Page 2: Chapter 1 - Getting Started
Installation Instructions Chapter 1 – Getting Started 1.1 Subject The Neo Bluetooth adapter will provide seamless Bluetooth integration into many factory car stereos. When connected to the car stereo the adapter provides wireless hands-free operation with accept/reject call features. The Neo Bluetooth adapter also enables wireless A2DP music playback with AVRCP control. - Page 3 1.5 Completeness and connection of set a) NEO Bluetooth adapter set consists of the following (see figure 1). b) Basic wiring diagram of NEO Bluetooth adapter (see Figure 2): 1.6 Important Compatibility Notes If your vehicle is equipped with an external factory CD changer, you must disconnect it in order to be able to install the interface.
- Page 4 2.3 Preparation and adapter installation Turn off car engine and remove key from ignition. If your radio uses a Security Code, make sure that you have the code before unplugging the radio. Un-mount your radio from the dash in order to get access to the back side of the radio.
- Page 5 Picture 2 Back of the Nissan Radio Connect the RED power wire (can also be yellow) (5) on the NIS2 harness to the radio 12V constant wire. You will need to use the blue Posi-Tap clip (6) provided with your package. Locate the radio 12V constant wire.
- Page 7 Connect the 12V constant wire and red power wire (can also be yellow) (5) on NIS02 harness using the Posi-Tap. Please refer to the scheme below for the proper connection (scheme 1). Scheme 1. How to connect the wires using Posi-taps. The wire (the 12V constant wire) that comes from your stereo is the “HOT”...
- Page 8 Once the interface is connected to the radio, you will need to test the operation of the interface before re-assembling the dash. Turn your car stereo on and switch it over to the CD Changer mode using the Disk / Mode / CD / AUX (depending on the stereo type) buttons on your car stereo until it shows Disk 1, Track 01 on a the display.
- Page 9 NOTE3: The Bluetooth interface is on as long as vehicle is on. If radio is OFF, and you are receiving a call, you can answer automatically by turning ON the radio and selecting the adapter mode. 2.5 Using your phone in the hands-free mode. Once the Bluetooth is paired with the phone and the stereo is in CD Changer mode you can start using your phone hands free.
- Page 10 Chapter 3. - Support Troubleshooting For technical support please contact Neo Car Audio 619-704-0690...
