Manual release for fuel filler flap

Important!
After manually operating the Skyview Top, a timing
synchronization is needed for future electrical operation
of the Skyview Top. To do so, turn key in steering lock to
position 2. Now push and hold switch until the Skyview
Top is fully closed. Continue to hold switch for
additional 15 seconds.
Instrument
Driving
cluster display
274
Practical hints Car care
Manual release for fuel filler flap
The manual release is located behind the cover in the
left rear compartment trim panel.
In case the central locking system does not release the
fuel filler flap, pull up on the lock rod (arrow).
ML 55 AMG:
First remove the space-saver tire from its holder, see
page 242.
