Undo the two Velcro fasteners of the
safety-net stowage.
X
Unroll and unfold the cargo net.
The upper and lower guide rods must
engage audibly.
Attaching the safety net
Cargo net attached behind the C-pillar
Retainer
:
Guide rod
;
X
Insert guide rod ; into retainer : in the
direction of the arrow.
X
Slide guide rod ; forwards into
retainer : in the direction of the arrow.
Tightening the safety net
Seat belt reel holder behind the front seats
X
Insert belt hook : into cargo tie-down
ring ; in the direction of the arrow.
X
Pull tensioning strap = by the loose end in
the direction of the arrow until the cargo
net is tight.
X
After driving a short distance, check the
tension of the cargo net and retighten it if
necessary.
Releasing the safety net
Seat belt reel holder behind the front seats
X
Pull belt adjuster : upwards in the
direction of the arrow to reduce the tension
on the tensioning strap.
X
Unhook belt hook ; from cargo tie-down
ring =.
Detaching and storing the safety net
X
Detach guide rod ; from bracket :
( Y page 259).
X
Press the red button on the upper and lower
guide rods.
X
Fold the cargo net and roll it up.
X
Close the two Velcro fasteners on the cargo
net holder.
Roof carrier
Important safety guidelines
G
Warning!
Only use the roof rack when the basic carrier
bars have been completely mounted. The left
