Quick Installation Guide

N600 Wireless Dual Band PCI Express Adapter
RNX-N600PCE_v2.0
MODEL NO.
2

Software Installation

Insert the Resource CD into the CD-ROM drive.
1
Double-click Computer, and then double-click the
2
CD/DVD Drive where the installation CD was placed.
Open RNX-N600PCE_v2.0 folder, and double-click
Setup.exe to begin.
7109504761 REV1.0.0

Package Contents

RNX-N600PCE_v2.0
Resource CD
System Requirement
· Windows XP · Windows Vista · Windows 7 · Windows 8
(The installation procedures in Windows XP/ Vista/ 7/ 8 are similar. Here we use the procedures in Windows 7 as an example.)
The InstallShield Wizard window will appear.
3
Click Next to continue.
Select Install Rosewill Wireless Con guration
4
Utility and Driver and then click Next.
1

Hardware Connection

Quick Installation Guide
N600 Wireless Dual Band PCI Express Adapter
MODEL NO.
RNX-N600PCE_v2.0
QIG
Steps:
1. Turn o your computer and unplug the power cord from the computer.
2. Open the case. Locate an available PCI Express slot and remove its slot cover.
Keep the screw.
3. Insert the adapter into the PCI Express slot as shown above.
4. Secure the adapter with the screw removed in Step 2.
5. Close the case and insert the power cord back into the computer.
6. Turn on your computer.
Click Change to specify the destination location
5
or you can leave it default. Click Next to continue.
Click Install to install the driver and utility for your
6
adapter.
You may see the Found New Hardware Wizard (Found
New Hardware) after the adapter has been inserted.
Please click Cancel.
For Windows XP
For Windows Vista
The installation process may take 1-2 minutes.
7
The following screen will then appear.
8
Click Finish to complete the setup.
