TV ready for use. Before you begin the first-time setup: •...
  • Page 20 Select your time zone and press OK. Select the name of your wireless network from the Use the Arrow and OK buttons on the remote to list of available networks and press OK. review the Terms Of Service and Privacy Policy. When you are finished, highlight I Accept and press OK.
  • Page 21 Use the Arrow buttons on the remote to highlight If the TV Signal channel scan screen appears, the your TV source and press OK. TV will need to scan for channels, which takes several minutes. Use the arrow buttons on the remote to highlight Begin Scan and press OK.

  • Page 22: Using The On-Screen Menu

    Using the On-Screen Menu NAVIGATING THE ON-SCREEN MENU CHANGING THE INPUT SOURCE Your TV features an easy-to-use on-screen menu. To open the on-screen menu, press the MENU button on the remote. To open the on-screen menu, press External devices such as DVD players, Blu-ray Players, and video You can also open the on-screen menu by pressing the VIA button the MENU button on the remote.

  • Page 23: Changing The Screen Aspect Ratio

    CHANGING THE SCREEN ASPECT RATIO not stretched, but the sides of the image are extremely stretched. If you are watching widescreen (1.85:1 or 2.35:1) content with black bars on the top and bottom, the black The TV can display images in five different modes: Normal, Stretch, bars will still appear on the top and bottom of the display Panoramic, Wide, and Zoom.

  • Page 24: Viewing Video With The Menu Open

    VIZIO VIEWING VIDEO WITH THE MENU OPEN Wide Zoom Normal Panoramic VIZIO When the on-screen menu opens, it covers the left-hand portion of PICTURE Wide Zoom Normal Panoramic Picture Mode Standard the picture. The picture can be displayed in three different ways: Auto Brightness Control Backlight Brightness...

  • Page 25: Adjusting The Picture Settings

    ADJUSTING THE PICTURE SETTINGS 3. Use the Arrow buttons on the 4. To manually change each of the picture settings, use the Up/ VIZIO remote to highlight Picture Down Arrow buttons on the remote to highlight that picture Mode, then use the Left/Right setting, then use the Left/Right Arrow buttons to adjust the PICTURE Your TV display can be adjusted to suit your preferences and viewing...

  • Page 26: Adjusting More Picture Settings

    Adjusting the Color Temperature Adjusting More Picture Settings • Clear Action - Reduces blur in scenes with fast action. Some sensitive viewers may notice flicker. Select On or Off. Adjusting the color temperature changes the white balance of the To adjust more picture settings: picture.

  • Page 27: Adjusting The Picture Mode Edit Settings

    Adjusting the Picture Mode Edit Settings Saving a Custom Picture Mode Locking/Unlocking a Custom Picture Mode Picture Mode Edit Settings allow you to make precise adjustments Custom picture modes allow you to save a group of custom settings Custom picture modes can be locked/unlocked with a unique PIN to to the picture and to create picture modes to save groups of picture for various viewing conditions and video sources.

  • Page 28: Deleting A Custom Picture Mode

    Deleting a Custom Picture Mode Custom picture modes that are no longer needed can be deleted. Inputs assigned to a deleted custom picture mode become assigned to the Calibrated picture mode. To delete a custom picture mode: 1. From the PICTURE MODE EDIT menu, use the Arrow buttons to highlight To delete the user created Custom 1 picture mode, Delete Picture Mode, and then...

  • Page 29: Adjusting The Color Tuner Settings

    Adjusting the Color Tuner Settings To turn color channels off and on: To adjust the 11 Point White Balance settings: The Color Tuner settings allow you to adjust the HSB color and 11 1. From the COLOR CALIBRATION menu, use the Arrow buttons 1.
  • Page 30 To show or hide the SMPTE Test Pattern: To show or hide the Flat Test Pattern: To show or hide the Ramp Test Pattern: 1. From the Color Tuner menu, use the Arrow buttons to 1. From the Color Tuner menu, use the Arrow buttons to 1.

  • Page 31: Adjusting The Audio Settings

    ADJUSTING THE AUDIO SETTINGS • Lip Sync - Adjusts the synchronization between the display Changing the Equalizer Settings image and the accompanying audio track. The graphic equalizer has several pre-set modes and allows you to To adjust the audio settings: •...

  • Page 32: Deleting The Custom Audio Mode

    Deleting the Custom Audio Mode To delete the custom audio mode that has been created: 1. Press the MENU button on the remote. The on-screen menu is displayed. 2. Use the Arrow buttons on the remote to highlight Audio and press OK.

  • Page 33: Setting Timers

    SETTING TIMERS Setting the Auto Power Off Feature Blanking the Screen To help save energy, your TV is set by default to turn off after You can blank the screen while there is audio streaming. This 10 minutes without a video or audio signal. This feature can be feature helps save energy and the life of the screen.

  • Page 34: Using The Network Connection Menu

    USING THE NETWORK CONNECTION MENU Changing the Manual Setup Settings Finding MAC Addresses for Network Setup Advanced users can fine-tune the network settings using the Manual The security settings on your router may require you to enter the Your TV is Internet-ready, featuring both an Ethernet port and Setup feature.

  • Page 35: Connecting To A Hidden Network

    Connecting to a Hidden Network Testing Your Network Connection To connect to a wireless network whose network name (SSID) is not To test your network connection: being broadcast: 1. From the NETWORK menu, highlight Test Connection and 1. From the NETWORK menu, press OK.

  • Page 36: Setting Up Channels

    SETTING UP CHANNELS Selecting a Channel Source Adding New Channels Select the type of tuner input you will be using. You can select either Occasionally, you may need to add a new range of channels or You can use the TV’s Channels menu to: Antenna (Over-the-air) or Cable (Out-of-the-wall) connections.

  • Page 37: Skipping Channels

    To add a single new analog channel: Skipping Channels After a channel scan is completed, you may find that some channels 1. From the CHANNELS menu, VIZIO are too weak to watch comfortably. There may also be some highlight Add Analog Channel channels you do not want to view.

  • Page 38: Listening To Alternate Audio

    LISTENING TO ALTERNATE AUDIO To use the Digital Language feature: 1. From the CHANNELS menu, Changing the Analog Audio Language highlight Digital Language VIZIO and press OK. The DIGITAL Some analog over-the-air (free) and cable channels broadcast DIGITAL LANGUAGE LANGUAGE menu is displayed. programs in more than one language.

  • Page 39: Setting Up Closed Captioning

    SETTING UP CLOSED CAPTIONING Changing the Appearance of Digital Closed Captions • Background Color - Change the color of the background directly behind the text. Digital closed captions can be displayed according to your Your TV can display closed captions for programs that include them. preference.
  • Page 40 Typical choices include: Background • Opaque background, transparent window—Only a strip of Text background appears behind the text, expanding as the text appears. This is the typical "As Broadcast" mode. • Opaque background and window in the same color—When text appears, the entire line fills with color at once. In the example below, the closed caption text is green, the background is black, and the window is red.

  • Page 41: Renaming Devices On The Input Menu

    RENAMING DEVICES ON THE INPUT MENU You can rename the inputs to make them easier to recognize on the Input menu. For example, if you have a DVD player connected to the Component input, you can rename that input to display “DVD Player.”...

  • Page 42: Changing The Tv Settings

    CHANGING THE TV SETTINGS Viewing System Information Changing the On-Screen Menu Language To view technical data and status information about your TV and Your TV can display the on-screen menu in different languages. Using the System menu, you can: network connection: To change the on-screen menu language: VIZIO •...

  • Page 43: Setting The Time And Local Settings

    Setting the Time and Local Settings Using the Parental Controls Enabling or Disabling Program Ratings To ensure the correct time is displayed when you press the INFO The TV’s parental controls allow you to prevent the TV from To manage program content according to its rating, you must button, set the TV’s time zone: displaying certain channels or programs without a password.

  • Page 44: Blocking And Unblocking Content By Rating

    Blocking and Unblocking Content by Rating Changing the Parental Control PIN Resetting the Content Locks A channel may sometimes broadcast programs that are meant for If you use the parental controls, you should change the PIN to To reset the content locks to the factory-default settings: children, and at other times broadcast programs that are meant prevent children from accessing inappropriate material.

  • Page 45: Changing The View Mode Settings

    CHANGING THE SCREEN ASPECT RATIO Changing the View Mode Settings not stretched, but the sides of the image are extremely stretched. If you are watching widescreen (1.85:1 or 2.35:1) You can resize the video content to fit while the menu is open. content with black bars on the top and bottom, the black The TV can display images in five different modes: Normal, Stretch, bars will still appear on the top and bottom of the display...

  • Page 46: Changing The Dlna Name Of Your Tv

    Changing the DLNA Name of Your TV Adjusting the CEC Settings Turning the Power Indicator On or Off The CEC function on your TV enables you to control devices The Power Indicator on the front of your TV normally does not glow Enter a custom DNLA name for your TV (Up to 10 characters connected to HDMI (ARC) input with the included remote, without when the TV is on.

  • Page 47: Using The Reset & Admin Menu

    USING THE RESET & ADMIN MENU 5. If you have changed the default parental control PIN, enter it Enabling and Disabling Smart Interactivity now. Your TV can display program-realted information as part of the You can use the TV’s Reset & Admin menu to restore the TV to its broadcast.

  • Page 48: Using The Guided Setup Menu

    USING THE GUIDED SETUP MENU USING THE INFO WINDOW Using Guided Setup The Info Window can be displayed by pressing the INFO or GUIDE The TV’s Setup App can be used to easily set up the TV channel or to button on the remote: connect the TV with your network.

  • Page 49: Using The Usb Media Player

    Using the USB Media Player Using the USB Media Player Preparing Your USB Drive to Play USB Media Removing the USB Drive from the TV To play USB media, you must first save your files onto a USB thumb To safely remove your USB drive from the TV: The USB Media Player allows you to connect a USB thumb drive to drive: your TV and play music, video, or photos.
  • Page 50 Now Playing Information Displays song title, album title, and artist name. Back Button Album Art Highlight this button and If included on the USB Progress Bar press OK to return to Displays the duration of the current- thumb drive and associated the previous screen.
  • Page 51 Back Button Highlight this button and press OK to return to the previous screen. Connected Sources VIZIO Displays Video connected USB USB1: MyFlashDrive devices. MyFlashDrive\Video\root\My Videos File Date Duration Family Vacation - California 00:23:43 Current Folder 26th Birthday Party 00:38:18 My Videos Summer 2012 00:41:08...
  • Page 52 Folder Contents This area displays the Back Button Back Button contents of the currently Highlight this button and Highlight and press OK to return to left column. selected folder. You can press OK to return to browse files and folders the previous screen.

  • Page 53: Using Vizio Internet Apps Plus (V.i.a. Plus)

    Using VIZIO Internet Apps Plus (V.I.A. Plus) ® VIZIO Internet Apps Plus (V.I.A. Plus) delivers popular online content ® to your TV. V.I.A. Plus features a selection of Apps that allow you to watch movies and TV shows, listen to music, get weather and news information, and more–all on demand.

  • Page 54: Using The Fullscreen V.i.a. Apps Window

    USING THE FULLSCREEN V.I.A. APPS WINDOW The Fullscreen V.I.A. Plus Apps window allows you to add and store Apps. The Apps on the first page are displayed in the Dock and Apps on additional pages can be moved to the Dock. To open the Fullscreen V.I.A.

  • Page 55: Fullscreen V.i.a. Plus Apps Window Overview

    FULLSCREEN V.I.A. PLUS APPS WINDOW OVERVIEW The Fullscreen V.I.A. Plus Apps Window allows you to add, delete and organize your Apps. The My Apps tab displays Apps that are already installed on your TV. The Apps on the first page are displayed in the V.I.A.

  • Page 56: Customizing The V.i.a. Plus Apps Window

    CUSTOMIZING THE V.I.A. PLUS APPS WINDOW Deleting an App from the My Apps Tab Moving an App in My Apps To delete an app from your TV: You can organize your Apps on your My Apps tab by moving them You can add, delete, and move apps around on your My Apps tab where you want.
  • Page 57 3. Use the Arrow buttons to move the app to the desired location and press OK to place the app. When you can move the app, it appears as shown below. Note: App location, appearance, and availability subject to change without notice. Cursor showing the location that the app will move to...

  • Page 58: Viewing Ultra Hd Content

    Viewing Ultra HD Content WHAT IS ULTRA HD? WHAT YOU NEED TO VIEW ULTRA HD CONTENT WHAT ARE HDMI 2.0 AND HDCP 2.2? Ultra HD (UHD) offers four times the resolution of 1080p (that’s To view Ultra HD content, you will need: Your D-Series TV supports the latest HDMI standards.

  • Page 59: Troubleshooting & Technical Support

    Troubleshooting & Technical Support Do You Have Questions? Find Answers At SUPPORT.VIZIO.COM Find help with: • New Product Setup • Connecting Your Devices • Technical Problems • Product Updates • And More Live Chat Support Available You can also contact our award-winning support team at: Phone: (877) 698-4946 (TOLL-FREE)
  • Page 60 Take A Moment To Register Your Product At VIZIO.COM/PRODUCT-REGISTRATION Why Register? Customized Support Get assistance quickly with your information on-hand. News & Offers Take advantage of the latest news and special offers from VIZIO. Safety & Satisfaction Stay up to date with important product updates and notifications. REGISTER YOUR VIZIO PRODUCT NOW...
  • Page 61 The remote is not responding. There is no sound. The image quality is not good. • Make sure the batteries are properly inserted matching • Press Volume Up on the remote control. • For the best image quality, view high-definition programs the - and + symbols.
  • Page 62 I see “noise” or static on the screen. • When your TV’s digital capabilities exceed a digital broadcast signal, the signal is up-converted (improved) to match your TV’s display capabilities. This up-converting can sometimes cause irregularities in the image. • If you are using an antenna, the signal strength of the channel may be low.

  • Page 63: Specifications

    Specifications D50u-D1 D50u-D1 Screen Size: 50" Remote Control Model: XRT122 Viewable Area: 49.50" Certifications: UL, cUL, FCC Class B, HDMI 1.4/2.0, Dolby Digital Plus Dimensions w/ Stand: 44.24" x 28.27" x 10.04" w/o Stand: 44.24" x 25.91" x 2.52" Voltage Range: 120 V @ 60 Hz...
  • Page 64 Specifications D55u-D1 D55u-D1 Screen Size: 55" Remote Control Model: XRT122 Viewable Area: 54.64" Certifications: UL, cUL, FCC Class B, HDMI 1.4/2.0, Dolby Digital Plus Dimensions w/ Stand: 48.76" x 30.75" x 10.04" w/o Stand: 48.76" x 28.39" x 2.52" Voltage Range: 120 V @ 60 Hz Weight w/ Stand: 37.48 lbs...

  • Page 65: Warranty

    Warranty ON PARTS AND LABOR that affords an equal degree of protection. VIZIO Technical TO STATE. THIS WARRANTY IS SUBJECT TO CHANGE WITHOUT Support will provide instructions for packing and shipping the NOTICE. Covers units purchased as new in United States and covered Product to the VIZIO service center.

  • Page 66: Legal & Compliance

    Legal & Compliance FCC Class B Radio Interference Statement Caution VIZIO Internet Applications Disclaimer NOTE: This equipment has been tested and found to comply with the limits Always use an AC/DC power adapter that is properly grounded. Use the AC VIZIO Internet Applications (“VIA”) affords the opportunity to access third party for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 67 VIZIO SOFTWARE LICENSE AGREEMENT related information, including but not limited to information about your use of indecent, or objectionable, which content may or may not be identified as the VIZIO Software, the VIA Services, content viewed and attached peripherals, having explicit language. Nevertheless, you agree to use the VIA Services at The following terms and conditions govern the use of any software on your products or services purchased, that is gathered periodically to facilitate the your sole risk and that VIZIO shall have no liability to you for content that may...
  • Page 68 11. Disclaimer of Warranties. YOU EXPRESSLY ACKNOWLEDGE AND AGREE 13. Export Control. You may not use or otherwise export or re-export the THAT USE OF THE VIZIO SOFTWARE AND VIA SERVICES (AS DEFINED ABOVE) VIZIO Software except as authorized by United States law and the laws of IS AT YOUR SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY the jurisdiction in which the VIZIO Software was obtained.
  • Page 69 © 2015 VIZIO INC. ALL RIGHTS RESERVED. 12082015 AD-US-A...
