Summary of Contents for KTI 1000Base-X
- Page 1 Installation Guide 1000Base-X Gigabit Ethernet PCI Adapter with SFP Support KG-500F Rev.B series DOC.131030-KG-500FB-K...
- Page 2 The information contained in this document is subject to change without prior notice. Copyright (C) All Rights Reserved. TRADEMARKS All brand names are trademarks or registered trademarks of their respective holders. Warning This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 CISPR 22 Class B This device complies with EMC directive of the European Commu- nity and meets or exceeds the following technical standard: EN 55022 - Limits and Methods of Measurement of Radio Interference Char- acteristics of Information Technology Equipment. This device com- plies with CISPR 22 Class B.
-
Page 4: Adapter Features
Introduction The 1000BASE-X Gigabit Ethernet PCI Adapter is a 32-bit LAN adapter for use in personal computers with PCI computer bus slots. This adapter features a mini-GBIC fiber connector (SFP) for a 1000 Mbps IEEE 802.3z Ethernet network connection over optical fiber cable. -
Page 5: Specifications
Specifications Standards IEEE 802.3z 1000Base-SX/LX Network Port SFP for 1000Mbps mini-GBIC fiber transceiver Host Interface 32-bit 33/66Mhz PCI Rev.2.1/2.2/2.3 LEDs SFP status, Link status, Optical status Network Cables 50/125 multimode fiber up to 500m 62.5/125 multimode fiber up to 220m 9/125 single mode fiber Transfer Rate Gigabit Ethernet: 2000Mbps (Full-duplex) -
Page 6: Board Components
Board Components The figures show the major components on the adapters with PCI standard bracket and PCI low-profile bracket. Adapter with PCI standard bracket... - Page 7 Adapter with PCI low-profile bracket No. Components Description LINK LED This LED lights when the fiber connection is established. SFP LED This LED lights when a mini-GBIC transceiver module is installed in the SFP slot. OL LED This LED lights when optical signal is presented in the transceiver.
-
Page 8: Installing The Adapter
Installing the Adapter Before installing the adapter, you need the following: • A computer system that is compliant with the PCI specifica- tions version 2.1 or later. • An available PCI bus master slot in the computer • The adapter driver diskettes (or CD supplied with the adapter) •... - Page 9 Installing Mini-GBIC Transceiver A typical mini-GBIC SFP transceiver is shown as follows: To install a fiber transceiver into the SFP slot, the steps are: 1. Insert the fiber transceiver into the mini-GBIC SFP port. Normally, a bail is provided for every SFP transceiver. Hold the bail and make insertion.
-
Page 10: Connecting To The Network
Connecting to the Network The rear bracket of the PCI adapter contains two fiber connectors. The TX connector is used for transmission and the RX is used for reception. When connecting to a device using fiber cable, make sure the TX connector of the adapter is connected to the RX connector of the device and RX connector is connected to the TX connector of the device. -
Page 11: Network Driver Installation
Network Driver Installation After making the connection to the network, you must install the adapter network driver in order to connect the network adapter to your network operating system. The adapter driver media contains the latest versions of the network drivers available when the adapter is shipped from the factory. -
Page 12: Led Indicators
No optical signal is detected. If you experience any problems, first make sure that the appropri- ate driver is loaded, the proper cable is connected to the connector, and the connected device complies with 1000BASE-X standard. Then recheck the LED.
