Page 3 Your Mercedes-Benz represents the efforts of many skilled engineers and craftsmen. To ensure your pleasure of ownership, and for your safety and that of your passengers, we ask you to make a small investment of your time: •...
Page 4: Table Of Contents
Introduction Product information ... 7 Operator’s manual ... 8 Where to find it ... 13 Reporting Safety Defects ... 15 Instruments and controls Instruments and controls ... 18 Center console ...20 Overhead control panel ... 21 Operation Vehicle keys ... 24 Start lock-out...
Page 5 Contents Cassette player ...99 Telephone ... 100 Telephone book ... 100 Redialing ... 102 Incoming call ... 104 Navigation system... 105 Trip computer... 106 Malfunction message memory ... 108 Individual settings... 110 Setting the audio volume... 113 Flexible service system (FSS)...
Page 6 Driving Control and operation of radio transmitters ... 184 The first 1 000 miles (1 500 km) ... 185 Maintenance ... 185 Tele Aid... 186 Catalytic converter... 196 Emission control ... 197 Steering lock... 198 Starting and turning off the engine ... 200 Automatic transmission...
Page 7 Contents AIRBAG OFF indicator lamp ...246 Malfunction and warning messages in the multifunction display ... 247 DISPLAY DEFECTIVE ...248 BATTERY / ALTERNATOR ...249 ABS-SYSTEM ...250 BRAKE ASSIST ...250 BRAKE LINING WEAR ... 251 BRAKE FLUID ... 251 PARKING BRAKE ...252 ENGINE FAN ...252 COOLANT (coolant level) ...253 COOLANT TEMP.
Page 8 Vehicle care Cleaning and care of the vehicle... 308 Power washer ...309 Tar stains ...309 Paintwork, painted body components ...309 Engine cleaning ... 310 Vehicle washing ... 310 Ornamental moldings ... 310 Headlamps, taillamps, turn signal lenses ... 310 Cleaning the parktronic system sensors ...
Page 10: Introduction
Use of such parts and accessories could adversely affect the safety, performance or reliability of your vehicle. Please do not use them. Mercedes-Benz original parts as well as conversion parts and accessories approved by us are available at your authorized Mercedes-Benz Center where you will receive comprehensive information, also on permissible technical modifications, and where proper installation will be performed.
Page 11: Operator's Manual
Ignoring them could result in damage to the vehicle or personal injury to you or others. Vehicle damage caused by failure to follow instructions is not covered by the Mercedes-Benz Limited Warranty. Your vehicle may have some or all of the equipment described in this manual. Therefore, you may find explanations for optional equipment not installed in your vehicle.
Page 12 The Service Booklet describes all the necessary maintenance work which should be performed at regular intervals. Always have the Service Booklet with you when you take the vehicle to your authorized Mercedes-Benz Center for service. The service advisor will record each service in the booklet for you.
Page 13 Introduction Roadside assistance The Mercedes-Benz Roadside Assistance Program provides factory trained technical help in the event of a breakdown. Calls to the toll-free Roadside Assistance number: 1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada) will be answered by Mercedes-Benz Client Assistance Representatives 24 hours a day, 365 days a year.
Page 14 • gasoline may have a considerably lower octane rating, and improper fuel can cause engine damage. Certain Mercedes-Benz models are available for delivery in Europe under our European Delivery Program. For details, consult your authorized Mercedes-Benz Center or write to:...
Page 15 If there are any equipment details that are not shown or described in this Operator’s Manual, your authorized Mercedes-Benz Center will be glad to inform you of correct care and operating procedures. The Operator’s Manual and Service Booklet are important documents and should be kept with the vehicle.
Page 16: Where To Find It
Where to find it The Operator’s Manual is divided into eight sections: • Instruments and controls: An overview of all the controls that can be operated from the driver’s seat. • Operation: Information on the vehicle’s equipment and its operation. •...
Page 17: Problems With Your Vehicle
If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact your authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is not handled to your...
Page 18: Reporting Safety Defects
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your retailer, or Mercedes-Benz USA, LLC.
Page 20: Instruments And Controls
Instruments and controls Instruments and controls ... 18 Center console ...20 Overhead control panel ... 21 Contents - Instruments and controls Instruments Operation Driving and controls Instrument Practical hints Car care cluster display Technical Index data...
Page 21: Instruments And Controls
Instruments Operation Driving and controls Instruments and controls Instruments and controls Instrument Practical hints Car care cluster display 16 17 18 Technical Index data 21 22 P68.10-2410-29...
Page 22 Parking assist warning indicators, see page 234 Side defroster outlet Side air outlet, adjustable Air volume control for side air outlet Exterior lamp switch, see page 119 Parking brake release, see page 210 Hood lock release, see page 266 Combination switch, see page 122 Cruise control switch, see page 220 Instrument cluster, see page 86 Multifunction steering wheel, see page 92...
Page 23: Center Console
Instruments Operation Driving and controls Instruments and controls Center console Instrument Practical hints Car care cluster display Ashtray with lighter, see page 165 ESP control switch, see page 230 Power window switches, front doors, see page 154 Power window safety switch, rear doors, see page 155 Airbag Off indicator lamp, see page 246 Power window switches, rear doors, see page 154...
Page 24: Overhead Control Panel
Overhead control panel Instruments and controls Instruments Operation Driving and controls Interior lighting, see page 159 Sliding/pop-up roof, see page 156 Rear view mirror, see page 82 Garage door opener, see page 179 Tele Aid (emergency call system), see page 186 Hands-free microphone for Tele Aid, telephone and voice recognition system Instrument...
Page 25 Instruments Operation Driving and controls Contents - Operation Operation Vehicle keys ... 24 Start lock-out... 27 General notes on the central locking system ... 28 Central locking system ... 29 Radio frequency and infrared remote control ...29 Opening and closing windows and sliding/pop-up roof from outside ...32 Panic button ...33...
Page 26 Engine oil level indicator... 117 Engine oil consumption ... 118 Exterior lamp switch ... 119 Night security Illumination ... 120 Headlamp cleaning system ... 121 Combination switch... 122 Rear window wiper / washer ... 124 Hazard warning flasher switch... 125 Automatic climate control ...
Page 27: Vehicle Keys
Instruments Operation Driving and controls Central locking system Vehicle keys Included with your vehicle are: • 2 electronic main keys with integrated radio frequency and infrared remote controls plus removable mechanical key. • 1 electronic reserve key without remote control functions, plus removable mechanical key.
Page 28 Electronic main key The electronic main key has an integrated radio frequency and infrared remote control, plus removable mechanical key. The remote control (1) operates all locks on the vehicle. The mechanical key (2) works only in the driver’s door, tailgate, and storage compartment locks.
Page 29 Instruments Operation Driving and controls Central locking system Electronic reserve key The electronic reserve key is without remote control functions, but with removable mechanical key. Instrument Practical hints Car care cluster display The electronic reserve key (1) works only in the steering lock.
Page 30: Start Lock-Out
Obtaining replacement keys Your vehicle is equipped with a theft deterrent locking system requiring a special key manufacturing process. For security reasons, replacement keys can only be obtained from your authorized Mercedes-Benz Center. Central locking system Instruments Operation Driving and controls...
Page 31: General Notes On The Central Locking System
Instruments Operation Driving and controls Central locking system General notes on the central locking system If the electronic key is inserted in the steering lock, the vehicle cannot be locked or unlocked with the remote control. If the vehicle cannot be locked or unlocked: •...
Page 32: Central Locking System
Central locking system Radio frequency and infrared remote control The electronic main key has an integrated radio frequency and infrared remote control. Due to the extended operational range of the remote control, it could be possible to unintentionally lock or unlock the vehicle by pressing the transmit button.
Page 33 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system P80.30-2137-26 P80.30-2138-26 Infrared receiver in driver’s door handle Infrared receiver in front passenger door handle...
Page 34 Locking and unlocking with remote control Unlocking: Press transmit button Œ. All turn signal lamps blink once to indicate that the vehicle is unlocked. The remote control can be programmed for two kinds of unlocking modes (see below): Selective unlocking mode – Press transmit button Œ...
Page 35: Opening And Closing Windows And Sliding/Pop-Up Roof From Outside
Instruments Operation Driving and controls Central locking system Choosing global or selective mode on remote control Press and hold transmit buttons ‹ and Œ simultaneously for five seconds to reprogram the remote control. Battery check lamp will blink two times indicating the completed mode change.
Page 36: Panic Button
Panic button To activate press and hold button (1) for at least one second. An audible alarm and blinking exterior lamps will operate for approximately 3 minutes. To deactivate press button (1) again, or insert electronic key in steering lock. Central locking system Instruments Operation...
Page 37: Doors
Instruments Operation Driving and controls Central locking system Doors Opening – pull handle Unlocking driver’s door Locking driver’s door Individual door from inside: Push lock button down to lock. Important! The mechanical key does not operate the central locking system or antitheft alarm system. Instrument Practical hints cluster display...
Page 38 If the vehicle has previously been locked from the outside, opening a door from the inside will trigger the alarm. When opening a door while the central locking system is in the: • selective unlocking mode, only that individual door is unlocked.
Page 39: Central Locking Switch
Instruments Operation Driving and controls Central locking system Central locking switch Locking Unlocking The central locking switch is located in the center console. The doors and tailgate can only be locked with the central locking switch, if front doors are closed. If the vehicle was previously locked with the central locking switch, while in the selective remote control mode, only the door opened from the inside is unlocked.
Page 40: Automatic Central Locking
Automatic central locking The central locking switch also operates the automatic central locking. With the automatic central locking system activated, the doors and trunk are locked at vehicle speeds of approximately 9 mph (15 km/ h) or more. The fuel filler flap remains unlocked.
Page 41: Tailgate
Instruments Operation Driving and controls Central locking system Tailgate The lock is located in the license plate recess. Neutral position Unlocking Locking Instrument Practical hints Car care cluster display Recessed handle Lock button Technical Index data...
Page 42 Grip molding Lock Recessed handle Central locking system Instruments Operation Driving and controls To close the tailgate, pull down on inside grip (8) and press down on outside grip molding (5) until the tailgate latch engages. It is not necessary to slam the tailgate closed, a power-assisted mechanism will draw the tailgate quietly and automatically.
Page 43 Instruments Operation Driving and controls Central locking system Important! In case of danger, the closed tailgate can be opened with the inside or outside handle. Only drive with the tailgate closed as otherwise exhaust fumes may enter the vehicle interior. Warning! To prevent possible personal injury, always keep hands and fingers away from the tailgate opening...
Page 44: Antitheft Alarm System
Antitheft alarm system Indicator lamp in switch located in center console Antitheft alarm system Instruments Operation Driving and controls The antitheft alarm is automatically armed or disarmed with the remote control by locking or unlocking the vehicle. The antitheft alarm is armed within approximately 10 seconds after locking the vehicle.
Page 45 Instruments Operation Driving and controls Antitheft alarm system The alarm will last approximately 3 minutes in form of flashing exterior lamps. At the same time an alarm will sound for 30 seconds. The alarm will stay on even if the activating element (a door, for example) is immediately closed.
Page 46: Tow-Away Alarm
Tow-away alarm The switch is located in the center console. Press to switch off Indicator lamp Once the alarm system has been armed, the exterior vehicle lamps will flash and an alarm will sound when someone attempts to raise the vehicle. Tow-away alarm Instruments Operation...
Page 47: Power Seats Front
Instruments Operation Driving and controls Seats Power seats front Warning! Do not adjust the driver’s seat while driving. Adjusting the seat while driving could cause the driver to lose control of the vehicle. Never ride in a moving vehicle with the backrest reclined.
Page 48 The slide switches are located in each front door. We recommend to adjust the power seat in the following order: Seat, up /down Press the switch (up/down direction) until comfortable seating position with still sufficient headroom is reached. Seat adjustment, fore/aft Press the switch (fore /aft direction) until a comfortable seating position is reached that still Seats...
Page 49 Instruments Operation Driving and controls Seats Synchronizing head restraints If the power supply was interrupted (battery disconnected or empty), the head restraints are no longer adjusted automatically. To resynchronize the adjustment feature, turn electronic key in steering lock to position 2, move the seat completely forward and the head restraint fully down, and hold respective buttons for approximately two seconds.
Page 50 Memory function Memory button Position buttons Seats Instruments Operation Driving and controls Storing positions into memory Three sets of seat/head restraint/steering wheel and exterior rear view mirror positions may be programmed into memory. After the seat/head restraint /steering wheel and exterior rear view mirrors are positioned, push memory button (6), release, and within 3 seconds push position button “1”.
Page 51 Instruments Operation Driving and controls Seats Recalling positions from memory To recall a seat/head restraint /steering wheel and exterior rear view mirror position, push and hold position button “1”, “2” or “3” until seat/ head restraint/ steering wheel and exterior rear view mirror movement has stopped.
Page 52 Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart installed in the vehicle to deactivate the passenger- side front airbag when it is properly installed.
Page 53: Front Seat Head Restraints
Instruments Operation Driving and controls Seats Front seat head restraints Removal: Push button (1) up to bring the power adjustable head restraint to its highest position. Pull out head restraint completely with both hands. Instrument Practical hints Car care cluster display Installation: Push button (1) of the power adjustable head restraint up for approximately 5 seconds.
Page 54: Rear Seat Head Restraints
Rear seat head restraints Head restraint release Raising: Pull up on head restraint. Lowering: Push head restraint release and push down on head restraint. Angle of head restraints: The head restraint angle can be adjusted manually. Seats Instruments Operation Driving and controls Adjust head restraint to support the back of the head approximately at ear level.
Page 55 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Rear seat head restraint, storage For improved rear vision, the head restraint for the rear bench center seat can be removed if the seat is not occupied.
Page 56: Multicontour Seat
Multicontour seat (optional) We recommend to adjust the multicontour seat in the following order: Seat cushion depth Backrest bottom Backrest center Side bolster adjustment Seats Instruments Operation Driving and controls Some models may be equipped with multicontour seats. These seats have movable seat cushions, and inflatable air cushions built into the backrest to provide additional lumbar and side support.
Page 57: Seat Heater
Instruments Operation Driving and controls Seats Seat heater The seat heaters can be switched on with the electronic key in steering lock positions 1 or 2. Instrument Practical hints Car care cluster display Notes: When in operation, the seat heater consumes a large amount of electrical power.
Page 58 Vehicles without seat ventilation The front seat heater switches are located in the center console. Seats Instruments Operation Driving and controls Press switch to turn on seat heater: Normal seat heating mode. One indicator lamp in the switch lights up. Rapid seat heating mode.
Page 59 Instruments Operation Driving and controls Seats Vehicles with seat ventilation The front seat heater switches are located in the center console. Instrument Practical hints Car care cluster display Rapid heating mode: Press button (3) once. Both red indicator lamps above the button light up. The system switches over to normal heating mode automatically after approximately 5 minutes.
Page 60: Seat Ventilation
Seat ventilation The front seat ventilation switches are located in the center console. Turn the electronic key in steering lock to position 1 or 2. Seats Instruments Operation Driving and controls Level 3 ventilation setting (maximum): Press button (1). Three blue indicator lamps beside the button light up. The level of ventilation is decreased one step approximately every 10 minutes.
Page 61 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Notes: When in operation, the seat ventilation consumes a large amount of electrical power. It is not advisable to use the seat ventilation longer than necessary. The seat ventilation may automatically switch off if too many power consumers are switched on at the same time or if the battery charge is low.
Page 62: Seat Belts And Integrated Restraint System
Driving and controls Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart which operates with the BabySmart installed in the vehicle to deactivate the passenger front airbag when it is properly installed.
Page 63: Seat Belt Nonusage Warning System
Instruments Operation Driving and controls Restraint systems Warning! Never ride in a moving vehicle with the backrest reclined. Sitting in an excessively reclined position can be dangerous. You could slide under the seat belt in a collision. If you slide under it, the belt would apply force at the abdomen or neck.
Page 64 Fastening of seat belts Latch plate Buckle Release button Restraint systems Instruments Operation Driving and controls Push latch plate (1) into buckle (2) until it clicks. Do not twist the belt. A twisted seat belt may cause injury. To help avoid severe or fatal injuries, the lap belt should be positioned as low as possible on your hips and not across the abdomen.
Page 65 Instruments Operation Driving and controls Restraint systems Tighten the lap portion to a snug fit by pulling shoulder portion up. The shoulder portion of the seat belt must be pulled snug and checked for snugness immediately after engaging it. Instrument Practical hints Car care cluster display...
Page 66 Adjust seat belt so that shoulder portion is located as close as possible to the middle of your shoulder (it should not touch the neck). For this purpose, you can adjust the height of the belt outlet. Three positions are available for the front seats, five positions are available for the split rear bench seats.
Page 67: Use Seat Belts Properly
Instruments Operation Driving and controls Restraint systems Unfastening of seat belts Push the release button (3) in the belt buckle (2). Allow the retractor to completely rewind the seat belt by guiding the latch plate (1). Instrument Practical hints Car care cluster display Warning! USE SEAT BELTS PROPERLY.
Page 68 • Position the lap belt as low as possible on your hips and not across the abdomen. If the belt is positioned across your abdomen, it could cause serious injuries in a crash. • Never wear belts over rigid or breakable objects in or on your clothing, such as eyeglasses, pens, keys etc., as these might cause injuries.
Page 69: Use Child Restraints Properly
Restraint systems Warning! USE CHILD RESTRAINTS PROPERLY. Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart installed in the vehicle to deactivate the passenger front airbag when it is properly installed.
Page 70: Babysmart Tm Airbag Deactivation System
BabySmart airbag deactivation system Special BabySmart compatible child seats, designed for use with the Mercedes-Benz system and available at any authorized Mercedes-Benz Center are required for use with the BabySmart airbag deactivation system. With the special child seat properly installed, the passenger front airbag will not deploy.
Page 71: Supplemental Restraint System (Srs)
Instruments Operation Driving and controls Restraint systems Supplemental restraint system (SRS) Airbags are intended as a supplement to seat belts. Airbags alone cannot protect as well as airbags plus seat belts in impacts for which the airbags were designed to operate, and do not afford any protection whatsoever in crashes for which the airbags are not designed to deploy.
Page 72: Emergency Tensioning Retractor (Etr)
Emergency tensioning retractor (ETR) The seat belts for the front and outer rear seats are equipped with emergency tensioning retractors. These tensioning retractors are located in each belt’s inertia reel and become operationally ready with the electronic key in steering lock position 1 or 2. The emergency tensioning retractors are designed to activate only when the seat belts are fastened during frontal impacts exceeding the first threshold of the SRS...
Page 73: Airbags
Instruments Operation Driving and controls Restraint systems Airbags Driver airbag Front passenger airbag Instrument Practical hints Car care cluster display The most effective occupant restraint system yet developed for use in production vehicles is the seat belt. In some cases, however, the protective effect of a seat belt can be further enhanced by an airbag.
Page 74 “SRS” may not be operational. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz dealer immediately to have the system checked; otherwise the “SRS” may not be activated when needed in an accident, which could...
Page 75 Instruments Operation Driving and controls Restraint systems Front airbags The driver and passenger front airbags are designed to activate only in certain frontal impacts exceeding a preset threshold. The front passenger airbag deploys only if the front passenger seat is occupied and the 7 indicator lamp on the center console is not illuminated.
Page 76 Side impact airbags The side impact airbags are designed to activate only in certain side impacts exceeding a preset threshold. Only the side impact airbags on the impacted side of the vehicle deploy. The side impact airbag for the front passenger deploys only if the front passenger seat is occupied.
Page 77 Instruments Operation Driving and controls Restraint systems Warning! Airbags are designed to reduce the potential of injury in certain frontal (front airbags) impacts, or side (side impact and head protection window curtain airbags) impacts which may cause significant injuries, however, no system available today can totally eliminate injuries and fatalities.
Page 78 If you have any problems, please see your authorized Mercedes-Benz Center. • Do not lean with your head or chest close to the steering wheel or dashboard.
Page 79: Safety Guidelines For The Seat Belt, Emergency Tensioning Retractor And Airbag
Mercedes-Benz Center at an child additional cost. Please contact your local authorized Mercedes-Benz Center or call our Client Assistance Center at 1-800-FOR-MERCedes (1-800-367-6372) for details. Safety guidelines for the seat belt, emergency...
Page 80 “SRS” inoperative or causing unintended airbag deployment. Work on the “SRS” must therefore only be performed by an authorized Mercedes-Benz Center. • For your protection and the protection of others, when scrapping the airbag unit or emergency tensioning retractor, our safety instructions must be followed.
Page 81: Infant And Child Restraint Systems
Instruments Operation Driving and controls Restraint systems Infant and child restraint systems We recommend all infants and children be properly re- strained at all times while the vehicle is in motion. All lap-shoulder belts except the driver’s seat belt have special seat belt retractors for secure fastening of child restraints.
Page 82 Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart installed in the vehicle to deactivate the passenger front airbag when it is properly installed.
Page 83 Instruments Operation Driving and controls Restraint systems Installation of infant and child restraint systems To secure a tether strap to the anchorage, securely fasten the hook (1), which is part of the tether strap, to the anchorage ring (2). For safety, please make sure that the hook has attached to the ring beyond the safety catch, as illustrated.
Page 84: Steering Wheel Adjustment
Steering wheel adjustment Turn electronic key in steering lock to position 1 or 2 (with the driver’s or front passenger’s door open, the steering wheel can also be operated with the electronic key removed or in steering lock position 0). Steering wheel adjustment Instruments Operation...
Page 85: Rear View Mirrors
Instruments Operation Driving and controls Rear view mirrors Rear view mirrors Inside rear view mirror Manually adjust the mirror. Use your inside mirror to determine the size and distance of objects seen in the passenger-side convex mirror. Antiglare night position With the electronic key in steering lock position 2, the mirror reflection brightness responds to changes in light sensitivity.
Page 86 Exterior rear view mirrors The switch is located on the center console. Rear view mirrors Instruments Operation Driving and controls Turn electronic key in steering lock to position 1 or 2. First select the mirror to be adjusted - press button: % Left mirror &...
Page 87 Instruments Operation Driving and controls Rear view mirrors Note: The exterior mirrors have electrically heated glass. The heater switches on automatically, depending on outside temperature. If an exterior mirror housing is forcibly pivoted from its normal position, it must be repositioned by applying firm pressure until it snaps into place.
Page 88 Parking position The passenger-side exterior mirror can be adjusted and programmed to assist the driver during parking maneuvers (e.g. to observe the curb or other objects close to the vehicle). With electronic key in steering lock position 2, and the exterior rear view mirror switch in the passenger-side position, the passenger-side mirror will be turned downward when placing the gear selector lever in...
Page 89: Instrument Cluster
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instrument cluster Instrument cluster...
Page 90 Push buttons for intensity of instrument lamps, see page 89 Push button for resetting trip odometer, see page 91, or to acknowledge a malfunction or warning message, see page 108 Coolant temperature gauge, see page 90 Fuel gauge with reserve and fuel cap placement warning lamp, see page 244 Outside temperature indicator, see page 90 Left turn signal indicator lamp, see combination...
Page 91 Instruments Operation Driving and controls Instrument cluster Indicator lamps in the instrument cluster High beam ABS malfunction, see page 245 Brake fluid low (except Canada). BRAKE Parking brake engaged, see page 243 Brake fluid low (Canada only). Parking brake engaged, see page 243 BAS malfunction, see page 245 ESP malfunction, see page 245 Fasten seat belts, see page 246...
Page 92 Activating instrument cluster display The instrument cluster is activated by: • Opening the door. • Pressing button J, V or W on the instrument cluster. • Turning the electronic key in steering lock to position 1 or 2. • Switching on the exterior lamps. Instrument cluster Instruments Operation...
Page 93 The engine should not be operated with the coolant temperature in the red zone. Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty. Warning! • Driving when your engine is badly overheated can cause some fluids which may have leaked into the engine compartment to catch fire.
Page 94 Avoid this engine speed, as it may result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. To help protect the engine, the fuel supply is interrupted if the engine is operated within the red marking.
Page 95: Multifunction Steering Wheel, Multifunction Display
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Multifunction steering wheel, multifunction display...
Page 96 Depending on your vehicle’s equipment, you may use the buttons on the multifunction steering wheel to call up, control and set the following systems in the multifunction display: Trip odometer and main odometer, see page 96 Vehicle speed, see page 96 Flexible service system (FSS), see page 114 Engine oil level indicator, see page 117 Audio systems, see page 97...
Page 97 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Multifunction display Multifunction steering wheel Instrument Practical hints cluster display Turn the electronic key in steering look to position 1 or 2. Press button: è for next system ÿ for previous system j for next display in system k for previous display in system æ...
Page 98 Press the è or ÿ button repeatedly until the required system is displayed. Pressing the è button advances the display to the next system. Pressing the ÿ button returns the display to the previous system. You may call up additional displays in some systems by pressing the j or k button.
Page 99: Trip And Main Odometer, Vehicle Speed, Fss And Engine Oil Level Display
Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Trip and main odometer, vehicle speed, FSS and engine oil level display Instrument Practical hints Car care cluster display Trip odometer and main odometer See page 88 for instructions on resetting the trip odometer.
Page 100: Audio Systems
Audio systems Radio Multifunction steering wheel, multifunction display Instruments Operation Driving and controls Audio system is switched off. The radio is switched on. Wave band setting and memory location number, where appropriate. Station frequency. This only appears when “MEMORY” rather than “FREQUENCY”...
Page 101: Cd Player
Instruments Operation Driving and controls Multifunction steering wheel, multifunction display CD player (optional) Instrument Practical hints Car care cluster display Audio system is switched off. The CD player is switched on. The number of the CD currently playing is displayed if you are using a CD changer.
Page 102: Cassette Player
Cassette player Multifunction steering wheel, multifunction display Instruments Operation Driving and controls Audio system is switched off. The cassette player is switched on. Side being played. The radio must be switched on. The cassette player must be switched on. Press the è or ÿ button repeatedly until display (2) appears.
Page 103: Telephone
Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Telephone Telephone book Instrument Practical hints Car care cluster display The telephone is switched off. The vehicle is currently outside the transmitter or receiver range. The telephone is ready for use. Name selected from the telephone book.
Page 104 The telephone must be switched on. Press the è or ÿ button repeatedly until display (3) appears. Refer to the separate telephone instruction manual. Pressing j or k “browses” alphabetically forwards or backwards through the telephone book, providing it was previously downloaded. See telephone operator’s manual for details concerning downloading.
Page 105: Redialing
Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Redialing Instrument Practical hints Car care cluster display The telephone is ready for use. Number or name stored in the redial memory. Number in the redial memory — redialing has commenced.
Page 106 The telephone must be switched on. Press the è or ÿ button repeatedly until the display (1) appears. Pressing the í button activates the redial memory and the most recently dialed number is displayed. Pressing the j or k button “browses” forwards or backwards through the redial memory.
Page 107: Incoming Call
Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Incoming call The telephone must be switched on. Instrument Practical hints Car care cluster display “CALL” — you are being called Press the í button to answer the call. Press the ì button to hang up or if you do not wish to answer the incoming call.
Page 108: Navigation System
Navigation system (optional) Multifunction steering wheel, multifunction display Instruments Operation Driving and controls The navigation system is switched off. The navigation system is switched on but no destination has been specified. The navigation system is switched on and destination guidance is active. Press the è...
Page 109: Trip Computer
Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Trip computer Instrument Practical hints Car care cluster display “AFTER START” — trip odometer records distance from first engine start after more than five hours of electronic key not being in steering lock position 2 “AFTER RESET”...
Page 110 Press the button è or ÿ repeatedly until the display (1) appears. Press the j or k button until the display for trip odometer memory “AFTER START” (1) and “AFTER RESET” (2), or the display (3) for estimated driving range remaining and fuel tank contents appears.
Page 111: Malfunction Message Memory
Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Malfunction message memory Instrument Practical hints Car care cluster display There are no messages stored in the system. Number of messages stored in the system. Press the è or ÿ button repeatedly until the message memory (1 or 2) is displayed.
Page 112 Mercedes-Benz Center to address the malfunction and warning messages. See page 247. Instrument Practical hints...
Page 113: Individual Settings
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Individual settings...
Page 114 Preliminary display of the individual settings “SET TIME – HOURS” (only vehicles without COMAND) “SET TIME – MINUTES” (only vehicles without COMAND) “12/24 O’CLOCK”, the unit set is displayed in the instrument cluster (only vehicles without COMAND) “TEMP. INDICATOR” — the unit set is displayed in the outside temperature display in the instrument cluster and in the automatic air conditioner display “DISPLAY VALUES IN”...
Page 115 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Press the è or ÿ button repeatedly until the individual setting preliminary display (1) appear. Press the j or k button until the required setting menu (2 to 8) is displayed. Pressing the æ...
Page 116: Setting The Audio Volume
To return setting menus (4 to 8) to their factory settings: • Call up the individual setting preliminary display (1). • Press the J button in the instrument cluster for approximately 3 seconds. Display (9) will appear. • Press the J button once more, the message “RESET TO FACTORY SETTINGS”...
Page 117: Flexible Service System (Fss)
Instruments Operation Driving and controls Flexible service system Flexible service system (FSS) (service indicator) 120 140 20km/h The FSS permits a flexible service schedule that is directly related to the operating conditions of the vehicle. The symbol 9 or ½ appears together with a message in the multifunction indicator prior to the next suggested service.
Page 118 Any such days not counted by the FSS can be added by your Mercedes-Benz Center. The interval between services is determined by the type of driving for which the vehicle is used. For example,...
Page 119 Driving and controls Flexible service system Following a completed A or B service the Mercedes-Benz Center sets the counter mileage to 10 000 miles (Canada: 15 000 km) and 365 days. The counter can also be set by any individual. To do so: Turn the electronic key in steering lock to position 2.
Page 120: Engine Oil Level Indicator
Engine oil level indicator To check the engine oil level, park vehicle on level ground, with engine at normal operational temperature. Check oil level approximately 5 minutes after stopping the engine, allowing for the oil to return to the oil pan. Engine oil level indicator Instruments Operation...
Page 121: Engine Oil Consumption
Excessive oil must be siphoned or drained off. It could cause damage to the engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. The message “PERF. SERV. ON TIME” (perform service [engine oil level check] on time) will be displayed if a proper oil level check cannot be performed.
Page 122: Exterior Lamp Switch
Exterior lamp switch D Off C Parking lamps (also side marker lamps, taillamps, licence plate lamps, instrument panel lamps) Canada only: When the engine is running, the low beam is additionally switched on. Exterior lamp switch Instruments Operation Driving and controls B Parking lamps plus low beam or high beam headlamps (combination switch pushed forward).
Page 123: Night Security Illumination
When exiting the vehicle after driving with the exterior lamps on, they switch on again for added illumination for approximately 30 seconds after closing the last door. The lamp-on time period can be changed at your Mercedes-Benz Center. Technical Index data...
Page 124: Headlamp Cleaning System
Headlamp cleaning system (optional) Headlamp cleaning system Instruments Operation Driving and controls The switch is located in the center console. The headlamp washer can be activated with the electronic key in steering lock position 2. Briefly press symbol side of switch. P82.15-2007-26 Instrument Practical hints...
Page 125: Combination Switch
Instruments Operation Driving and controls Combination switch Combination switch Low beam (exterior lamp switch position B) High beam (exterior lamp switch position B) Instrument Practical hints cluster display High beam flasher (high beam available independent of exterior lamp switch position) Turn signals, right Turn signals, left To signal minor directional changes, such as changing...
Page 126 Control for windshield wiper /washer system: Push briefly for single wipe without adding washer fluid (use only when windshield is wet). Push past detent and hold to activate wiper and washer. Windshield wiper Combination switch Instruments Operation Driving and controls 0 Wiper off Intermittent wiping Vehicles with optional rain sensor:...
Page 127: Rear Window Wiper/Washer
Instruments Operation Driving and controls Rear window wiper/washer Note: The windshield washer reservoir, hoses and nozzles are automatically heated. For windshield and headlamp washer fluid mixing ratio, see page 271 Windshield wiper smears If the windshield wiper smears the windshield, even during rain, activate the washer system as often as necessary.
Page 128: Hazard Warning Flasher Switch
Hazard warning flasher switch Hazard warning flasher Instruments Operation Driving and controls The hazard warning flasher can be activated with the switch located in the dashboard. To activate hazard warning flasher, press switch once. To deactivate, press switch again. Note: With the hazard warning flasher activated, the combination switch in position for either left or right turn, and the electronic main key in steering lock...
Page 129: Automatic Climate Control
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Automatic climate control...
Page 130 Air volume control for center air outlets, turn wheel up to open. Air volume control for side air outlet and side window defroster outlet. To open side air outlets: Turn wheel to position i. To open defroster outlets: Turn wheel to position l. Center air outlets, adjustable Side air outlet, adjustable Side defroster outlet...
Page 131: Display And Controls
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Display and controls Press the desired button to activate, indicator lamp is on while activated. U Automatic mode f Raise temperature g Lower temperature P Defrost O Air recirculation e Activated charcoal filter...
Page 132: Basic Setting
Basic setting - Automatic mode Press left and right U button for automatic mode. Simultaneously press both f and g buttons for temperature setting of 72°F. Air volume and distribution are controlled automatically. This setting can be used all year around. Economy The function of this setting corresponds to the automatic mode.
Page 133: Rear Window Defroster
Instruments Operation Driving and controls Automatic climate control Rear window defroster Turn electronic key in steering lock to position 2. To select, press F button. To cancel, press F button again. Notes: Heavy accumulation of snow and ice should be removed before activating the defroster.
Page 134: Air Recirculation
Air recirculation This mode can be selected to temporarily reduce the entry of annoying odors or dust into the vehicle’s interior. Outside air is not supplied to the car’s interior. To select, press O button. To cancel, press O button again. The system will automatically switch from recirculated air to fresh air •...
Page 135: Activated Charcoal Filter
Instruments Operation Driving and controls Automatic climate control Activated charcoal filter An activated charcoal filter markedly reduces bad odors and removes pollutants from the air entering the passenger compartment. To select, press e button. To cancel, press e button again. The blower speed is slightly increased to supply a constant volume of air.
Page 136: Front Center Console Compartment Ventilation
Front center console compartment ventilation The front center console compartment has its own air outlet. To open: Push lever down. To close: Push lever up. The air volume is dependent on the setting of the • air volume control • air distribution control •...
Page 137: Rear Passenger Compartment Adjustable Air Outlet
Instruments Operation Driving and controls Automatic climate control Rear passenger compartment adjustable air outlet To open air outlet, rotate wheel (1) upward. The air outlet is adjustable. Instrument Practical hints cluster display Important This vehicle is equipped with an air conditioner system that uses R-134a (HFC: hydrofluorocarbon) as a refrigerant.
Page 138: Operation
These malfunctions might seriously impair the operating safety of your vehicle. We recommend that you have any service work or alternations on electronic components done in an authorized Mercedes-Benz Center. 1 Optional equipment Dolby and the double-D symbol Laboratories Licensing Corporation. The Dolby noise reduction system is manufactured under licence from Dolby Laboratories Licensing Corporation.
Page 139 Instruments Operation Driving and controls Audio system Operating and display elements On/off, volume, see page 139 Telephone mode selector, see page 151 Seek, see page 141, 145 and 149 Radio mode selector, see page 141 Tune, see page 141 and 142 Fast forward/reverse, see page 145 and 149 Instrument Practical hints...
Page 140 Soft keys for radio band selection, see page 141 tone controls, see page 139 scan, see page 142 Tape eject, see page 144 Tape track select, see page 144 Dolby, see page 146 CD random /repeat, see page 150 Tape mode selector, see page 143 Antitheft system If the power supply to the radio has been...
Page 141 Instruments Operation Driving and controls Audio system Entering the code number Switch on the radio.“CODE” will appear on the display. Using the buttons on the alpha-numeric keypad, enter the five digit code. Confirm by pressing the “OK” key. If an incorrect code has been entered and confirmed, “CODE”...
Page 142 Operation Switching on and off Press the control knob The radio is switched off when the ignition key is turned to position 0 or removed from the ignition. The radio is switched on again when the ignition key is turned to position 1 or 2.
Page 143: Audio System
Instruments Operation Driving and controls Audio system Fader Press the AUD key repeatedly until “FADER” appears on the display. Press the “R” key to move the sound to the rear speakers or the “F” key to move the sound to the front speakers. Balance Press the AUD key repeatedly until “BALANCE”...
Page 144 Radio mode Selecting radio mode Press button. Selecting the band Press the key located below the desired band. The band selected is shown in the top line of the display. Frequency ranges: Audio system Instruments Operation Driving and controls Manual tuning The first three tuning steps will take place without muting.
Page 145 Instruments Operation Driving and controls Audio system Scan tuning Press the SC key. Each strong receivable station on the band selected will be tuned in for 8 seconds. The first scan will tune only the stations with a high signal strength. The second scan will tune every receivable station.
Page 146 Cassette mode Note: Vehicles equipped with the COMAND system do not come with a factory installed cassette mechanism. A standard 1/8” stereo phono plug for auxiliary audio input (located in glove box) is provided for connection of a portable battery operated cassette player or any other portable device which uses a headphone output.
Page 147 Instruments Operation Driving and controls Audio system Important! If the display is in the down position for more than 20 seconds, 2 successive beeps will be heard. This will continue at 5 second intervals until the display is returned to its normal position. The radio will switch to cassette mode.
Page 148 Track search forwards /backwards Press the “SEEK FWD” will be shown on the display and the track search will run the tape forwards to the start of the next track. Press the “SEEK RWD” will be shown on the display and the track search will run the tape backwards to the start of the track currently playing.
Page 149 Instruments Operation Driving and controls Audio system Scanning Press the “SC” key. Each track on the cassette will be played for 8 seconds in ascending order. Note: The beginning of a track can only be located if there is a break of at least 4 seconds between tracks.
Page 150 CD mode General notes on CD mode Should excessive temperatures occur while in CD mode, “TEMP HIGH” will appear in the display and muting will take place. The unit will then switch back to radio mode until the temperature has decreased to a safe operating level.
Page 151 Instruments Operation Driving and controls Audio system CD changer installed CD changer CD magazine CD tray If a CD changer is installed, it can be operated from the front control panel of the radio. A loaded magazine must be installed for CD playing. 1 Optional equipment Instrument Practical hints...
Page 152 If there is no CD in the selected magazine slot, “NO CD” and the corresponding slot number will be displayed (e.g.“NO CD3”). After the last track on a CD has been played, the next CD will automatically be selected and played.
Page 153 Instruments Operation Driving and controls Audio system Random play/repeat function The tracks of the current CD are played in random order when the random feature (RDM) is selected. Press the RDM key to switch on, and press RDM again to switch off.
Page 154 Telephone operation Various functions of the Mercedes-Benz integrated cellular telephone can be performed and displayed via the car radio. Further instructions for operating the car telephone can be found in the operation guide for the cellular telephone Switching the telephone on and off Switching on: Press the button, “TEL”...
Page 155 Instruments Operation Driving and controls Audio system Switching between name search and number search Press ABC key - Name search Press NUM key - Number search Searching and selecting phone book entries by name Press the ABC key. The current name is shown on the display.
Page 156 Failure of one of the components can lead to malfunctions of the other components. Please contact your authorized Mercedes-Benz Center or call 1-800-FOR-MERCedes for more information in the event of a malfunction. 1 Optional equipment...
Page 157: Power Windows
Instruments Operation Driving and controls Interior equipment Power windows Power window switches located on center console Switches for: left, front left, rear right, front right, rear Switch for rear door window override Instrument Practical hints cluster display P54.25-2119-26 Power window switches located in rear doors Individual switches (rear doors) Turn electronic key in steering lock to position 1 or 2.
Page 158 Express opening and closing Press switch k or j past resistance point and release — window opens or closes completely. To interrupt procedure, briefly press k or j. If the upward movement of the window is blocked during the closing procedure, the window will stop during the last few inches before closure and open slightly.
Page 159: Sliding / Pop-Up Roof
Instruments Operation Driving and controls Interior equipment Synchronizing power windows If the power supply was interrupted (battery disconnected or low), the windows cannot be opened or closed by the Express feature. To resynchronize the express feature, press j side of power window switch until the window is completely closed and hold for additional 2 seconds.
Page 160 To open, close, raise or lower the sliding/pop-up roof: Move switch to resistance point in the required direction. Release the switch when the roof has reached the required position. The switch is illuminated when the exterior lamps are switched on (except standing lamps). Warning! When closing the sliding/pop-up roof, be sure that there is no danger of anyone being harmed by the...
Page 161 Instruments Operation Driving and controls Interior equipment Express opening of sliding /pop-up roof Move switch past resistance point and release — the sliding/pop-up roof slides open half-way. Move again to open fully. To interrupt procedure, briefly move switch in any direction.
Page 162: Interior Lighting
Interior lighting Automatic interior lighting Press once and the interior lighting is activated. Interiors lamps are switched on, and off (soft fade) delayed, when unlocking or locking the vehicle, or when opening or closing a door. However, there will be no (soft fade) delay when the electronic key is in steering lock position 2.
Page 163: Interior Equipment
Instruments Operation Driving and controls Interior equipment Sun visors Swing sun visors down to protect against sun glare. If sunlight enters through a side window, disengage visor from inner mounting, pivot to the side and slide it to the desired position. Instrument Practical hints Car care...
Page 164: Interior
Interior Warning To help avoid personal injury during a collision or sudden maneuver, exercise care when stowing things. Put luggage or cargo in the trunk if possible. Do not pile luggage or cargo higher than the seat backs. Do not place anything on the shelf below the rear window.
Page 165: Glove Box
Instruments Operation Driving and controls Interior equipment Glove box Unlocking: Turn mechanical key to vertical position and remove. Locking: Turn mechanical key to the right and remove. Opening: Pull on handle. The glove box can be locked and unlocked with the mechanical key.
Page 166: Storage Compartment Above Ashtray In Center Console
Storage compartment above ashtray in center console To open: Touch bottom of cover slightly. The cover opens automatically. Interior equipment Instruments Operation Driving and controls Storage compartments in center console P68.20-2260-26 To open compartment in armrest: Lift lid with handle (4). To open compartment under armrest: Lift lid with handle (5).
Page 167: Cup Holder In Center Console
Instruments Operation Driving and controls Interior equipment Cup holder in center console To open cover: Touch top of cover (6) slightly. The cover opens automatically. To open cup holder: Briefly press button (7). The cup holder opens automatically. To store cup holder: Push button (7) down until cup holder engages.
Page 168: Ashtrays
Ashtrays Center console, front By touching the bottom of the cover lightly, the ashtray opens automatically. Prior to removing the ashtray insert, move the gear selector lever to position “N”. Interior equipment Instruments Operation Driving and controls To remove ashtray: Push sliding knob (1) toward the right to eject the insert.
Page 169 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Rear doors To remove ashtray: Push left and right sides down and pull out the ashtray. To install ashtray: Install top of ashtray, push bottom part in to engage.
Page 170: Lighter
Lighter Turn electronic key in steering lock to position 1 or 2. Push in lighter (1); it will pop out automatically when hot. Interior equipment Instruments Operation Driving and controls Warning! Never touch the heating element or sides of the lighter, they are extremely hot, hold at knob only.
Page 171: Split Rear Bench Seat
Instruments Operation Driving and controls Interior equipment Split rear bench seat The two sections can be folded down separately to enlarge the cargo area. 1. Slip seat belt webbing behind belt retainer (1) and move buckle latch plate upward to belt outlet. 2.
Page 172 Warning! Do not drive the vehicle without head restraints. Always reinstall head restraints when returning cushions to seating use. Head restraints help reduce injuries should an accident occur. Interior equipment Instruments Operation Driving and controls P91.12-2050-26 Set up: Pull backrest up until it locks in its upright position. A red indicator (5) on the pull locking handle is visible in the unlocked position.
Page 173 Instruments Operation Driving and controls Interior equipment Enlarging cargo area: The cargo area can be enlarged by placing the seat cushions in a vertical position and removing them. To remove each seat cushion, pull up the lever (6) on the underside of the seat and pull the seat cushion out its hinge pins (7).
Page 174 Warning! In an accident, during hard braking or sudden maneuvers, loose items will be thrown around inside the vehicle, and can cause injury to vehicle occupants unless the items are securely fastened in the vehicle. Always lock backrest in its upright position when rear seat bench is occupied, or the extended cargo area is not in use.
Page 175 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Luggage cover: Pull out lower blind, draw it over the luggage and engage into track on the D pillar. When the tailgate is opened the blind is lifted up automatically so that it need not be retracted for loading or unloading the vehicle.
Page 176 Partition net: Pull out upper blind (safety net) and engage into eyelets on the roof (1). This is a particularly important safety factor when the vehicle is loaded higher than the top of the seat backrest. Interior equipment Instruments Operation Driving and controls Warning!
Page 177: Rear-Facing Bench Seat
Instruments Operation Driving and controls Interior equipment Rear-facing bench seat The rear-facing bench seat can be unfolded to enlarge the seating area. By pressing down on the handle, lift the backrest into place. Raise the seat cushion in a similar manner. Hook the safety belts into the brackets (1) provided.
Page 178 Note: If the rear-facing bench seat is to be occupied, the forward-facing split rear bench seat must be equipped with head restraints. To stow the rear-facing bench seat, proceed in reverse order, pulling the seat cushion up by its strap (2). Interior equipment Instruments Operation...
Page 179: Loading Instructions
Instruments Operation Driving and controls Interior equipment Loading instructions The handling characteristics of a fully loaded vehicle depend greatly on the load distribution. It is therefore recommended to load the vehicle according to the illustrations shown, with the heaviest items being placed towards the front of the vehicle.
Page 180: Cargo Tie-Down Rings
Warning! Always fasten items being carried as securely as possible. In an accident, during hard braking or sudden maneuvers, loose items will be thrown around inside the vehicle, and can cause injury to vehicle occupants unless the items are securely fastened in the vehicle.
Page 181: Parcel Net In Front Passenger Footwell
Cellular telephone The vehicle is prepared for the installation of a cellular telephone. For further information and installation contact your authorized Mercedes-Benz Center. Warning! Some jurisdictions prohibit the driver from using a cellular telephone while driving a vehicle. Whether...
Page 182: Garage Door Opener
If you should experience difficulties with programming the transmitter, contact your authorized Mercedes-Benz Center, or call Mercedes-Benz Client Assistance Center (in the USA only) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100. For operation in the USA only: This device complies with Part 15, Subpart C, Section 209 of the FCC Rules.
Page 183 Instruments Operation Driving and controls Garage door opener Programming or reprogramming the integrated remote control: 1. Turn electronic key in steering lock to position 1 or 2. 2. Hold the end of the hand-held transmitter of the device you wish to train approximately 2 to 5 inches (5 cm to 12 cm) away from the surface of the integrated remote control located on the inside rear view mirror, keeping the indicator lamp in view.
Page 184 Rolling code programming: To train a garage door opener (or other rolling code devices) with the rolling code feature, follow these instructions after completing the “Programming” portion of this text. (A second person may make the following training procedures quicker and easier.) 1.
Page 185 Instruments Operation Driving and controls Garage door opener Operation of remote control: 1. Turn electronic key in steering lock to position 1 or 2. 2. Select and press the appropriate button to activate the remote controlled device. The integrated remote control transmitter continues to send the signal as long as the button is pressed –...
Page 186 Driving Control and operation of radio transmitters ... 184 The first 1 000 miles (1 500 km) ... 185 Maintenance ... 185 Tele Aid... 186 Catalytic converter... 196 Emission control ... 197 Steering lock... 198 Starting and turning off the engine ... 200 Automatic transmission...
Page 187: Control And Operation Of Radio Transmitters
Instruments Operation Driving and controls Control and operation of radio transmitters Control and operation of radio transmitters COMAND, radio and telephone Warning! Please do not forget that your primary responsibility is to drive the vehicle. Only operate the COMAND (Cockpit Management and Data System), radio or telephone conditions permit.
Page 188: The First 1 000 Miles (1 500 Km)
See Flexible service system (FSS) on page 114. We strongly recommend that you have your vehicle serviced by your authorized Mercedes-Benz Center, in accordance with the Service Booklet at the times called for by the FSS.
Page 189: Tele Aid
Instruments Operation Driving and controls Tele Aid Tele Aid Important! The initial activation of the Tele Aid system may only be performed by completing the subscriber agreement and placing an acquaintance call using the “SOS” button. Failure to complete either of these steps will result in a system that is not activated.
Page 190 WORKSHOP” is not displayed in the multifunction display after the system self check. If a malfunction is indicated as outlined above, have the system checked at the nearest Mercedes-Benz Center as soon as possible. Emergency calls An emergency call is initiated automatically: •...
Page 191 Instruments Operation Driving and controls Tele Aid The Tele Aid system is available if: • it has been activated and is operational. Activation requires a subscription for monitoring services and cellular air time • the relevant cellular phone network and GPS signals are available and pass the information on to the response center.
Page 192: Initiating An Emergency Call Manually
Initiating an emergency call manually Tele Aid Instruments Operation Driving and controls Briefly press on cover (1) – the cover will open. Press the SOS button (2) briefly (for longer than 2 seconds). The indicator lamp in the SOS button (2) will flash until the emergency call is concluded.
Page 193: Roadside Assistance Button
“TELE AID – ROADSIDE ASSISTANCE CALL ACTIVE” appears in the multifunction display. The nature of the need for assistance can then be described. The Mercedes-Benz Roadside assistance dispatcher will either dispatch a qualified Mercedes-Benz technician or arrange to tow your vehicle to the nearest Mercedes-Benz Center.
Page 194: Information Button
“TELE AID – INFO CALL ACTIVE” appears in the multifunction display. Information regarding the operation of your vehicle, the nearest Mercedes-Benz Center or Mercedes-Benz USA products and services is available to you. For more details concerning Tele Aid, please visit www.mbusa.com and use your ID and password, sent to...
Page 195 Tele Aid system has detected a fault or the service is not currently active, and may not initiate a call. Visit your Mercedes-Benz Center and have the system checked or contact the Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada) as soon as possible.
Page 196 If the indicator lamp continues to flash or the system does not reset, contact the Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada), or Mercedes-Benz Client Assistance at 1-800-FOR-MERCedes (1-800-367-6372) in the USA or Customer Service at 1-800-387-0100 in Canada.
Page 197 In the case you have your vehicle locked unintentionally (e.g. key inside vehicle), and the reserve key is not handy, contact the Mercedes-Benz Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada). You will be asked to provide your password which you provided when you completed the subscriber agreement.
Page 198 Stolen vehicle tracking services In the event your vehicle was stolen, report the incident to the police who will issue a numbered incident report. Pass this number on to the Mercedes-Benz Response Center. The Response Center will then attempt to covertly contact the vehicle’s Tele Aid system.
Page 199: Catalytic Converter
Driving and controls Catalytic converter Catalytic converter Your Mercedes-Benz is equipped with monolithic type catalytic converters, an important element in conjunction with the oxygen sensors to achieve substantial control of the pollutants in the exhaust emissions. Keep your vehicle in proper operating condition by following our recommended maintenance instructions as outlined in your Service Booklet.
Page 200: Emission Control
Mercedes- Benz authorized Center technicians. Engine adjustments should not be altered in any way. Moreover, the specified service jobs must be carried out regularly according to Mercedes-Benz servicing requirements. For details refer to the Service Booklet. Emission control Instruments...
Page 201: Steering Lock
Instruments Operation Driving and controls Steering lock Steering lock The electronic key can be withdrawn in this position only. The steering is locked when the electronic key is removed from the steering lock. If necessary, move steering wheel slightly to allow the locking mechanism to engage.
Page 202 Important! If the electronic key is left in the steering lock position 0 for an extended period of time, it can no longer be turned in the lock. In this case, remove electronic key from steering lock and reinsert. Caution! To prevent accelerated battery discharge and a possible dead battery, always remove the electronic key from the steering lock.
Page 203: Starting And Turning Off The Engine
In areas where temperatures frequently drop below -4°F (–20°C) we recommend that an engine block heater be installed. Your authorized Mercedes-Benz Center will advise you on this subject, see page 218. Turning off Turn the electronic key in the steering lock to position 0 to stop the engine.
Page 204: Automatic Transmission
Automatic transmission Automatic transmission Instruments Operation Driving and controls The automatic transmission selects individual gears automatically, dependent upon • Selector lever position • Program mode selector • Accelerator position • Vehicle speed The gear shifting process is continuously adapted, dependent on the driving style, the driving situation and the road characteristics.
Page 205 Instruments Operation Driving and controls Automatic transmission Driving The selector lever is automatically locked while in position “P”. To move the selector lever out of position “P”, the service brake pedal must be firmly depressed before the shift lock will release. Shift selector lever to the desired position only when the engine is idling normally and the service brake is applied.
Page 206 Stopping For brief stops, e.g. at traffic lights, leave the transmission in gear and hold vehicle with the service brake. For longer stops with the engine idling, shift into “N” or “P” and hold the vehicle with the service brake. When stopping the vehicle on an uphill gradient, do not hold it with the accelerator, use the brake.
Page 207 Instruments Operation Driving and controls Automatic transmission Selector lever position The current selector lever position is indicated in the gear range indicator display. The automatic gear shifting process can be adapted to specific operating conditions using the selector lever. Instrument Practical hints Car care cluster display...
Page 208 Coasting the vehicle, or driving for any other reason with selector lever in “N” can result in transmission damage that is not covered by the Mercedes-Benz Limited Warranty. Drive The transmission automatically upshifts through 5th gear. Position “D” provides optimum driving characteristics under all normal operating conditions.
Page 209 Instruments Operation Driving and controls Automatic transmission Press and hold selector lever in the æ direction: The transmission will shift from the current gear directly to gear range “D”. Warning! On slippery road surfaces, never downshift in order to obtain braking action. This could result in drive wheel slip and reduced vehicle control.
Page 210 Gear ranges: Upshift through 4th gear only. Suitable for performance driving. Upshift through 3rd gear only. Suitable for moderately steep hills. Since the transmission does not shift higher than 3rd gear, this gear selection will allow use of the engine’s braking power downhill.
Page 211 Instruments Operation Driving and controls Automatic transmission Program mode selector switch The transmission is provided with a selector switch (1) for Standard “S” and Winter /Wet (snow and ice) “W” program modes. Instrument Practical hints Car care cluster display Standard mode Press switch on symbol “S”.
Page 212 5. Restart the engine. 6. Move selector lever to position “D” (for 2nd gear), or move selector lever to position “R” (for reverse gear). Have the transmission checked at your authorized Mercedes-Benz Center as soon as possible. Instrument Practical hints Car care...
Page 213: Parking Brake
Instruments Operation Driving and controls Parking brake Parking brake Instrument Practical hints Car care cluster display To engage, firmly depress parking brake pedal. When the electronic key is in steering lock position 2, the brake warning lamp in the instrument cluster should come on brightly.
Page 214: Driving Instructions
• allow engine to warm up under low load use, • avoid frequent acceleration and deceleration, • have all maintenance work performed at regular intervals by an authorized Mercedes-Benz Center. Fuel consumption is also increased by driving in cold weather, in stop-and-go traffic, on short trips and in hilly country.
Page 215: Power Assistance
Have the brake system inspected at an authorized Mercedes-Benz Center immediately. All checks and service work on the brake system should be carried out by an authorized Mercedes-Benz Center. Install only brake pads and brake fluid recommended by Mercedes-Benz. Warning!
Page 216: Driving Off
When starting off on a slippery surface, do not allow one drive wheel to spin for an extended period with the ESP switched off. Doing so may cause serious damage to the drive train which is not covered by the Mercedes-Benz Limited Warranty. Driving instructions...
Page 217: Tires
Inspect the tires and under the vehicle for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for repairs. Tread wear indicators (TWI) are required by law. These...
Page 218 Specified tire pressures must be maintained. This applies particularly if the tires are subjected to high loads (e.g. high speeds, heavy loads, high ambient temperatures). Warning! Do not drive with a flat tire. A flat tire affects the ability to steer or brake the vehicle. You may lose control of the vehicle.
Page 219: Snow Chains
Snow chains Use only snow chains that are tested and recommended by Mercedes-Benz. Your authorized Mercedes-Benz Center will be glad to advise you on this subject. Chains should only be used on the rear wheels. Follow the manufacturer’s mounting instructions.
Page 220: Winter Driving Instructions
Winter driving instructions The most important rule for slippery or icy roads is to drive sensibly and to avoid abrupt acceleration, braking and steering maneuvers. Do not use the cruise control system under such conditions. When the vehicle is in danger of skidding, move selector lever to position “N”.
Page 221: Block Heater
Driving instructions Winter driving Have your vehicle winterized at your authorized Mercedes-Benz Center before the onset of winter. • Change the engine oil if the engine contains an oil which is not approved for winter operation. For viscosity (SAE/CCMC class) and filling quantity, see page 322.
Page 222: Deep Water
Traveling abroad Abroad, there is a widely-spread Mercedes-Benz service network at your disposal. If you plan to travel into areas which are not listed in the index of your Mercedes-Benz Center directory, you should request pertinent information from your authorized Mercedes-Benz Center.
Page 223: Cruise Control
Instruments Operation Driving and controls Driving systems Cruise control The cruise control allows you to drive in a more relaxed manner, for example over long distances, as it automatically maintains the set speed by actively regulating the throttle setting. Any given speed above approximately 25 mph (40 km /h) can be maintained with the cruise control by operating the lever.
Page 224 If the cruise control cancels by itself and remains inoperative until the engine is restarted, have the system checked at your authorized Mercedes-Benz Center as soon as possible. Resume If the lever is briefly pushed to position 4 when...
Page 225 Instruments Operation Driving and controls Driving systems Notes: If the engine does not brake the vehicle sufficiently while driving on a downgrade, the speed you set on the cruise control may be exceeded. In this case the automatic transmission shifts down (max. to 3rd gear) to maintain the set cruise control speed by using the engine’s braking power.
Page 226: Brake Assist System (Bas)
Brake assist system (BAS) Warning! BAS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded. The BAS cannot prevent accidents, including those resulting from excessive speed in turns, following another vehicle too closely, or aquaplaning.
Page 227 With the ABS malfunctioning, the BAS and ESP is also switched off. Both malfunction indicator lamps come on with the engine running. If a BAS warning message is displayed, have the BAS and ESP checked at your authorized Mercedes-Benz Center as soon as possible. Technical Index...
Page 228: Antilock Brake System (Abs)
Antilock brake system (ABS) Warning! Do not pump the brake pedal, rather use firm, steady brake pedal pressure. Pumping the brake pedal defeats the purpose for ABS and significantly reduces braking effectiveness. Important! The ABS improves steering control of the vehicle during hard braking maneuvers.
Page 229 If the ABS malfunction indicator lamp stays illuminated, have the system checked at your authorized Mercedes-Benz Center as soon as possible. Warning! ABS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase...
Page 230: Four Wheel Electronic Traction System (4Matic)
The warning lamp in the speedometer blinks at any speed as soon as one tire loses traction. Note: In winter operation, the maximum effectiveness of the 4MATIC is only achieved with Mercedes-Benz recommended M+S rated radial-ply tires and/ or snow chains. Instrument...
Page 231: Electronic Stability Program (Esp)
Instruments Operation Driving and controls Driving systems Electronic stability program (ESP) Warning! ESP cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded. The ESP cannot prevent accidents, including those resulting from excessive speed in turns, or aquaplaning.
Page 232 If the BAS malfunctions, the brake system functions in the usual manner, but without BAS. If the ESP warning message is displayed, have the BAS or ESP checked at your authorized Mercedes-Benz Center as soon as possible. With the ABS malfunctioning, the ESP is also switched off.
Page 233 Instruments Operation Driving and controls Driving systems ESP control switch ESP control switch located on center console. Press to switch ESP off ESP warning lamp v, located in speedometer dial, comes on. Press to switch ESP on ESP warning lamp v, located in speedometer dial, goes out.
Page 234 Avoid spinning of one drive wheel. This may cause serious damage to the drive train which is not covered by the Mercedes-Benz Limited Warranty. The ESP warning lamp, located in the speedometer dial, starts to flash at any vehicle speed as soon as the tires lose traction and the wheels begin to spin.
Page 235: Parking Assist (Parktronic)
Instruments Operation Driving and controls Parking system Parking assist (Parktronic) (optional) The Parktronic system assists the driver during parking maneuvers. It visually and audibly indicates the relative distance between the vehicle and an obstacle. The front area of the vehicle is monitored when driving forward.
Page 236 Sensors Sensors located in bumper (front bumper shown) Parking system Instruments Operation Driving and controls A total of 10 sensors (1) monitor the vehicle’s front and rear areas. Six sensors are located in the front bumper, four sensors in the rear bumper. For proper operation of the Parktronic always keep the sensors clean, especially at times of snow and ice.
Page 237 Instruments Operation Driving and controls Parking system Warning indicators Frame Segments Instrument Practical hints cluster display Visual and audible signals indicate to the driver the relative distance between the vehicle and an obstacle. Warning indicators for the front area are located above the center air outlets in the dashboard.
Page 238 Monitoring reach of sensors Front bumper: Center approx. 40 in Corner approx. 24 in Rear bumper: Center approx. 48 in Corner approx. 32 in Parking system Instruments Operation Driving and controls P54.65-2299-26 The first yellow segment lights up at these distances. Additional segments light up as the vehicle comes (100 cm) closer to the obstacle.
Page 239 After cleaning the sensors, turn electronic key in steering lock to position 2. If the defect continues to be displayed, have the system checked at your authorized Mercedes-Benz Center. Instrument Practical hints Car care...
Page 240: What You Should Know At The Gas Station
What you should know at the gas station Fuel supply Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious injury. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extinguish all smoking materials. Never allow sparks, flame or smoking materials near gasoline! What you should know at the gas station Instruments...
Page 241 Instruments Operation Driving and controls What you should know at the gas station Fuel tank capacity approximately 21.1 US gal (80.0 l). This includes approximately 2.6 US gal (10.0 l) reserve. Use premium unleaded gasoline: Posted Octane Index 91 (Average of 96 RON/ 86 MON). Engine oil Engine oil level check, see page 268.
Page 242: Check Regularly And Before A Long Trip
Check regularly and before a long trip E 320 shown Check regularly and before a long trip Instruments Operation Driving and controls Windshield washer system For refilling reservoir see page 271. Headlamp cleaning system Auxiliary tank connected to windshield washer reservoir.
Page 244: Instrument Cluster Display
Instrument cluster display Malfunction and indicator lamps in the instrument cluster ... 242 On-board diagnostic system ...242 Check engine malfunction indicator lamp ...242 Brake warning lamp ...243 Supplemental restraint system (SRS) indicator lamp ...244 Fuel reserve and fuel cap placement warning ...244 Electronic stability program (ESP) —...
Page 245: Malfunction And Indicator Lamps In The Instrument Cluster
If the “CHECK ENGINE” lamp is illuminated continuously and the vehicle is driving normally, you may still drive the vehicle, however, in all cases, we recommend that you have the system checked at your authorized Mercedes-Benz Center as soon as possible. Instrument Practical hints Car care cluster display If the “CHECK ENGINE”...
Page 246: Brake Warning Lamp
An on-board diagnostic connector is located in the passenger compartment near to the parking brake pedal, allowing the accurate identification of system malfunctions through the readout of diagnostic trouble codes. Brake warning lamp BRAKE Except Canada Canada only When the brake warning lamp and message appear while the engine is running, this means: •...
Page 247: Supplemental Restraint System (Srs) Indicator Lamp
If the warning lamp continues to blink after closing the fuel cap correctly, have the fuel system checked at your authorized Mercedes-Benz Center as soon as possible. Leaving the engine running and the fuel cap open can also cause the “CHECK ENGINE” lamp to illuminate, see also page 242.
Page 248: Electronic Stability Program (Esp) - Warning Lamp
When the voltage is above this value again, the malfunction indicator lamp should go out and the ABS is operational. Have the system checked at your authorized Mercedes-Benz Center as soon as possible. See page 225 for notes on antilock brake system (ABS). Instrument Practical hints...
Page 249: Indicator Lamp
Instruments Operation Driving and controls Malfunction and indicator lamps Seat belt warning lamp With the electronic key in steering lock position 2, the seat belt warning lamp comes on and a warning sounds for approximately 6 seconds if the driver’s seat belt is not fastened. Instrument Practical hints Car care...
Page 250: Messages In The Multifunction Display
Mercedes-Benz Center. Failure to repair condition noted may cause damage not covered by the Mercedes-Benz Limited Warranty, or result in property damage or personal injury. Instrument...
Page 251: Display Defective
Instruments Operation Driving and controls Malfunction and warning messages DISPLAY DEFECTIVE (engine control unit) Line 1 Line 2 DISPLAY DEFECTIVE VISIT WORKSHOP! This message is displayed to indicate that the information being relayed by the engine control unit is no longer complete. The coolant temperature gauge, tachometer, or the cruise control may have failed.
Page 252: Battery / Alternator
Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Instrument Practical hints Car care...
Page 253: Brake Assist
With the ABS malfunctioning, the BAS and ESP are also switched off. Have the system checked at your authorized Mercedes-Benz Center as soon as possible. Instrument Practical hints Car care cluster display BRAKE ASSIST P54.30-2938-21...
Page 254: Brake Fluid
BRAKE LINING WEAR VISIT WORKSHOP! When this message appears during braking, it indicates that the brake pads are worn down. Have the brake system checked at your authorized Mercedes-Benz Center as soon as possible. Malfunction and warning messages Instruments Operation Driving...
Page 255: Parking Brake
Instruments Operation Driving and controls Malfunction and warning messages PARKING BRAKE Line 1 Line 2 PARKING BRAKE RELEASE BRAKE! Parking brake, see page 210. Instrument Practical hints Car care cluster display ENGINE FAN Line 1 ENGINE FAN 1 The cooling fan for the coolant is faulty. Observe the coolant temperature gauge while driving, see page 90.
Page 256: Coolant (Coolant Level)
In cases of major or frequent minor coolant loss, have the cooling system checked at your authorized Mercedes-Benz Center as soon as possible. Notes: Do not drive without coolant in the cooling system. The engine will overheat causing major engine damage.
Page 257: Coolant Temp
Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Instrument Practical hints...
Page 258: Lighting System
LIGHTING SYSTEM Line 1 Line 2 LAMP DEFECTIVE CHECK LAMPS! DISPLAY DEFECTIVE VISIT WORKSHOP! Malfunction and warning messages Instruments Operation Driving and controls When the message appears after starting the engine, or if it come on while driving, this indicates a failure in the parking lamp, taillamp, stop lamp, or low beam headlamp.
Page 259: Light Sensor
Instruments Operation Driving and controls Malfunction and warning messages LIGHT SENSOR With the electronic key removed and the driver’s door open, a warning sounds and the message “SWITCH OFF LIGHTS!” appears in the multifunction indicator if the vehicle’s exterior lamps (except standing lamps) are not switched off.
Page 260: Tele Aid
System without or with insufficient steering gear oil level. Danger of damage to steering gear exists. When this message appears, the steering gear oil level has dropped below the required level. Have the system checked at the nearest Mercedes-Benz Center as soon as possible. Instrument Practical hints...
Page 261: Engine Oil Level
“full” mark on the dipstick with an approved oil. The engine oil level warnings should not be ignored. Extended driving with the symbol displayed could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Technical Index data...
Page 262: Washer Fluid
WASHER FLUID Line 1 Line 2 WASHER FLUID CHECK LEVEL! Malfunction and warning messages Instruments Operation Driving and controls When this message appears while the engine is running, the level of the reservoir has dropped to approximately of the total volume. The reservoir should be refilled with the prescribed mixture of MB Windshield Washer Concentrate “S”...
Page 263: Elec. Stabil. Prog
Instruments Operation Driving and controls Malfunction and warning messages ELEC. STABIL. PROG. (Electronic stability program) Line 1 Line 2 DISPLAY DEFECTIVE VISIT WORKSHOP! ELEC. STABIL. PROG. VISIT WORKSHOP! 1 A malfunction has been detected in the system. Pressing the accelerator pedal will require greater effort. Only partial engine output will be available.
Page 264 Practical hints First aid kit... 262 Fuses... 263 Electrical outlet ... 265 Hood... 266 Checking engine oil level ... 268 Automatic transmission fluid level ... 269 Coolant level ... 269 Adding coolant ...270 Windshield and headlamp washer system ... 271 Windshield and headlamp washer fluid mixing ratio ...
Page 265: First Aid Kit
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data First aid kit First aid kit The first aid kit is stored in the cargo area behind the right hand side trim panel. To open trim panel: Release lock and fold down.
Page 266: Fuses
Fuses Before replacing a blown fuse, determine the cause of the short circuit. Spare fuses are supplied inside the main fuse box. Observe amperage and color of fuse. A special fuse puller is supplied with the vehicle tools. Always use a new fuse for replacement. Never attempt to repair or bridge a blown fuse.
Page 267 Instruments Operation Driving and controls Fuses Lock for auxiliary fuse box and battery cover Fuse box and battery cover Instrument Practical hints Car care cluster display Auxiliary fuse box below right rear bench seat To gain access, fold seat cushion forward. Rotate lock (2) counterclockwise and remove cover.
Page 268: Electrical Outlet
Auxiliary fuse box to left of exterior lamp switch To again access, open door, pry off cover and remove. Fuses Instruments Operation Driving and controls Electrical outlet The electrical outlet is located in the rear compartment on the left side. To gain access, flip cover up.
Page 269: Hood
Instruments Operation Driving and controls Engine compartment Hood Warning! To help prevent personal injury, stay clear of moving parts when the hood is open and the engine is running. Be sure the hood is properly closed before driving. When closing hood, use extreme caution not to catch hands or fingers.
Page 270 To open: To unlock the hood, pull release lever (1) under the driver’s side of the instrument panel. At the same time a handle will extend out of the radiator grill (it may be necessary to lift the hood up slightly). Caution! To avoid damage to the windshield wiper or hood, open the hood only with wiper in the parked position.
Page 271: Checking Engine Oil Level
Excessive oil must be drained or siphoned. It could cause damage to engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. See malfunction and warning messages on page 258 if an engine oil level display appears on the multifunction display when the engine is running.
Page 272: Coolant Level
Regular automatic transmission fluid level checks and changes are not required. For this reason the dipstick is omitted. If you notice fluid leaks or gear shifting malfunctions, have your authorized Mercedes-Benz Center check the transmission fluid level. Engine compartment Instruments...
Page 273: Adding Coolant
Instruments Operation Driving and controls Engine compartment Adding coolant If coolant has to be added, a 50/50 mixture of water and MB anticorrosion/antifreeze should be added. The drain plugs for the cooling system are located on the right side of the engine block and at the bottom of the radiator.
Page 274: Windshield And Headlamp Washer Fluid Mixing Ratio
Windshield and headlamp washer system E 320 shown Windshield washer fluid reservoir Capacity approximately 5.8 US qt (5.5 l) Headlamp cleaning fluid reservoir Auxiliary tank connected to windshield washer reservoir. Open filler caps on both reservoirs during refilling. Capacity approximately 1.9 US qt (1.8 l) Engine compartment Instruments Operation...
Page 275: Spare Wheel, Vehicle Tools
Instruments Operation Driving and controls Spare wheel Spare wheel, vehicle tools Trim panel, left side Vehicle tools To open trim panel: Release lock and fold down. Note: If trim panel was fully removed, make certain to insert pins (arrows) into retainers in floor when reinstalling. Instrument Practical hints Car care...
Page 276: Vehicle Jack
Vehicle jack Jack arm Jack base The vehicle jack is stored behind the spare wheel. See illustration for proper storage of jack. To remove, first remove vehicle tools and spare wheel. Then open clamp and remove vehicle jack. Before storing the jack in the spare wheel well, the jack arm must be lowered almost to the base of the jack.
Page 277: Tire Replacement
Wheels Replace rims or tires with the same designation, manufacturer and type as shown on the original part. See your authorized Mercedes-Benz Center for further information. See your authorized Mercedes-Benz Center for information on tested and recommended rims and tires for summer and winter operation.
Page 278: Rotating Wheels
Rotating wheels The wheels can be rotated according to the degree of tire wear while retaining the same direction of travel. Rotating, however, should be carried out as recommended by the tire manufacturer, before the characteristic tire wear pattern (shoulder wear on front wheels and tread center wear on rear wheels) becomes visible, as otherwise the driving properties deteriorate.
Page 279: Spare Wheel Bolts
Instruments Operation Driving and controls Tires, Wheels Spare wheel Important! Unidirectional tires must always be mounted with arrow on tire sidewall pointing in direction of vehicle forward movement. If the arrow on tire side wall does not point in direction of vehicle forward movement when using the spare wheel, observe the following restrictions: •...
Page 280: Changing Wheels
Changing wheels Warning! The jack is designed exclusively for jacking up the vehicle at the jack tubes built into either side of the vehicle. To help avoid personal injury, use the jack only to lift the vehicle during a wheel change. Never get beneath the vehicle while it is supported by the jack.
Page 281 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tires, Wheels P40.10-2132-26 4. Using the wrench, loosen but do not yet remove the 5. Remove the protective cover from the jack support wheel bolts. tube opening by inserting the screwdriver (supplied in the tool kit) in the opening and prying it out.
Page 282 6. Insert jack arm fully into the tube hole up to the stop. Place jack on firm ground. Position the jack so that it is always vertical (plumb-line) as seen from the side (see arrow), even if the vehicle is parked on an incline.
Page 283 Instruments Operation Driving and controls Tires, Wheels Important! When installing steel spare wheel rim, make certain to use the correct wheel bolts, supplied in the vehicle tool kit, see page 276 and page 272. Instrument Practical hints Car care cluster display 10.
Page 284 11. Lower vehicle. Remove jack and insert jack tube cover. Before storing the jack, the jack arm must be lowered almost to the base of the jack. 12. Using the wrench, tighten the five bolts evenly, following the sequence illustrated, until all bolts are tight.
Page 285: Tire Inflation Pressure
Tires, Wheels Tire inflation pressure A table (see fuel filler flap) lists the tire inflation pressures specified for Mercedes-Benz recommended tires as well as for the varying operating conditions. Important! Tire pressure changes by approximately 1.5 psi (0.1 bar) per 18°F (10°C) of air temperature change.
Page 286: Battery
If a tire constantly loses air, it should be inspected for damage. The spare tire should be checked periodically for condition and inflation. Spare tire will age and become worn over time even if never used, and thus should be inspected and replaced when necessary.
Page 287 Battery must not leak acid when upside down for at least 15 minutes. Your authorized Mercedes-Benz Center can provide such a special battery. The service life of the battery is dependent on its condition of charge. The battery should always be kept sufficiently charged, in order to last an optimum length of time.
Page 288: Jump Starting
Only use 12 V battery to jump start your vehicle. Jump starting with more powerful battery could damage the vehicle’s electrical systems, which will not be covered by the Mercedes-Benz Limited Warranty. Jump start the car by using the battery terminals located under hood.
Page 289 Instruments Operation Driving and controls Jump starting Proceed as follows: 1. Position the vehicle with the charged battery so that the jumper cables will reach, but never let the vehicles touch. Make sure the jumper cables do not have loose or missing insulation. 2.
Page 290 Note: If engine does not run after several unsuccessful starting attempts, have it checked at the nearest authorized Mercedes-Benz Center. Excessive unburned fuel may damage the catalytic converter. Instrument Practical hints...
Page 291: Towing The Vehicle
Instruments Operation Driving and controls Towing the vehicle Towing the vehicle Prior to towing the vehicle with all wheels on the ground, make certain that the electronic key is in steering lock position 2. If the electronic key is left in the steering lock position 0 for an extended period of time, it can no longer be turned in the lock.
Page 292 We recommend that the vehicle be transported using flat bed equipment. This method is preferable to other types of towing. The vehicle may be towed with all wheels on the ground and the selector lever in position “N” for distances up to 30 miles (50 km) and at a speed not to exceed 30 mph (50 km /h).
Page 293: Transmission Selector Lever Manually Unlocking
Instruments Operation Driving and controls Towing the vehicle Transmission selector lever, manually unlocking In the case of power failure the transmission selector lever can be manually unlocked, e.g. to tow the vehicle. Instrument Practical hints Car care cluster display To do so, insert a pin (1), e.g. ball point pen, into the covered opening below the position “D”...
Page 294: Exterior Lamps
Exterior lamps Replacing bulbs Warning! Bulbs and bulb holder can be very hot. Allow the lamp to cool down before changing a bulb. Halogen lamps contain pressurized gas. A bulb can explode if you: • touch or move it when hot, •...
Page 295: Headlamp Assembly
Instruments Operation Driving and controls Exterior lamps Headlamp assembly Headlamp cover for low beam headlamp Headlamp cover for high beam headlamp, parking and standing lamp Instrument Practical hints Car care cluster display Bulb socket for turn signal lamp Electrical connector for low beam headlamp bulb Electrical connector for high beam headlamp bulb Bulb socket for parking and standing lamp Technical...
Page 296 Bulbs for low beam H7 (55 W) Open hood. Twist cover (1) counterclockwise and remove. Pull off electrical connector (4). Twist bulb holder counterclockwise and remove bulb from it. Insert the new bulb so that the base locates in the recess on the holder.
Page 297 Instruments Operation Driving and controls Exterior lamps Turn signal lamp 1156 NA (26.9/5 W/32/4 cp bulb) Open hood. Twist bulb socket (3) counterclockwise and pull out. Push bulb into socket, turn counterclockwise and remove. Insert new bulb in socket, push in and twist clockwise. Reinstall bulb socket.
Page 298: Taillamp Assemblies
Taillamp assemblies Turn signal lamp (21 W/24 cp bulb) Stop, tail, parking and side marker lamp (21/4 W bulb) Exterior lamps Instruments Operation Driving and controls P82.10-2620-26 Backup lamp (21 W/32 cp bulb) Driver’s side: Rear fog lamp (21 W/32 cp bulb) Instrument Practical hints cluster display...
Page 299 Instruments Operation Driving and controls Exterior lamps Open tailgate and left or right trim panel. Twist bulb socket counterclockwise and pull out. Push bulb into socket, turn counterclockwise and remove. Insert new bulb in socket, push in and twist clockwise. Reinstall bulb socket, and close trim panel.
Page 300 The high mounted stop lamp (3rd brake lamp), and the additional turn signals on the exterior mirrors are equipped with LEDs. Have the system checked at an authorized Mercedes-Benz Center if a malfunction occurs. Instrument Practical hints Car care cluster display...
Page 301: Changing Batteries In The Electronic Main Key
Instruments Operation Driving and controls Electronic main key Changing batteries in the electronic main key Transmit buttons Lamp for battery check and function control Checking batteries If one of the transmit buttons (1) is pressed, the battery check lamp (2) lights up briefly – indicating that the batteries are in order.
Page 302 Insert mechanical key (4) in side opening (5) to open latch. Press briefly (do not use mechanical key as lever) to release battery compartment. Remove mechanical key from side opening. Carefully remove battery compartment in direction of arrow (6). Electronic main key Instruments Operation Driving...
Page 303: Synchronizing Remote Control
Instruments Operation Driving and controls Electronic main key Important! Batteries contain materials that can harm the environment if disposed of improperly. Recycling of batteries is the preferred method of disposal. For disposal, please follow manufacturer’s recommendation on battery package. Replacement Battery: Lithium, type CR 2025 or equivalent.
Page 304: Emergency Operation Of Sliding / Pop-Up Roof
Emergency operation of sliding /pop-up roof The sliding/pop-up roof can be opened or closed manually should an electrical malfunction occur. The sliding/pop-up roof drive is located behind the lens of the left interior lamp between the sun visors. 1. Pry off lens (1) by using a screw driver. 2.
Page 305: Manual Release For Fuel Filler Flap
Instruments Operation Driving and controls Manual release for fuel filler flap Manual release for fuel filler flap The manual release knob is located behind the right side rear compartment trim panel. In case the central locking system does not release the fuel filler flap, pull the manual release knob (arrow) while simultaneously opening the fuel filler flap.
Page 306 Removal: Fold wiper arm forward. Press safety tab down (1), push wiper blade downward (2) and remove. Place wiper blade on firm support. Press down both tabs and slide (direction of arrow) the wiper blade insert out of the retainer claws. Replacing wiper blade insert Instruments Operation...
Page 307 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Replacing wiper blade insert Rear window wiper blade Removal: Fold wiper arm (1) away from rear window and rotate wiper blade (2) until perpendicular to wiper arm. Push safety tab (3) of attachment link (4) and pull wiper blade from end of wiper arm.
Page 308: Roof Rack
Roof rack Cross bar Knurled-head screws Clamping plates Protective strips The cross bars (1) should only be used as guard rails to prevent luggage from sliding. They must only be installed above the protective strips (4). Roof rack Instruments Operation Driving and controls Installation:...
Page 309 Car care cluster display Note: Use only roof racks approved by Mercedes-Benz. They mount to the roof railings and do not require additional supports (e.g. suction cups or legs). Such supports may lead to marring of the paint or denting of the roof. For further information inquire at your Mercedes-Benz Center.
Page 310: Vehicle Care
Vehicle care Cleaning and care of the vehicle... 308 Power washer ...309 Tar stains ...309 Paintwork, painted body components ...309 Engine cleaning ... 310 Contents - Vehicle care Instruments Operation Driving and controls Vehicle washing ...310 Instrument cluster ... 312 Ornamental moldings ...310 Steering wheel and gear selector lever ...
Page 311: The Vehicle
Your vehicle has been treated at the factory with a wax- base rustproofing in the body cavities which will last for the lifetime of the vehicle. Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others applied later.
Page 312: Power Washer
Mercedes-Benz Center. The following topics deal with the cleaning and care of your vehicle and give important “how-to” information as well as references to Mercedes-Benz approved car-care products. Additional information can be found in the booklet titled “Vehicle Car Guide”.
Page 313: Engine Cleaning
For regular cleaning and care of very dirty chrome- plated parts, use a chrome cleaner. Headlamps, taillamps, turn signal lenses Use a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo, with plenty of water. To prevent scratches, never apply strong force and use only a soft, non-scratchy cloth when cleaning the lenses.
Page 314: Cleaning The Parktronic System Sensors
Cleaning the parktronic system sensors Use a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo, with plenty of water. When using a steam cleaner or power washer, aim nozzle only briefly from a minimum distance of 4 in.
Page 315: Light Alloy Wheels
Cleaning and care of the vehicle Light alloy wheels Mercedes-Benz approved Wheel Care should be used for regular cleaning of the light alloy wheels. If possible, clean wheels once a week with Mercedes-Benz approved Wheel Care, using a soft bristle brush and a strong spray of water.
Page 316: Upholstery
Cloth Upholstery Clean with soft bristle brush, or use a dry-shampoo cleaner in case of excessive dirt. MB Tex Upholstery Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure. Cleaning and care of the vehicle Instruments...
Page 318 Technical data Spare parts service ... 316 Warranty coverage... 316 Identification labels... 317 Layout of poly-V-belt drive... 318 Technical data... 319 Fuels, coolants, lubricants etc. - capacities ... 322 Contents - Technical data Instruments Operation Driving and controls Engine oils... 324 Engine oil additives ...
Page 319: Spare Parts Service
Therefore, Mercedes-Benz original spare parts should be installed. Important! The use of non-genuine parts and accessories not authorized by Mercedes-Benz could damage the vehicle which damage is not covered by the Mercedes-Benz Limited Warranty or compromise its durability or safety. Instrument Practical hints Car care...
Page 320: Identification Labels
Identification labels Certification label Technical data Instruments Operation Driving and controls P63.20-2368-26 Vehicle Identification Number (VIN) Instrument Practical hints Car care cluster display Technical Index data...
Page 321: Layout Of Poly-V-Belt Drive
Instruments Operation Driving and controls Technical data VIN, visible (lower edge of windshield) Engine number Body number and paintwork number Emission control label Information label, California version Vacuum line routing for emission control system When ordering spare parts, please specify vehicle identification and engine number.
Page 322: Technical Data
Maximum torque acc. to SAE J 1349 232 ft.lb/3000 rpm Maximum engine speed Firing order Poly-V-belt 1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Technical data Instruments...
Page 323 Instruments Operation Driving and controls Technical data Rims – Tires Rims (light alloy) Wheel offset 1.6 in (41 mm) All season tires: Radial-ply tires 215 /55 R 16 93 H Winter tires: Radial-ply tires 215 /55 R 16 93 H M+S Spare wheel Rim (steel) Wheel offset...
Page 324 Weights (see certification tag) Roof load on roof rails max. Roof load on protective strips (distributed over total area) max. Technical data Instruments Operation Driving and controls Main dimensions Overall vehicle length 220 lb (100 kg) Overall vehicle width Overall height 175 lb (80 kg) Wheel base Track, front...
Page 325: Fuels, Coolants, Lubricants Etc. - Capacities
Fuels, coolants, lubricants etc. - capacities Vehicle components and their respective lubricants must match. Therefore use only brands tested and recommended by us. Please refer to the Factory Approved Service Products pamphlet, or inquire at your authorized Mercedes-Benz Center. Model...
Page 326 Model Windshield washer system Headlamp washer system Cooling system Fuel tank including a reserve of Air conditioner system 1 Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing or MB Windshield Washer Concentrate “S” and commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing. Follow suggested mixing ratios, see page 271.
Page 327: Engine Oils
Engine oil additives Do not blend oil additives with engine oil. They may be harmful to the engine operation. Damage or malfunctions resulting from blending oil additives are not covered by the Mercedes-Benz Limited Warranty. Instrument Practical hints Car care...
Page 328: Premium Unleaded Gasoline
Premium unleaded gasoline Caution! To maintain the engine’s durability and performance, premium unleaded gasoline must be used. If premium unleaded is not available and low octane fuel is used, follow these precautions: • have the fuel tank filled only partially with unleaded regular and fill up with premium unleaded as soon as possible, •...
Page 329: Gasoline Additives
Fuels, coolants, lubricants etc. - capacities Gasoline additives A major concern among engine manufacturers is carbon build up caused by gasoline. Mercedes-Benz recommends the use of only quality gasoline containing additives that prevent the build up of carbon deposits. After an extended period of using fuels without such...
Page 330 (Failure to use such anticorrosion / antifreeze coolant will result in a significantly shortened service life.) Therefore the following product is strongly recommended for use in your car: Mercedes-Benz Anticorrosion/Antifreeze Agent. Fuels, coolants, lubricants etc. - capacities Instruments...
Page 331: Consumer Information
Instruments Operation Driving and controls Consumer information Consumer information This has been prepared as required of all manufactures of passenger cars under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”. Uniform tire quality grading Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum...
Page 332 Traction The traction grades, from highest to lowest are “AA”, “A”, “B”, and “C”. Those grades represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked “C” may have poor traction performance.
Page 333: Index
Instruments Operation Driving and controls Index ABS (Antilock brake system) ...225 Malfunction indicator lamp ...245 ABS-SYSTEM - malfunction and warning messages ...250 Adjusting steering wheel ... 81 Air conditioner refrigerant ...324 Air distribution ... 130 Air volume ... 130 Airbag deactivation system ... 67 AIRBAG OFF indicator lamp ...246 Airbags ...70 Alarm system ...
Page 334 Economy ...129 Front center console compartment ventilation ... 133 Rear passenger compartment adjustable air outlet ... 134 Rear window defroster ... 130 Residual engine heat utilization (REST) ... 132 Special settings ...129 Automatic transmission ...201 Emergency operation ...209 Fluid level ...269 Program mode selector switch ...208 Selector lever position ...204 Transmission selector lever,...
Page 335 Instruments Operation Driving and controls Choosing global or selective mode ... 32 Electronic main key ...25 Electronic reserve key ... 26 Locking and unlocking ... 31 Mechanical keys ... 26, 33 Remote control ... 25 Summer opening/convenience feature ...32 CHECK ENGINE malfunction indicator lamp ...242 Check regularly and before a long trip ...239 Checking engine oil level...
Page 336 ELEC. STABIL. PROG. - malfunction and warning messages ...260 Electrical outlet ...265 Electronic main key ...25 Changing batteries ...298 Synchronizing remote control ...300 Electronic stability program (ESP) ...228 Control switch ...230 Malfunction indicator lamp ...245 Synchronizing ...229 Warning lamp ...245 Emergency call See Tele Aid ...
Page 337 Instruments Operation Driving and controls Parking lamps ...294, 295 Replacing bulbs ... 291 Side marker lamp, front ...297 Standing lamps ...294, 295 Taillamp assemblies ...295 Turn signal lamps ...294, 295 First aid kit ...262 Flexible service system (FSS) ...114 Four wheel electronic traction system (4MATIC) with electronic stability program (ESP) ...227 Fuel ...237...
Page 338 Identification labels ... 317 Illuminated vanity mirrors ... 160 Indicator lamps in the instrument cluster ... 88, 242 Individual settings ...110 Infant and child restraint systems ... 78 Information call See Tele Aid ... 186 Instrument cluster ...86 Activating ...89 Illumination ...
Page 339 Instruments Operation Driving and controls Maintenance ... 185 Malfunction and indicator lamp in the center console ...246 Malfunction and indicator lamps in the instrument cluster ...242 Malfunction and warning messages ...247 ABS-SYSTEM ...250 BATTERY / ALTERNATOR ...249 BRAKE ASSIST ...250 BRAKE FLUID ...251 BRAKE LINING WEAR ...251 COOLANT (coolant level) ...253...
Page 340 Navigation system - Multifunctions display ... 105 Night security Illumination ...120 On-board diagnostic system ...242 Operator’s manual ... 8 Outside temperature indicator ...90 Overhead control panel ... 21 Panic button ... 33 Parcel net in front passenger footwell ... 178 Parking ...
Page 341 Instruments Operation Driving and controls REMOVE KEY - malfunction and warning messages ...256 Replacing bulbs ... 291 Replacing wiper blade insert ...302 Reporting Safety Defects ... 15 Reserve key ...26 Residual engine heat utilization (REST) ... 132 Roadside assistance ... 10 Roadside assistance call See Tele Aid ...
Page 342 STEERING GEAR OIL - malfunction and warning messages ...257 Steering lock ... 198 Steering wheel adjustment ... 81 Storage compartments Above ashtray in center console ... 163 Glove box ... 162 In center console ... 163 Stowing things in the vehicle ...176 Sun visors ...
Page 343 Instruments Operation Driving and controls Transmission selector lever, manually unlocking ...290 Traveling abroad ... 219 Trip computer ... 106 Trip odometer ... 91 Turn signal failure ...122 Turn signals ... 122 Vanity mirrors ... 160 Vehicle jack ...273 Vehicle tools ...272 Warranty Coverage ...
Page 344: Service And Literature
If you have any question about carrying out some service, turn to the advice of an authorized Mercedes-Benz Center.
Page 345 Order No. 6515 1079 13 Part No. 210 584 4996 USA Edition B 2001...

This manual is also suitable for:

2001 e 320

Mercedes-Benz 2001 E -Class Wagon Operator's Manual

Introduction

Instruments and Controls

Operation

Driving

Instrument Cluster Display

Vehicle Care

Index

Quick Links

Need help?

Questions and answers

Related Manuals for Mercedes-Benz 2001 E -Class Wagon

Summary of Contents for Mercedes-Benz 2001 E -Class Wagon
