WARNING TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN...
PRECAUTION Follow the advice below for safe and appropriate operation. ON PLACEMENT ON CONDENSATION • Do not use the unit in places which are extremely • When left in a heated room where it is warm and hot, cold, dusty, or humid. damp, water droplets or condensation may form •...
SYSTEM CONNECTIONS IMPORTANT SPEAKERS TERMINALS IMPEDANCE: Switch off the power before connecting speakers and other equipment. SPEAKER CORD CONNECTION Connect the black wires to the black (-) terminals and the other color (white, red & brown) to the red (+) terminals. NOTE: Connecting speakers other than the speakers supplied with the unit, may damage the unit.
PARTS IDENTIFICATIONS CD door CD storage STEREO WIDE indicator STEREO WIDE button POWER / STANDBY button BAND button VOLUME control buttons DISC SKIP button RANDOM / TUNING / REPEAT buttons OPEN / CLOSE button REMOTE SENSOR PLAY / PAUSE button DISPLAY window SKIP/SEARCH/PRESET buttons FM MODE (STEREO / MONO)
DISPLAY -BASS TUNER MEMORY TIMER ONOFF RANDOM SLEEP TRACK AM FM STEREO REPEAT DISC 11. Pause indicator. 1. TRACK and CHANNEL indicators. 2. FUNCTION indicators. 12. MEMORY indicator. 3. SLEEP indicator. 13. RANDOM indicator. 14. Indicators to show which disc holder of the disc tray 4.
ADJUSTING THE SOUND TO ADJUST THE VOLUME TO USE THE X-BASS WOOFER Press the X-BASS WOOFER button to adjust the bass. Press the VOLUME buttons to adjust the sound. S T E R E O -BASS VOL UP To increase the volume press here.
SETTING THE CLOCK To set the current time (Select POWER STANDBY mode) 2. Press the (SKIP) button repeatedly to set current MEMORY/ CLOCK 1. Press the button in clock hour. mode. Hours flash. MEMORY CLOCK 3. Press the MEMORY/ CLOCK button to 4.
SETTING THE SLEEP TIMER 2. Press and hold the SLEEP button to select the length of 1. Press the SLEEP button while the power is on. remaining time until the unit turns off. "SLEEP 90" lights in the display. It changes the indicator in the following way: SLEEP 90 SLEEP 80 SLEEP 10...
FOR BETTER RECEPTION AM/MW Fully unwind the wire antenna. Then extend the wire antenna Connect the loop aerial (provided) to the 'AM/MW LOOP and place it in the position that sounds best. ANTENNA' snap terminals at the back of the unit. Position NOTE: Do not connect to outside antenna.
TUNING INTO A PRESET STATION 1. Press the FUNCTION button to 2. Press the BAND button to select the 3. Press the PRESET buttons to TUNER. a band. preset number. BAND FUNCTION The contents (preset channel number, frequency and frequency band) which have been stored in memory will appear on the display in numerical order, irrespective of the frequency bands.
COMPACT DISC PLAYBACK 1. Press the FUNCTION button to CD. 2. Press the OPEN/CLOSE button to open the disc tray. FUNCTION T R A C K 3. Place the first disc onto the disc holder, with the label 4. Press the DISC SKIP button to revolve the tray clock- side up.
Page 13
COMPACT DISC PLAYBACK (CONTINUED) Notes: 1. During playback, disc tray can be opened to change/add disc, but DISC SKIP button will become invalid and the current disc playback will not be interrupted. 2. The SKIP buttons can only be used to choose a track of the current disc. To choose a track of another disc, DISC SKIP button should be pressed to get to the desired disc first.
COMPACT DISC PLAYBACK (CONTINUED) SHUFFLE PLAY - PLAYING IN A RANDOM ORDER IN STOP MODE 1. Press the DISC SKIP button to select a disc. 2. Press the RANDOM button, the word "RANDOM" will appear on the display. T R A C K 3.
Page 15
COMPACT DISC PLAYBACK (CONTINUED) REPEAT PLAYBACK DURING PLAYBACK MODE To Repeat the Current Track • Press the REPEAT button until REPEAT ONE appears on the display and the currently playing track will be played repeatedly until the STOP button is pressed. •...
Page 16
COMPACT DISC PROGRAMMED PLAYBACK A program of up to 32 tracks from all the available discs in the disc tray can be played in a preset order. 2. Press the DISC SKIP button to select the desired disc (the 1. Press the MEMORY/ CLOCK button (in stop mode). disc symbol ( ) shows which disc is selected).
Page 17
STOPPING AND CANCELLING PROGRAMMED PLAYBACK To stop programmed play for a moment: • Press the PLAY/PAUSE button and " " will be displayed. Press this button again to resume playing. T R A C K To add additional tracks during program playback: •...
MAINTENANCE CLEANING CD If the CD skips or will not play, the disc may need cleaning. Before playing, wipe the disc from the centre out with a cleaning cloth. After playing, store the disc in its case. CLEANING THE UNIT Do not use volatile chemicals on this unit.
